Installation Instructions
Model Number VRB46
Zero Clearance Vented Gas Fireplace Heater
Stock #'s: VRB46N, VRB46NE, VRB46LP, VRB46LPE
Conforms to: ANSI Z21.88-2016 • CSA 2.33-2016
VENTED GAS FIREPLACE HEATER
This appliance may be installed in an
aftermarket permanently located,
manufactured home (USA only) or mobile
home, where not prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
This Appliance Is Only Approved With
Kingsman Flex Vent System, Except When
Using The Power Venting Option.
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for future
reference.
A Division of R-Co. Inc.
2340 Logan Avenue
Winnipeg, Manitoba, Canada R2R 2V3
Ph: (204) 632-1962
Printed in Canada September 6, 2017 Part # 46VRB-MAN16
Advertisement
Table of Contents
Related Manuals for Kingsman Fireplaces VRB46
Summary of Contents for Kingsman Fireplaces VRB46
- Page 1 Installation Instructions Model Number VRB46 Zero Clearance Vented Gas Fireplace Heater Stock #’s: VRB46N, VRB46NE, VRB46LP, VRB46LPE Conforms to: ANSI Z21.88-2016 • CSA 2.33-2016 VENTED GAS FIREPLACE HEATER This appliance may be installed in an aftermarket permanently located, manufactured home (USA only) or mobile home, where not prohibited by local codes.
-
Page 2: Table Of Contents
Mobile Home/Manufactured Housing Installation……………………..........INSTALLATION Framing Your Gas Fireplace......................Nailing Tab Guide..........................VRB46 -Facing Requirements- ALL UNITS- Chase Not Vented or Vented Chase......Facing Kit for VRB46- Z46PRO4..................... Locating your Appliance........................Fireplace Dimensions........................Unvented Chase VS Vented Chase- Choose Your Installation............ - Page 3 Burner System Removal/Installation Guide..................LOGS AND MEDIA ULK2 Universal Light Kit (Optional Accent Lighting Kit)..............44-45 RBCB1 -Cannonballs- Installation Instructions................MQ Dealer Accessories for VRB46....................47-48 MQRBD3 5 Piece Driftwood Log Set……………………………………………………………………. IPI ELECTRONIC IGNITION SYSTEM IPI Electronic Ignition System......................
-
Page 4: Pre-Installation Questions And Answers
Pre-installation Questions and Answers About curing of the paint Your stove or fireplace has been painted with the highest quality silicone stove paint. This paint dries quickly in 15-20 minutes when first applied at the factory. However, due to the high temperature silicone components, the paint will cure when heat is applied to the appliance as it is first used. -
Page 5: Warnings, Installations And Operations
Warnings, Installations and Operations Installation Regulations This gas appliance must be installed by a qualified installer in accordance with local building codes, or in the absence of local codes, with the current CAN/CSA-B149.1 or .2 Installation Code (in Canada) or the current National Fuel Gas Code Z223.1- NFPA 54 when installed in the United States. This appliance, when installed, must be electrically connected and grounded in accordance with local codes, or in the absence of local codes, with the current CSA C22.1 Canadian Electrical Code or with the National Electrical Code;... - Page 6 Gas fired appliances may be used only for supplemental heat and/or decorative purposes and under no circumstances shall they provide a primary heat source. This appliance must not be connected to a chimney flue serving a separate solid-fuel burning appliance. NOTE: It is recommended that a Carbon Monoxide (CO) Detector be installed in or near bedrooms and on all levels of your home.
