SOLACE/SKYLINE
Models:MQHBZDV3636N, MQHBZDV3636NE, MQHBZDV3636NE2, MQHBZDV3636LP, MQHBZDV3636LPE,
MQHBZDV3636LPE2
Models: MQHBZDV4236N, MQHBZDV4236NE, MQHBZDV4236NE2, MQHBZDV4236LP, MQHBZDV4236LPE,
MQHBZDV4236LPE2
Models:MQRB4236NT, MQRB4236NTE, MQRB4236NTE2, MQRB4236LPT, MQRB4236LPTE, MQRB4236LPTE2
Models: HBZDV4736N, HBZDV4736NE, HBZDV4736NE2, HBZDV4736LP, HBZDV4736LPE, HBZDV4736LPE2
Certified to: ANSI Z21.88-2017 • CSA 2.33-2017 Vented Gas Fireplace Heaters, CSA 2.17-2017
MQHBZDV3636, MQHBZDV4236, MQRB4236T, HBZDV4736
Installation Instructions
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of
gas indicated on the rating plate. This appliance
is not convertible for use with other gases,
unless a certified kit is used.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
For Propane Horizontal installations the venting
must be a minimum of one foot vertical off the
flue before going horizontal.
VENTED GAS FIREPLACE HEATER:
NOT FOR USE WITH SOLID FUEL.
A Division of R-Co. Inc.
2340 Logan Avenue
Winnipeg, Manitoba, Canada R2R 2V3
Ph: (204) 632-1962
Printed in Canada February 9, 2021
Part # 36MQ-MAN17
Advertisement
Table of Contents
Related Manuals for Kingsman Fireplaces SOLACE
Summary of Contents for Kingsman Fireplaces SOLACE
- Page 1 SOLACE/SKYLINE Installation Instructions MQHBZDV3636, MQHBZDV4236, MQRB4236T, HBZDV4736 Models:MQHBZDV3636N, MQHBZDV3636NE, MQHBZDV3636NE2, MQHBZDV3636LP, MQHBZDV3636LPE, MQHBZDV3636LPE2 Models: MQHBZDV4236N, MQHBZDV4236NE, MQHBZDV4236NE2, MQHBZDV4236LP, MQHBZDV4236LPE, MQHBZDV4236LPE2 Models:MQRB4236NT, MQRB4236NTE, MQRB4236NTE2, MQRB4236LPT, MQRB4236LPTE, MQRB4236LPTE2 Models: HBZDV4736N, HBZDV4736NE, HBZDV4736NE2, HBZDV4736LP, HBZDV4736LPE, HBZDV4736LPE2 Certified to: ANSI Z21.88-2017 • CSA 2.33-2017 Vented Gas Fireplace Heaters, CSA 2.17-2017...
-
Page 2: Table Of Contents
Table of Contents Table of Contents……………………………………………………………........Pre-installation Questions and Answers…………………………………........Operating Instructions………………………………………………………........Safety Screen Installation…………………………………………………………………………… Mobile Home/Manufactured Housing Installation……………………........Warnings, Installations, and Operations…………………………………........Installation Requirements for the Commonwealth of Massachusetts…........Fireplace Installations in Covered Outdoor Locations............. MQHBZDV3636 Locating your Appliance................Fireplace Dimensions................. - Page 3 Configuration 2- Remote ON/OFF................... Operating the Receiver Without Batteries For GT / EGT / GTM / EGTM Remote Controls..Configuration 3- Remote ON/OFF, Variable Hi/Lo, and Fan........... IPI Lighting Instructions......................PROFLAME 2 Parts List, GTMFL System....................... IFC Module and Remote Control..................... Cold Climates –...
