LITHIUM + 16V [RACING] MODE (16V 19.5A):
Long press 3sec. the MODE selection button, if the measured voltage is
between 2 V and 12.8 V the battery is identified as a Lithium (16V 4-cells
LiFePO4) to activate LITHIUM + 16V [RACING] mode.
Then if you do not take any further action, the electronic system will
automatically start the charging process together with the LCD display will
flash at (with a current of) 19.5A. If the process runs without any problems,
the LCD display will show the battery charging (bars will start flashing) until the
battery is charged. When the battery is fully charged, the battery icon should
be full and will stop flashing. The device now switches automatically into
maintenance charging mode.
JUMP CHARGE MODE (15V 20A):
To operate JumpCharge, the charger must be connected to a 12V battery with
the battery clamp connectors connected. If the battery voltage is between 2.0
V and 15 V, and go to charging mode after user presses the JUMP CHARGE
Button.
Charging Program: Begin 2.6A current charging, 270 seconds, then 30A
charging, 30 seconds. After that go to Stand-by mode.
JumpCharge completes after a five minute charge.
NOTE: Use the mode with care. This mode is for 12V Lead-Acid batteries only.
SMPS 13.6V MODE (13.6V 5A):
This mode is adaptor, it can be used to as a 13.6V 5.0A DC power supply, and
it can be used to float charging for 12V battery also.
Long press 3sec. the MODE selection button at no battery connected status
after doing so, the corresponding LCD display SMPS 13.6V lights up.
Then if you do not take any further action, the electronic system will
automatically start the power supply output process as adaptor function
together with the LCD display the output is 13.6V DC 5.0A.
NOTE: DO NOT short-circuit the output terminals after the MODE SMPS
13.6V has started.