-
Page 7: Mobile Home/Manufactured Housing Installation
Mobile Home/Manufactured Housing Installation This Direct Vent System Appliance must be installed in accordance with the manufacturer’s installation instructions and the Manufactured Home Construction and Safety Standard Title 24 CFR, Part 3280, or the current Standard for Fire Safety Criteria for Manufactured Home Installations, Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240 MH Mobile Home Standard in Canada. -
Page 8: Framing Your Gas Fireplace
VRB46 Framing Your Gas Fireplace This section is intended for qualified installers only. Before beginning, make note of where the gas and electrical accesses are located on the unit. This will streamline the construction process. Furthermore, familiarize yourself with the venting and clearance requirements (see Venting section) for this appliance. -
Page 9: Nailing Tab Guide
VRB46 Nailing Tab Guide [Qty]2 Nailing Tabs are located on each side of the fireplace front frame. These Nailing Tabs can be used in two ways: 1/2” Drywall Flush with Face of Fireplace –Fireplace and Framing Flush with Face of Fireplace... -
Page 10: Vrb46 -Facing Requirements- All Units- Chase Not Vented Or Vented Chase
VRB46 -Facing Requirements- ALL UNITS- Chase Not Vented or Vented Chase- drywall screws to pop or pull due to wood studs NOTE: ANY MATERIALS COVERING THE FACE OF drying out. THE FIREPLACE BESIDE AND ABOVE THE FIREPLACE OPENING MUST BE NON- ... -
Page 11: Facing Kit For Vrb46- Z46Pro4
VRB46 -Facing Kit for VRB46- Z46PRO4 This kit is recommended for Clean View Facing of the VRB46. Promat precut boards can be installed with standard drywall screws (pre-drilling into fireplace face required) or self-drilling drywall screws. It may be desirable to countersink the screw holes for easier finishing later. -
Page 12: Locating Your Appliance
VRB46 Locating Your Appliance LOCATION KEY: Flat on Wall Across the Corner As an Island As a Room Divider Flat on Wall Corner Exterior Wall See Mantel Leg Clearances Instruction for the proper placement of fireplace. Island installation with a top vent is... -
Page 13: Unvented Chase Vs Vented Chase- Choose Your Installation
VRB46 –Unvented Chase VS Vented Chase- Choose Your Installation Look at the following chart before you begin the installation. Cool Touch TV above Fireplace with Mantel Height Heat can be Enclosure Wall Recessed Installation directed to option second room UNVENTED CHASE 64”... -
Page 14: Framing Dimensions -Chase Not Vented- Ventilation Plates In Place -As Shipped
VRB46- Framing Dimensions -Chase Not Vented- Ventilation Plates In Place- -As Shipped Determine whether face of fireplace will be: flush with finished wall (e.g., for surround, cultured stone or other non combustible covering). flush with framing (to be covered with concrete board for a Flat Wall appearance). -
Page 15: Mantel Clearances -Chase Not Vented- Ventilation Plates In Place -As Shipped
VRB46 -Mantel Clearances –Chase Not Vented- Ventilation Plates In Place -As Shipped Before installing any mantels it is important to determine the combustibility of its material(s). There are two types of mantels to consider: Combustible and Non-Combustible. A Combustible Mantel is one that... -
Page 16: Clearance To Combustibles -Chase Not Vented-Ventilation Plates In Place -As Shipped
VRB46 -Clearance to Combustibles –Chase Not Vented- Ventilation Plates in Place -As Shipped Clearance to Combustibles VRB46 –Chase Not Vented- Front 36” [92cm] Back (from Stand-offs) 0” [0cm] Side (from Stand-offs) 0” [0cm] Floor* 0” [0cm] Minimum Ceiling Height (from bottom of fireplace) 64”... -
Page 17: Vented Chase -Removal Of Ventilation Plates- See Framing For Vented Chase
VRB46 -Vented Chase –Removal of Ventilation Plates- See Framing for Vented Chase ⚠ CAUTION: Ventilation Plates must be removed before VRB46 is installed into a Vented Chase. STEP 1: Remove [Qty 2] Knockouts from Outer Heat Shield. STEP 2: Remove [Qty 2] Ventilation Plates. -
Page 18: Vented Chase - Style 1 - Opening With No Grill
VRB46 – Vented Chase – Style 1 – OPENING WITH NO GRILL ⚠ NOTE: ENCLOSURE MUST BE SEALED VENTILATION PLATES MUST BE REMOVED. Air heated by circulation over the heating surfaces of Minimum Enclosure Height is 70” from the bottom of the appliance must not be discharged directly into the the appliance. - Page 19 VRB46 –Vented Chase- Style 1 – OPENING WITH NO GRILL VENTILATION PLATES MUST BE REMOVED Ceiling / Enclosure Top Open Area Open Area 47” FRAMING I.D. Finished Minimum Opening is 105 square inches of free air. Finished Openings must be at ceiling level.
-
Page 20: Vented Chase - Style 2 - Opening With Grill
VRB46 – Vented Chase – Style 2 – OPENING WITH GRILL ⚠ NOTE: ENCLOSURE MUST BE SEALED VENTILATION PLATES MUST BE REMOVED. Air heated by circulation over the heating surfaces of Grill openings must be within 2” of enclosure top. - Page 21 VRB46 – Vented Chase – Style 2 – OPENING WITH GRILL VENTILATION PLATES MUST BE REMOVED Grill Opening must be within 2” of Enclosure Top FRAMING TO CEILING - MINIMUM ENCLOSURE- FRAMING TO CEILING- SIDE GRILLS MINIMUM ENCLOSURE- Grills must have a total of...