-
Page 4: Pre-Installation Questions And Answers
Pre-installation Questions and Answers About curing of the paint Your stove or fireplace has been painted with the highest quality silicone stove paint. This paint dries quickly in 15-20 minutes when first applied at the factory. However, due to the high temperature silicone components, the paint will cure when heat is applied to the appliance as it is first used. -
Page 5: Safety Screen Installation
Safety Screen Installation Z Series Contents of Kit: [1] Safety Screen [2] Side Angles [2] Horizontal Angles [12-16] DT Screws (Depending on screen size) Assembly: Attach components with supplied screws as shown. NOTE: Screens are symmetrical from top to bottom. ⚠... -
Page 6: Mobile Home/Manufactured Housing Installation
Mobile Home/Manufactured Housing Installation This Direct Vent System Appliance must be installed in accordance with the manufacturer’s installation instructions and the Manufactured Home Construction and Safety Standard Title 24 CFR, Part 3280, or the current Standard for Fire Safety Criteria for Manufactured Home Installations, Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240 MH Mobile Home Standard in Canada. -
Page 7: Warnings, Installations, And Operations
Warnings, Installations and Operations - Installation Regulations This gas appliance must be installed by a qualified installer in accordance with local building codes, or in the absence of local codes, with the current CAN/CSA-B149.1 or .2 Installation Code (in Canada) or the current National Fuel Gas Code Z223.1- NFPA 54 when installed in the United States. -
Page 8: Installation Requirements For The Commonwealth Of Massachusetts
Installation Requirements for the Commonwealth of Massachusetts In the Commonwealth of Massachusetts, the installer or service agent shall be a plumber or gas fitter licensed by the Commonwealth. When installed in the Commonwealth of Massachusetts or where applicable codes; the unit shall be installed with a CO detector per the requirements listed below. -
Page 9: Fireplace Installations In Covered Outdoor Locations
Fireplace Installations in Covered Outdoor Locations – FOR BASIC MILLIVOLT UNITS ONLY- NO FAN – NO LIGHTS- CAUTION – Installation of an indoor gas fireplace with an outdoor exposure is not covered under the (ANSI Z21.88 – CSA 2.22 or ANSI Z21.50 – CSA 2.33) standard(s) used to certify the indoor gas-fired fireplace. The Intertek safety certification will not apply to this installation method. -
Page 10: Locating Your Appliance
Locating Your Appliance LOCATION KEY: Flat on Wall Across the Corner As an Island As a Room Divider Flat on Wall Corner Exterior Wall See Mantel Leg Clearances Instruction for the proper placement of fireplace. Island installation with a top vent is possible as long as the horizontal portion of the vent system does not exceed 20 feet (6.1 m). -
Page 11: Framing For Your Gas Fireplace
MQHBZDV3636 - Framing for your Gas Fireplace 4. When installing horizontal with a 90 degree bend maintain a mini- Framing Specifications mum of two and a half (2.5”) inches above the bend in enclo- 1. Cold climate installation recommendation: When installing this fire- sures. -
Page 12: Framing And Facing Requirements
HBZDV36 - Framing and Facing Requirements HBZDV36 WITH HB36CVCK (CLEAN VIEW CIRCULATING KIT) Non Combustible Header Attached Non Combustible Header Attached... -
Page 13: Installing Clean View Kit (Cvck)
MQHBZDV3636 - HOW TO INSTALL CLEAN VIEW KIT (CVCK) CAUTION: When using CVCK DO NOT INSTALL a Louver assembly. Install optional fan kit (see Fan Instruction). Fold two standoffs up into position and mount with supplied screws. (FIG 1) Hang CVCK on top of fireplace retainer tabs and rotate down into position. (FIG 2) Using the screws provided, fasten the non-combustible header onto the top of the CVCK assembly. - Page 14 MQHBZDV3636 Parts List 1001-P634SI Valve Nova NG Hi/Lo 0820652 Fireplace Part Numbers Fireplace Heater Rated NG, Ceramic 1001-P713SI Pilot Burner LP 199.713 TC SIT MQHBZDV3636N (Millivolt) Glass, 30,500 BTU AT 75% efficient. MQHBZDV3636NE (IPI) 1001-P714SI Pilot Burner NG 199.714 TC SIT Approved for bedroom and mobile MQHBZDV3636NE2 (IPI) Optional Thermostats and Remote Controls...
