LTM8026
TYPICAL APPLICATIONS
Two LTM8026s Operating in Parallel to Produce 2.5V
V
IN
6V TO 36V
10µF
22
LTM8026
V
V
IN
OUT
324k
RUN
SS
V
REF
SYNC
CTL_T
COMP
CTL_I
RT
GND
ADJ
75k
LTM8026
V
V
IN
OUT
RUN
SS
V
REF
SYNC
CTL_T
COMP
CTL_I
0.1µF
RT
GND ADJ
75k
For more information
at 10A, Equally Sharing Current
OUT
V
OUT
2.5V
10A
100µF
4.02k
100µF
+
330µF
www.linear.com/LTM8026
470pF
680k
V
V
OUT
REF
0.47µF
150k
100k
V
OUT
LTC6255
100k
100k
8026 TA09
8026fd