-
Page 22: Vented Chase -Style 2 - Opening With Grill - Kingsman V46Eg
VRB46 –Vented Chase -Style 2 – OPENING WITH GRILL - Kingsman V46EG VENTILATION PLATES MUST BE REMOVED. Ceiling Height is Variable Maximum Distance from the Required Top Enclosure to Variable Enclosure Top Grill Opening is 2" Grill Opening Optional Recess Variable 47”... -
Page 23: V46Eg Grill Installation
VRB46 V46EG Grill Installation Parts List: [1] Louver Grill (ready to paint) This Kit comes with two installation options: Outer Trim Grill Mount - For a Quick and simple installation. [1] Outer Trim Grill Mount (ready to paint) Hidden Grill Mount - For a very clean installation with only the [1] Upper Frame for Hidden Grill Mount grill visible in the finished opening. -
Page 24: Framing Dimensions -Vented Chase -Ventilation Plates Removed
VRB46 -Framing Dimensions –Vented Chase -Ventilation Plates Removed Determine whether face of fireplace will be: flush with finished wall (e.g., for surround, cultured stone or other non combustible covering). flush with framing (to be covered with concrete board for a Flat Wall appearance). -
Page 25: Mantel Clearances -Vented Chase -Ventilation Plates Removed
VRB46 -Mantel Clearances –Vented Chase -Ventilation Plates Removed Before installing any mantels it is important to determine the Sealed Enclosure combustibility of its material(s). There are two types of mantels to consider: Combustible and Non-Combustible. A Combustible Mantel is one that... -
Page 26: Clearance To Combustibles -Vented Chase -Ventilation Plates Removed
VRB46 -Clearance to Combustibles –Vented Chase -Ventilation Plates Removed- Clearance to Combustibles VRB46 Vented Chase Front 36” [92cm] Back (from Stand-offs) 0” [0cm] Side (from Stand-offs) 0” [0cm] Floor 0” [0cm] Minimum Ceiling Height (from bottom of fireplace) 70” [179cm] Top (from Stand-offs) 0”... -
Page 27: Surround Dimensions
VRB46 Surround Dimensions Surround Frame Z46S1 Surround Frame Z46S2 • The Surround Frames are 1” thick, with a 3/4” space behind the frame. • When using Surrounds, Maximum Thickness for Non-Combustible Facing Materials is 3/4”. The Fireplace may be covered up to within 1/8” of the Fireplace Opening with non-combustible materials. -
Page 28: Surround Installation
VRB46 Surround Installation Each kit contains: Small Surrounds: (Qty-1) Surround Frame (44-5/8”W x 17-7/8”) (Qty-2) Surround Side Fillers ZRB46S1BL (Qty-1) Surround Access Cover – SS Only ZRB46S1SS (Qty-8) #6 Self Tapping Screws Large Surrounds: Surround Frame (50-1/2”W x 22-1/2”) ZRB46S2BL... -
Page 29: Uhs Box
VRB46 51UHS Box Included with base model. The 51-UHS is designed for millivolt and IPI units for in-unit installation of the Remote Receiver, Fan Control Module, and the IPI Module. NOTE: When using a remote control, the 51-UHS must be used. -
Page 30: Fan Kit Installation
VRB46 Z46FK Fan Kit Installation Fan Kit should be installed before facing material is applied or surround is installed. To remove fan for service, the burner pan must be removed and work done through the opening (See Burner System Removal section). -
Page 31: Split Receptacle- Fan Speed Control Outside Of Fireplace
Split Receptacle- Fan Speed Control Outside of Fireplace If you plan to locate the variable speed control switch for the fan outside of the fireplace and you require a constant source of AC power inside the unit for another accessory such as lights or an IPI valve system, follow one of the procedures below. -
Page 32: Door And Glass Information
Top Latch assembly to the door. cleansers and warm water. After that, the glass should be cleaned two or three times a season depending on the circum- Spring Replacement: VRB46 stances. *Over time, spring may need to be replaced if tension is lost. -
Page 33: Valve Access Cover Removal
VRB46 Valve Access Cover Removal Remove Valve Access Cover in order to access igniter and valve controls. To remove Valve Access Cover, simply insert fingers into holes in Access Panel and lift out. When replacing Access Panel, engage Tabs into Slots in Bracket. -