-
Page 15: Parts List
Parts List - Continued Kingsman Fireplace Venting Catalog Number Description ZDVHSK Horizontal Vent Starter Kit - 3 FT Length Horizontal Vent Termination, Wall Thimble, 36” Flex Pipe, Mill Pac, screws/washers, springs. ZDVHSK5 Horizontal Vent Starter Kit - 5 FT Length Horizontal Vent Termination, Wall Thimble, 60”... -
Page 16: Locating Your Appliance
Locating Your Appliance LOCATION KEY: Flat on Wall Across the Corner As an Island As a Room Divider Flat on Wall Corner Exterior Wall See Mantel Leg Clearances Instruction for the proper placement of fireplace. Island installation with a top vent is possible as long as the horizontal portion of the vent system does not exceed 20 feet (6.1 m). -
Page 17: Framing For Your Gas Fireplace
MQHBZDV4236/MQRB4236 - Framing for your Gas Fireplace 4. When installing horizontal with a 90 degree bend maintain a minimum Framing Specifications 1. Cold climate installation recommendation: When installing this fire- of two and a half (2.5”) inches above the bend in enclosures. place against non insulated exterior wall or chase, it is recom mended 5. -
Page 18: Framing And Facing Requirements
HB42 - Framing and Facing Requirements HBZDV42 WITH HB42CVCK (CLEAN VIEW CIRCULATING KIT) Non Combustible Header Attached Non Combustible Header Attached... -
Page 19: Installing Clean View Kit (Cvck)
MQHBZDV4236/MQRB4236 - HOW TO INSTALL CLEAN VIEW KIT (CVCK) CAUTION: When using CVCK DO NOT INSTALL a Louver assembly. Install optional fan kit (see Fan Instruction). Fold two standoffs up into position and mount with supplied screws. (FIG 1) Hang CVCK on top of fireplace retainer tabs and rotate down into position. (FIG 2) Using the screws provided, fasten the non-combustible header onto the top of the CVCK assembly. -
Page 20: Parts List
MQHBZDV4236 & MQRB4236T Parts List Fireplace Part Numbers Conversion Kit (Sit Valve Only) Fireplace Heater Rated NG, Ceramic 4232HB-CKLP MQHBZDV4236LP - Millivolt MQHBZDV4236N (Millivolt) Glass, 30,500 BTU AT 75% efficient. MQHBZDV4236NE (IPI) 4232HB –CKLPI MQHBZDV4236LPE - Proflame 1 Approved for bedroom and mobile 4232HB –CKLP2 MQHBZDV4236LPE2 –... -
Page 21: Kingsman Fireplace Venting Parts
ZDVDFA Simpson Dura-Vent Fireplace Adapter (for 1001-P166si Orifice Pilot (NG) 1001-P168si Orifice Pilot (LP) ZDV33/36/42/47, ZDV6000, MDV31 & HB 1002-P013si Stepper Motor (NG) models) 1002-P012si Stepper Motor (LP) ZDVHSKSQ Horizontal Square Termination Vent 1002-P016si Hi/Lo Regulator (NG) Starter Kit - 3 FT Length 1002-P014si Hi/Lo Regulator (LP) Horizontal Vent Termination, Wall Thimble,... -
Page 22: Locating Your Appliance
Locating Your Appliance LOCATION KEY: Flat on Wall Across the Corner As an Island As a Room Divider Flat on Wall Corner Exterior Wall See Mantel Leg Clearances Instruction for the proper placement of fireplace. Island installation with a top vent is possible as long as the horizontal portion of the vent system does not exceed 20 feet (6.1 m). -
Page 23: Framing For Your Gas Fireplace
MQHBZDV4736 - Framing for your Gas Fireplace sleeve is required. If greater than six and a half (6.5”) an insulation sleeve Framing Specifications is not required. 1. Cold climate installation recommendation: When installing this fire- place against non insulated exterior wall or chase, it is recom mended 5. -
Page 24: Framing And Facing Requirements
Non Combustible Header Attached Non Combustible Header Attached... -
Page 25: Installing Clean View Kit (Cvck)
MQHBZDV4736- HOW TO INSTALL CLEAN VIEW KIT (CVCK) CAUTION: When using CVCK DO NOT INSTALL a Louver assembly. Install optional fan kit (see Fan Instruction). Fold two standoffs up into position and mount with supplied screws. (FIG 1) Hang CVCK on top of fireplace retainer tabs and rotate down into position. (FIG 2) Using the screws provided, fasten the non-combustible header onto the top of the CVCK assembly. - Page 26 MQHBZDV4736 Parts List 1001-P714SI Pilot Burner NG 199.714 TC SIT Fireplace Part Numbers HBZDV4736N Fireplace Heater Rated NG, Tempered Glass, Optional Thermostats and Remote Controls (Millivolt) 40,000 BTU Z2MT Thermostat Digital ‐ Vertical Wall Mount ‐ MV/PF1 HBZDV4736NE Fireplace Heater Rated NG, Tempered Glass, Z80PT Thermostat Programmable Digital ‐...
