TYPICAL APPLICATIONS
REGULATED
REGULATED
Two LTM8026s Running from 12V and 24V. At Max Load, Each LTM8026
Draws Less Than 750mA from Their Respective Input Sources
V
<750mA
IN1
324k
24V
10µF
V
<750mA
IN1
12V
10µF
Input Current vs Output Current
700
24V INPUT CURRENT
12V INPUT CURRENT
600
TOTAL INPUT POWER
500
400
300
200
100
0
0 2
OUTPUT CURRENT (A)
For more information
LTM8026
V V
IN OUT
RUN
SS V
REF
SYNC CTL_I
COMP CTL_T
RT GND ADJ
66.5k
90.9k 4.53k 140k
LTM8026
V V
IN OUT
RUN
SS V
REF
SYNC CTL_I
COMP CTL_T
RT GND ADJ
132k
90.9k 88.7k
25
20
15
10
5
0
4 6 8
8026 TA07b
www.linear.com/LTM8026
LTM8026
V
OUT
2.5V
8A
100µF
100µF
+
330µF
8026 TA07
8026fd