Page 34: Porcelain Liner Installation Guide
ZRB46PL Liner Installation Warning: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. ZRB46PRL consists of: [1] – Back Liner [1] –... -
Page 35: Child Safety Screen
ZRB46CSS Child Safety Screen 46ZRBCSS Contents of Kit: [1] Child Safety Screen [2] Screen Mount Brackets [6] 3/8” x 1/2” Screws Assembly Instructions: Fasten Screen Mount Brackets to Child Safety Screen with supplied screws. ⚠ WARNING: Wait until unit is COMPLETELY cool before touching glass or attempting to install or remove Child Safety Screen. -
Page 36: Gas Line Installation
Gas Line Installation This gas appliance should be installed by a qualified installer in accordance with local building codes and with current CAN/CGA - B149.1 or .2 installation codes for Gas Burning appliances and equipment in Canada and the National Fuel Gas Code ANSI Z223 in the U.S.A. -
Page 37: Millivolt System, Lighting, & Burner Control
Millivolt System, Lighting, and Burner Control FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. BEFORE LIGHTING Immediately call your gas supplier from a neighbour’s phone. Follow the This appliance has a pilot which must be lighted by hand. -
Page 38: Troubleshooting The Gas Control System
Troubleshooting the Gas Control System WARNING BEFORE DOING ANY GAS CONTROL SERVICE WORK, REMOVE THE GLASS FRONT. Before troubleshooting the gas control system, be sure external gas shut off is in the "On" position. Problem Possible Causes Corrective Action Spark igniter will not light. Defective or misaligned Check for spark at electrode and pilot: if no spark and electrode wire is electrode at pilot. -
Page 39: Burner System Maintenance
Burner System Maintenance VRB46 It is recommended to annually inspect and clean the Burner System to prevent malfunction and / or sooting. This operation should be performed by your dealer or a qualified technician. -CAUTION- Before servicing the burner system ensure that the gas supply is turned OFF and disconnect all electrical connections to the appliance. -
Page 40: Gas Conversion Part A
Gas Conversion Part A VRB46 Models: VRB46LP, VRB46N, VRB46LPE, VRB46NE Kit Number Description Pilot Orifice Burner Orifice Brass Nipple Air Shutter Hi/Lo Regulator Brass (1000-255) 46ZRB-CKLP LP Conversion 1001-P167SI 1000-P201VE 5/16” 1001-P202SI #30 (977.167) -Millivolt- (0.907.202) 46ZRB-CKNG NG Conversion 1001-P165SI... -
Page 41: Gas Conversion Kit For Top Convertible Pilot Part B
Gas Conversion for Top Convertible Pilot – Part B (series 0190XYZ) Instructions for converting SIT 190 series pilot burner injector from NG to LPG and from LPG to NG only. This information should be considered as supplemental to the Appliance Manufacturer's Instructions. WARNING! The installation of this conversion kit must only be undertaken by a qualified and certified gas appliance installer. -
Page 42: Gas Conversion For Modulator - Part C
Gas Conversion for Modulator – PART C... -
Page 43: Burner Tube Removal
VRB46 Burner Tube Removal Remove the six [6] DT screws from the lower portion of the Burner Tube Mount Brackets. Slide the Burner Tube away from the Plumbing Connection until it disengages from the orifice. Reverse these steps to reinstall. -
Page 44: Ulk2 Universal Light Kit (Optional Accent Lighting Kit)
ULK2 Universal Light Kit ( Optional Accent Lighting Kit) Please follow the current ANSI/NFPA 70 National Electrical Code in the USA and CAN/CSA C22.1 Canadian National Electrical Code in Canada. Contents of Kit: [2] 12V Halogen Lamps Lamp Plate with Insulated Studs & wiring ... - Page 45 MQRB3328, ZDVRB3622, & MQRB4236, ZRB46, VRB46 Screw Screw STEP 3: Place Lamps in position in firebox. Attach to fireplace with a single screw at the locations shown above for each unit. Lamps can be placed facing upward or sideways. Replace burner tube and false bottom, along with pilot shield.