-
Page 27: Parts List
Parts List - Continued Kingsman Fireplace Venting Catalog Number Description ZDVHSK Horizontal Vent Starter Kit - 3 FT Length Horizontal Vent Termination, Wall Thimble, 36” Flex Pipe, Mill Pac, screws/washers, springs. ZDVHSK5 Horizontal Vent Starter Kit - 5 FT Length Horizontal Vent Termination, Wall Thimble, 60”... -
Page 28: Common Section Clearances - Mantels
Clearances – HB36 / HB42 / HB47 – Mantels Warning: Combustible objects must not be placed on a non-combustible mantel unless the non- combustible mantel meets the minimum height and width requirements for a combustible mantel. -
Page 29: Mantel Leg Clearances
Mantel Leg Clearances Mantels Depending on the depth of the fireplace mantel, it may be installed higher or lower from the top of the fireplace opening. See drawings for proper installation height of your combustible mantel. Non-combustible mantels may be installed at any height above the fireplace opening except when using MQHBSW. -
Page 30: Fan Installation
Fan Installation for HBZDV 36/42/47 3. Wire Junction Box to 120v and wall mounted variable speed control. Fan Installation instructions for HBZDV36/42/47 Install a duplex outlet to junction box and plug fan into outlet. with or without CVCK (Clean View Circulating Kit) 4. -
Page 31: Split Receptacle- Fan Speed Control Outside Of Fireplace
Split Receptacle- Fan Speed Control Outside of Fireplace If you plan to locate the variable speed control switch for the fan outside of the fireplace and you require a constant source of AC power inside the unit for another accessory such as lights or an IPI valve system, follow one of the procedures below. -
Page 32: Installing Mqrb4236T Liner Panels
Installing MQRB4236 Liner Panels There are several types of Liner Panels available for the MQRB4236: -Flat Black Back Panel and False Bottom- (Supplied with Unit). -Porcelain Back and Side Panels- MQRB42PL Removal of False Bottom and Back Panel Remove four [4] screws from False Bottom and lift out of the Firebox (Ref.1). The Back Panel is held in place by the False Bottom and 2 Locking Tabs on the inside top of the Firebox (See Ref.2 Below). -
Page 33: Brick Installation
Brick Installation - For Models MQHBZDV3636 / MQHBZDV4236 / HBZDV4736 INSTALLING BRICK PANELS FOR MODEL MQHBZDV3636 / MQHBZDV4236 / HBZDV4736 1. Remove door glass from the unit by unlatching the 2 latches on top of unit. 2. (MQHBZDV4736 ONLY) Using a 1/4” nut driver remove two screws from Brick Panel Filler (#1) and discard brick panel filler. (Ref.1) 3. -
Page 34: Installation Of Hb Porcelain Liners - Hb36Pl/Hb42Pl/Hb47Pl
Installation of HB Porcelain Liners - HB36PL/HB42PL/HB47PL 1. Remove Door from the fireplace by unlatching the 2 latches on top of unit. 2. Remove back Log Holder by removing 3 screws from face of Log Holder. The Log Holder will have to be re- installed after the placement of the Back Panel. -
Page 35: Gas Line Installation
Gas Line Installation This gas appliance should be installed by a qualified installer in accordance with local building codes and with current CAN/CGA - B149.1 or .2 installation codes for Gas Burning appliances and equipment in Canada and the National Fuel Gas Code ANSI Z223 in the U.S.A. -
Page 36: Millivolt System, Lighting, And Burner Control
Millivolt System, Lighting, and Burner Control FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. BEFORE LIGHTING This appliance has a pilot which must be lighted by hand. When ... -
Page 37: Troubleshooting The Gas Control System
Troubleshooting the Gas Control System ⚠ WARNING BEFORE DOING ANY GAS CONTROL SERVICE WORK, REMOVE THE GLASS FRONT. NOTE: Before troubleshooting the gas control system, be sure external gas shut off is in the "On" position. Problem Possible Causes Corrective Action Spark igniter will not Defective or misaligned Check for spark at electrode and pilot: if no spark and electrode wire is... -
Page 38: Burner System Removal For Mqhb36/42/47
