Installation Instructions
Model Number HBZDV3624, HBZDV3628, HBZDV3632
Zero Clearance Direct Vent Fireplace
Stock #'s: HBZDV3624N, HBZDV3624LP are
Certified to: ANSI Z21.50-2014 • CSA 2.22-2014
ZERO CLEARANCE VENTED GAS FIREPLACE
Stock #'s: HBZDV3628N, HBZDV3628LP, HBZDV3632N and HBZDV3632LP are
Certified to: ANSI Z21.88-2014 • CSA 2.33-2014
ZERO CLEARANCE VENTED GAS FIREPLACE HEATER
This appliance may be installed in an
aftermarket, permanently located,
manufactured home (USA only) or mobile
home, where not prohibited by local
codes.
This appliance is only for use with the
type of gas indicated on the rating
plate. This appliance is not convertible
for use with other gases, unless a
certified kit is used.
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for future
reference.
For Propane Horizontal installations the
venting must be a minimum of one foot
vertical off the flue before going horizontal.
A Division of R-Co. Inc.
2340 Logan Avenue
Winnipeg, Manitoba, Canada R2R 2V3
Ph: (204) 632-1962
Printed in Canada March 31, 2017
Part # 36HB-MAN14