-
Page 46: Rbcb1 -Cannonballs- Installation Instructions
RBCB1 -Cannonballs- Installation Instructions Assorted size and colors. Place randomly as desired inside fireplace. Can be used with MQ Glass, MQ Rock, MQ Stone or MQ Ember. Follow instructions for these accessories. NOTE Pilot Area Must Not Be Covered, as delayed ignition can occur. ... -
Page 47: Mq Dealer Accessories For Vrb46
MQ Dealer Accessories for VRB46 The following Accessories are available through MQ Dealers only. GLASS (MQG5W, MQG5C, MQG5A, MQG5B) ACCESSORY ITEM DESCRIPTION If you wish to use this media evenly spread the glass embers onto the false bottom and burner. Ensure the glass embers do not excessively MQG5W Decorative Glass 1/2”... - Page 48 MQROCK2, MQROCK3, MQRBD1 - Place rocks randomly onto False Bottom. MQRock2 MQRock3 MQRBD1 NOTE Pilot Area Must Not Be Covered, as delayed ignition can occur. Do Not Cover any part of the burner tube with logs as sooting may occur. ...
-
Page 49: Mqrbd3 5 Piece Driftwood Log Set
MQRBD3 -5 Piece Driftwood Log Set- Can be used with MQ Glass, MQ Rock, MQ Stone or MQ Ember. Follow instructions for these accessories. Place logs along front and back side of burner tube as shown. ⚠ NOTE LOG 4 ... -
Page 50: Ipi Electronic Ignition System
IPI Electronic Ignition System Overview Cover The IPI system is an advanced burner controller that provides you with the option of having either a Standing- Pilot, or an intermittent igniting system. This alternating Backup mode is controlled by the CPI/IPI Switch (Continuous Pilot Battery Ignition/Intermittent Pilot Ignition) located on the IPI System Pack... -
Page 51: Remote Control Operation
-Remote Control Operation- The Proflame GTM is configured to control the on/off main burner operation, its flame levels, and provides on/off and Smart thermostatic control of the appliance. Transmitter Remote Receiver Transmitter Room Thermostat ( Transmitter Operation) The Transmitter is powered by 3 AAA type batteries. A Mode The Remote Control can operate as a room thermostat. -
Page 52: Ipi Electronic Ignition Parts List - Standard System
IPI Electronic Ignition Parts List – Standard System ITEM NO. PART NO. DESCRIPTION 1006-P002si Valve IPI Hi/Lo NG 1006-P003si Valve IPI Hi/Lo LP *1002-P047si Pilot Assembly-LP -24” Wire *1002-P033si Pilot Assembly-NG -24” Wire 1002-P017si Spark Electrode (with wire) *1002-P119si Spark Electrode (with wire- 35” Length) 1002-P903si Electrode Flame Sensor *1002-P910si... -
Page 53: Configuration #1: Basic System
Configuration #1: Basic manual HI/LO and manual ON/OFF capabilities. -
Page 54: Configuration #2: Remote On/Off
Receiver Module .584.523/521/221 1001-P221SI Receiver Module .584.523/521/221 1001-P221SI... -
Page 55: Egtm / Gtm System -No Batteries
Operating the Receiver Without Batteries For GT / EGT / GTM / EGTM Remote Controls -Wiring Harness P/N 1002-P906si required for both IPI & Millivolt systems. -Millivolt Systems will also require Power Adapter P/N 1002-P850si. The Remote Receiver & IPI or Millivolt system can be powered by the AC Adapter. This is advantageous if you do not want to use batteries. -
Page 56: Configuration #3: Remote On/Off, Variable Hi/Lo, And Fan
Configuration #3: Remote ON/OFF, variable HI/LO, and fan capabilities. Refer to the fan installation/removal section for fan installation. -
Page 57: Ipi Lighting Instructions
Electronic Ignition Lighting Instructions If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Always light the pilot whether for the first time or if the gas supply has ran out with the glass door opened or removed. FOR YOUR SAFETY READ BEFORE LIGHTING: A. -
Page 58: Vent Termination
Vent Termination WARNING: A HORIZONTAL VENT CERTIFIED GUARD (SAFETY CAGE) IS AVAILABLE WHEN REQUIRED BY LOCAL Measure to the edge of the termination plate. CODES. Measure to the edge of the round termination. Vent Terminal Area Where Terminal Not Permitted. Air Supply Clearance above grade, veranda, porch, deck, or balcony 12 M. -
Page 59: General Vent Installation Information
General Vent Installation This gas appliance is approved to be vented either through the side wall or vertically through the roof. Only Kingsman Flex (Z-Flex) Venting Kits and components specifically approved and LABELED for this fireplace may be used. ⚠ WARNING: DO NOT mix parts from different systems unless stated in the manual. -
Page 60: Venting Table
Venting Routes And Components Venting Routes And Components Since it is very important that the vent system maintain its How To Use The Horizontal Vent Table balance between the combustion air intake and the flue gas 1. Determine the height of the system and the number of exhaust, certain limitations as to vent configurations apply and bends required. -
Page 61: Horizontal Snorkel Terminations
RB46 Horizontal Snorkel Terminations Z47ST24 / Z47ST36 Two snorkel terminations are available if a vertical rise is necessary on the exterior side of a building: Z47ST24 (24” Tall, 14-1/2” Center to Center) Z47ST36 (36” Tall, 26-1/2” Center to Center) Follow standard horizontal venting installation procedures. If the Snorkel Termination is to be located below grade, a window well is recommended with adequate and proper drainage as per local codes. -
Page 62: Vertical Venting
Venting Straight Up Through Roof An Attic Insulation Shield must be installed where the vent passes from a lower living space into an attic space where the chimney is not enclosed. It is designed to keep insulation materials away from the chimney. When installing the Attic Insulation Shield where the chimney passes from a living space to an attic space, install the shield from below and nail in place using 1"... - Page 63 -Restrictor- Remove for Runs Under 15 Feet Z47VT Clearances in horizontal venting. 43ft Straight-through roof support configuration; b) Flex bend configuration; c) Termination mounting...