Burner System Removal for MQHB36/42/47 Warning: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. Removing Burner System / Access Cover for MQHBZDV36/42/47 If fireplace has been installed with optional CVCK (Clean View Circulating Kit) to service fan system or burner system controls, the access cover and burner system pan will have to be removed. -
Page 39: Burner System Maintenance
It is recommended to turn on the unit at least once a month and inspect the flame pattern to ensure there are no problems with the burner tube. The pilot flame should also be inspected monthly to ensure proper operation. MQHBZDV3636, MQHBZDV4236, HBZDV4736 Flame should appear similar to the above picture – Solace Series MQRB4236 Flame should appear similar to the above picture... -
Page 40: Annual Inspection List For Determining Safe Operation Of A Direct Vent Gas Fireplace
Annual Inspection List for Determining Safe Operation of a Direct Vent Gas Fireplace Refer to this checklist for proper maintenance, safe use, and operation. See each section for more specific information. 1. Inspect and operate all pressure relief mechanisms (i.e., relief dampers, spring loaded door latches) installed on your appliance to verify relief mechanisms are free from obstruction to operate. -
Page 41: Conversion Kit Instructions - Part A
Conversion Kit Instructions – PART A Burner Orifice Brass Hi/Lo Kit Number Appliance Description Pilot Orifice Brass (1000-255) Nipple Shutter Regulator Propane Conversion 1001-P167SI 1001-P202SI 3632HB -CKLP MQHBZDV3636LP 1000-253closed 5/16” -Millivolt- #30 (977.167) (0.907.202) Propane Conversion 1001-P168SI 1002-P014SI 3632HB –CKLPI MQHBZDV3636LPE 1000-253closed 5/16”... - Page 42 MQHB3636/4236 / HBZDV4736 Gas Conversion –Part A WARNING: This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instruction s and all applicable codes and requirements of the authority having jurisdiction. If the information in these instructions is not followed exactly a fire, explosion or production of carbon monoxide may result causing property damage, personal injury or loss of life.
-
Page 43: Gas Conversion For Top Convertible Pilot (Series 019065X) - Part B
Gas Conversion for Top Convertible Pilot – Part B (series 0190XYZ) Instructions for converting SIT 190 series pilot burner injector from NG to PROPANE and from PROPANE to NG only. This information should be considered as supplemental to the Appliance Manufacturer's Instructions. -
Page 44: Gas Conversion For Modulator - Part C
Gas Conversion for Modulator – PART C WARNING!- WARNING!-... -
Page 45: Door And Glass Information / Appliance/Log Reference Chart/Log Placement
Door and Glass Information Removal of the Glass Door Glass Cleaning 1. Remove the door by unlatching the 2 top latches. Simply It will be necessary to clean the glass periodically. During start- place 2 fingers in the grooves, pull towards you and lift up, condensation, which is normal, forms on the inside of the upwards slightly. -
Page 46: Log Placement - Logf36
Log Placement - LOGF36 STEP 1: Place log #1 onto rear log holder and center. Parts List STEP 2: Place log #2 onto left side of log. Place log #3 STEP 3: Locate 2 holes on the bottom of logs #4 and #5. onto right side of log #1. -
Page 47: Pilot Shield Rsp1 / Rsp2
Pilot Shield RSP1 / RSP2 Qty: 1 Shield Per Kit SLOTS SLOTS Back View SLOTS SLOTS... -
Page 48: Mqrock1/Mqrsp2 Setup For Models Mqhbzdv3636/Mqhbzdv4236
MQROCK1/MQRSP2 Setup for Models MQHBZDV3636/MQHBZDV4236 PARTS LIST STEP 1: Remove the log holder mount, log supports, and STEP 2: Attach the back rock support with the 4 screws the grate bar. as shown. Replace/reinstall the 2 screws from the grate bar. - Page 49 STEP 5: Place rocks #1 onto the burner as shown. STEP 6: Place rocks #3 onto the burner as shown. STEP 7: Place rocks #4 onto the burner as shown. STEP 8: Place rocks #6 onto the burner as shown. STEP 9: Place remaining rocks #4 and #6 into position as Finished Rock F2 Setup shown.
-
Page 50: Mqrock1/Mqrsp1 Setup For Models Hbzdv4736
MQROCK1 / MQRSP1 Setup for Model HBZDV4736 PARTS LIST: Rock #1 - 5 pieces; Rock #3 – 6 pieces; Rock #4 - 10 pieces; Rock #6 - 9 pieces. STEP 2: Attach the back rock support using the existing STEP 1: Remove the back log holder, log supports, and screws from the back log holder. - Page 51 MQROCK1 / MQRSP1 Setup for Model HBZDV4736 - Continued STEP 5: Place rocks #3 into position as shown. Do not STEP 6: Place rocks #4 into position as shown. place rocks directly onto the burner tubes. STEP 8: Place remaining rocks #4 and #6 into position as STEP 7: Place rocks #6 into position as shown.
-
Page 52: Accessories Available For Skyline & Zdvrb3622 Ribbon Burner Units
Accessories for Skyline, ZDVRB3622, & ZRB46 Ribbon Burner Units ACCESSORY ITEM MQRB3632 MQRB4236 ZDVRB3622 White Glass MQG5W Yes / 5LB MAX 5LB Bag c/w Unit MQ Dealer Only Bronze Glass Yes / 5LB MAX Yes / 5LB MAX 5LB Bag c/w MQG5C Unit Cobalt Blue Glass... - Page 53 ⚠ NOTE: Glass Media must be evenly spread over the Burner and False Bottom as described on last page before Rock / Stones / and Log Accessories are placed. MQROCK2, MQROCK3, MQRBD1 - Place rocks randomly onto False Bottom. Be careful not to cover any part of the Burner Tube as sooting may occur.
-
Page 54: Ulk2 Universal Light Kit (Optional Accent Lighting Kit)
ULK2 Universal Light Kit ( Optional Accent Lighting Kit) For the Skyline Series (MQRB3328, MQRB3632, MQRB4236) and Kingsman ZDVRB3622 Please follow the current ANSI/NFPA 70 National Electrical Code in the USA and CAN/CSA C22.1 Canadian National Electrical Code in Canada. Contents of Kit: ... - Page 55 MQRB3328, ZDVRB3622, & MQRB4236 Screw Screw MQRB3632 Screw Screw STEP 3: Place Lamps in position in firebox. Attach to fireplace with a single screw at the locations shown above for each unit. Lamps can be placed facing upward or sideways. Replace burner tube and false bottom, along with pilot shield.