-
Page 64: Glass Safety / Termination Cap Safety -All Units
-Glass Safety- All Units IT IS THE RESPONSIBILITY OF THE HOME OWNER TO ENSURE THAT NO ONE TOUCHES A HOT APPLIANCE. If the barrier becomes damaged, the barrier shall be replaced with the manufacturer’s barrier for this appliance. Any safety screen, guard, or barrier removed for servicing the appliance, must be replaced prior to operating the appliance. -
Page 65: Approved For Power Vent Pvh58
MDV31, MDV39, MQRB3632, ZDV3622, MQZDV3622, ZDVRB3622, HBZDV3624, HBZDV3628, HBZDV3632, MQHBZDV3636, HBZDV4224, HBZDV4228, HBZDV4232, MQHBZDV4236, HBZDV4740, MQHBZDV4736, MQRB4436, MQRB5143, MQRB6961, ZRB46, ZCV3622, ZCVRB3622, ZCV39, ZCV42, MCVP42, MCVST42, MQZDV3927*, MQZDV4634*, MQZCV48, VRB46 *NOTE: For MQZDV3927 and MQZDV4634, Power Vent Control Module (PVCM) must be placed outside of Fireplace. -
Page 66: Pvh58 Parts List
PVH58 Power Vent Parts List NOTE: THE HARD PIPE VENTING AND ADAPTERS IN THIS SECTION ARE TO BE USED IN CONJUNCTION WITH A PVH58 POWER VENT ONLY FOR THE VRB46 PART NUMBER DESCRIPTION PVH58 HORIZONTAL POWER VENT TERMINATION Listed for Canada and USA CHOOSE TYPE OF VENTING FOR POWER VENT: OPTION 1 HARD PIPE OR OPTION 2 FLEX PIPE: OPTION 1: Hard Pipe Used for entire installation (Duravent-DirectVent Pro, etc.) at the fireplace:... -
Page 67: Parts Lists
Surround Trim Kit 1001-P633SI Valve Nova LP Hi/Lo 0820651 (50-1/2”W x 22-1/2”) Stainless Steel 1001-P634SI Valve Nova NG Hi/Lo 0820652 VRB46 OPTIONS – MQ DEALER ONLY - 1001-P713SI Pilot Burner LP 199.713 TC SIT RBCB1 Cannonballs- Assorted size and colors 1001-P714SI Pilot Burner NG 199.714 TC SIT... - Page 68 Pilot Assembly (NG) Safety Cage for Horizontal Snorkel 1002-P033si* Z57STSC *Longer (35 “) Must be used when Termination purchasing complete Pilot Safety Cage for Horizontal Termination FDVHSCU Spark Electrode (35”) 1002-P119si Attic Insulation Shield ZDVAIS Electrode Flame Sensor (35”) 1002-P910si Attic Insulation Shield 24”...
-
Page 69: Limited Lifetime Warranty
This Limited Lifetime Warranty applies only while the unit remains at the site of the original installation and only if the unit is installed inside the continental United States, Alaska, Hawaii, and Canada. The warranty applies only if the unit is installed and operated in accordance with the printed instructions and in compliance with applicable installation and building codes and good trade practices.