-
Page 56: Overview And Components
IPI Electronic Ignition System Overview CPI / IPI The IPI system is an advanced burner controller that Switch provides you with the option of having either a Standing- Cover Pilot, or an intermittent igniting system. This alternating mode is controlled by the CPI/IPI Switch (Continuous Pilot Ignition/Intermittent Pilot Ignition) located on the IPI System Box. -
Page 57: Remote Control Operation
Proflame 1 -Remote Control Operation- The Proflame GTM is configured to control the on/off main burner operation, its flame levels, and provides on/off and Smart *thermostatic control of the appliance. Transmitter Remote Receiver Transmitter Room *thermostat ( Transmitter Operation) The Transmitter is powered by 3 AAA type batteries. A Mode The Remote Control can operate as a room *thermostat. -
Page 58: Ipi Electronic Ignition Parts List - Standard System
Proflame 1 -IPI System Parts List- PART NO. DESCRIPTION 1006-P002SI Valve IPI Hi/Lo NG 11. 1002-P012SI IPI Stepper Kit - LP 907.012 1006-P003SI Valve IPI Hi/Lo LP 12. 1002-P013SI IPI Stepper Kit - NG 907.013 1002-P302SI IPI Ignition Board 13. 1002-P014SI IPI Reg Kit - LP Hi-Lo 907.014 1002-P047SI Pilot Assembly-LP -24”... -
Page 59: Configuration #1: Basic Manual Hi/Lo And Manual On/Off Capabilities
Configuration #1: Basic manual HI/LO and manual ON/OFF capabilities. -
Page 60: Configuration 2- Remote On/Off
Receiver Module .584.523/521/221 1001-P221SI Receiver Module .584.523/521/221 1001-P221SI... -
Page 61: Operating The Receiver Without Batteries For Gt / Egt / Gtm / Egtm Remote Controls
Operating the Receiver Without Batteries For GT / EGT / GTM / EGTM Remote Controls -Wiring Harness P/N 1002-P906si required for both IPI & Millivolt systems. -Millivolt Systems will also require Power Adapter P/N 1002-P850si. The Remote Receiver & IPI or Millivolt system can be powered by the AC Adapter. This is advantageous if you do not want to use batteries. -
Page 62: Configuration 3- Remote On/Off, Variable Hi/Lo, And Fan
Configuration #3: Remote ON/OFF, variable HI/LO, and fan capabilities. Refer to the fan installation/removal section for fan installation. -
Page 63: Ipi Lighting Instructions
- Lighting Instructions - Intermittent Pilot Ignition System (IPI) FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Always light the pilot whether for the first time or if the gas supply has run out with the glass door opened or removed. -
Page 64: Proflame 2 Parts List, Gtmfl System
Proflame 2 –NE2 / LPE2 -IPI System Parts List- IPI PROFLAME 2 - COMPONENT PARTS IPI - PF1 and PF2 Common Components PART NO. DESCRIPTION PART NO. DESCRIPTION 1005-P001SI Valve IPI Proflame PF2 885.001 NG - Stepper 13. 1002-P033SI TC - Pilot Burner IPI (Assembled) NG 199.033 1005-P002SI Valve IPI Proflame PF2 885.002 LP - Stepper 14. -
Page 65: Ifc Module And Remote Control
Proflame 2 IFC Module and Remote Control LCD Display ON / OFF Key Thermostat Key Batteries UP / DOWN Arrow Key Mode Key IFC Module Button Within 10 seconds press the button again until Pairing Remote Control: you hear it beep. ... -
Page 66: Cold Climates - Cpi Setting
Cold Climates – CPI Setting - Proflame 2 Remote Control Use the CPI setting during cold weather, otherwise the fireplace may have a hard time starting up and establishing a flame. The CPI (Continuous Pilot Ignition) setting will keep the firebox and fireplace exhaust vent warm during cold weather. When the firebox and exhaust vent are warm, exhaust gasses will readily flow out of the firebox. -
Page 67: Flame Control, Room Thermostat
Proflame 2 Remote Control... -
Page 68: Smart Thermostat, Fan Speed Control, Light Control
Note: When Smart Thermostat is activated, manual flame height adjustment is disabled. Note: This function is only available in Room Thermostat or Smart Thermostat Control Mode. -
Page 70: Vent Terminal Clearances
Vent Terminal Clearances NOTE: A HORIZONTAL VENT CERTIFIED GUARD (SAFETY CAGE) IS AVAILABLE WHEN REQUIRED BY LOCAL CODES. Clearances are to the edge of the terminal plate. Add 6-3/4” to clearances to arrive at centerline. Local codes or regulations may require different clearances. -
Page 71: General Vent Installation Information
General Vent Installation Information This gas appliance is approved to be vented either through Place the spring spaces provided approximately every two the side wall or vertically through the roof. Only Kingsman feet to stabilize 4” flex in the center of 7” flex. When forming Flex (Z-Flex) Venting Kits and components specifically bends place spring in bend or before and after. -
Page 72: Installation Of Side Wall Venting
Installation Of Side Wall Venting 1. Establish the minimum distance from the bottom of fireplace to centre MQHBZDV3636 of vent. Cut a hole through the wall allowing for a 11” x 11” (inside diameter) in combustible walls for wall thimble or an 8” diameter hole in a non-combustible wall (See Figure 1-2-3). -
Page 73: Venting Routes And Components / Venting Table
How To Use The Horizontal Vent Table Venting Routes And Components Since it is very important that the vent system maintain its bal- 1. Determine the height of the system and the number of bends ance between the combustion air intake and the flue gas required. -
Page 74: Horizontal Snorkel Terminations Z47St24 / Z47St36
Horizontal Snorkel Terminations Z47ST24 / Z47ST36 Two snorkel terminations are available if a vertical rise is necessary on the exterior side of a building: Z47ST24 (24” Tall, 14-1/2” Center to Center) Z47ST36 (36” Tall, 26-1/2” Center to Center) Follow standard horizontal venting installation procedures. If the Snorkel Termination is to be located below grade, a window well is recommended with adequate and proper drainage as per local codes. -
Page 75: Vertical Venting
Venting Straight Up Through Roof An Attic Insulation Shield must be installed where the vent passes from a lower living space into an attic space where the chimney is not enclosed. It is designed to keep insulation materials away from the chimney. When installing the Attic Insulation Shield where the chimney passes from a living space to an attic space, install the shield from below and nail in place using 1"... - Page 76 -Restrictor- Remove for Runs Under 15 Feet Clearances in horizontal venting. FDVVT40 Clearance to perpendicular wall 24 inches (60 cm). (Recommended to prevent re- circulation of exhaust products. For additional requirements check local codes.) 24” 18” MIN Clearance above highest point of exit on roof 18 inches (45cm) 43ft...
-
Page 77: Glass Safety / Termination Cap Safety- All Units
-Glass Safety- All Units IT IS THE RESPONSIBILITY OF THE HOME OWNER TO ENSURE THAT NO ONE TOUCHES A HOT APPLIANCE. If the barrier becomes damaged, the barrier shall be replaced with the manufacturer’s barrier for this appliance. Any safety screen, guard, or barrier removed for servicing the appliance, must be replaced prior to operating the appliance. -
Page 78: Approved For Power Vent Pvh58
Approved for Power Vent PVH58 / PVH58FM - This appliance is approved for use with a Kingsman PVH58 Horizontal Power Vent - A Horizontal Power Vent Termination is intended for use where standard venting configurations are not possible. NOTE: MODELS EQUIPPPED WITH MILLIVOLT/ STANDING PILOT IGNITION: Downward vertical vent runs are NOT permitted. - Page 79 POWER VENT PARTS LIST – 4/7 VENTING NUMBER DESCRIPTION PVH58 Horizontal Power Vent Starter Kit ‐ Exterior Mount PVH58FM Horizontal Power Vent Kit ‐ Flush Mount Note: Must use a one foot section of 5/8 DV hard pipe to connect to the Power Vent Termination (not supplied) CHOOSE CONTROL MODULE OR HARNESS DEPENDENT ON VALVE SYSTEM PVC58MV Power Vent Control Module ‐...
- Page 80 POWER VENT ACCESSORIES ZDV4FC Flex Connector 4” Diameter ZDV7FC Flex Connector 7” Diameter ZDV4FCL Flex Clamp 4" ZDV7FCL Flex Clamp 7" ZDV4SS Spring 4" Standoff Spacer PVH58WT Wall Thimble for Power Vent...
-
Page 81: Limited Lifetime Warranty
This Limited Lifetime Warranty applies only while the unit remains at the site of the original installation and only if the unit is installed inside the continental United States, Alaska, Hawaii, and Canada. The warranty applies only if the unit is installed and operated in accordance with the printed instructions and in compliance with applicable installation and building codes and good trade practices.
