COMPONENTS IN THIS KIT ARE NOT COMPATIBLE WITH ANY ROLL-UP SIDE THAT INCLUDES THE
115287 CURTAIN STABILIZER BAR. SEE PAGE 3 FOR DETAILS.
©2020
All Rights Reserved. Reproduction
is prohibited without permission.
Revision date: 12.16.20
AUTOMATED ROLL-UP SIDES
(INCLUDES COMPONENTS TO AUTOMATE TWO EXISTING MANUAL ROLL-UP SIDES)
ATTENTION: Components in this kit replace some roll-up
side panel components included with the original manual
roll-up panels. Other original roll-up parts are required to
install these automated roll-up side panel components.
SKU#
117149
1
Advertisement
Related Manuals for GrowSpan 117149
Summary of Contents for GrowSpan 117149
- Page 1 COMPONENTS IN THIS KIT ARE NOT COMPATIBLE WITH ANY ROLL-UP SIDE THAT INCLUDES THE 115287 CURTAIN STABILIZER BAR. SEE PAGE 3 FOR DETAILS. ©2020 All Rights Reserved. Reproduction is prohibited without permission. SKU# 117149 Revision date: 12.16.20...
- Page 2 Important Information BEFORE YOU BEGIN Thank you for purchasing this automated roll-up side kit for high tunnels. When properly installed and maintained, the components in this kit will provide years of reliable service. If you have any questions during the assembly, contact Customer Service at 1.800.245.9881 for assistance. SAFETY PRECAUTIONS ASSEMBLY PROCEDURE Steps outlining assembly are as follows:...
- Page 3 Important Information PICTORIAL PARTS GUIDE The following photos help identify different parts included with this kit. ATTENTION: Components in this kit replace some manual roll-up side panel components included with the original manual roll-up panels. Other original roll-up parts are required to install the automated roll-up kit components. These items include: roll-up side panel, roll-up panel conduit, threaded rod and related nuts and washers, fabric clips, and Tek screws.
- Page 4 Remove Some Manual Roll-Up Panel Components ATTENTION: If the manual roll-up side components (gearbox, roller bearings, aluminum track, etc.) included with the building are not installed, skip this page and continue with the next page to install the automated roll-up side components included with this kit. In addition to smaller items not shown, these items (included with the original manual roll-up panel) are not used when the automated roll-up side panel components are installed:...
- Page 5 Attach Guide Pipe to Existing Threaded Rod Gather parts: Threaded rod and hardware • 12' Guide Pipe (131S147) included with the original roll-up panel components. These are not included with this kit. ATTACH GUIDE PIPE ATTENTION: Asthetics, available power supply, and other factors may help determine where best to position the new motor.
- Page 6 Attach Motor Bracket to Motor ATTACH MOTOR BRACKET TO MOTOR Complete these steps: 1. Take the motor (116018D) and motor bracket (116019) and place on a work bench or flat surface. 2. Using the fasteners included with the bracket, attach the bracket to the motor as shown.
- Page 7 Attach Motor Adapter to Roll-Up Conduit Gather parts: Roll-Up Conduit with • 12" Extension Pipe for Roll-Up Conduit (131S012). Use depends on setup; Adapter Mounting Hole pipe may not be needed. ATTACH MOTOR ADAPTER TO ROLL-UP CONDUIT ATTENTION: If the roll-up conduit is not attached to the roll-up side panel, return to the roll-up panel assembly section of the main building instructions and complete the steps to install the side panel and attach the roll-up conduit to the side panel.
- Page 8 Attach Motor to Adapter Gather parts: • Shear Pin Bushing (117058) • 1-1/2" Hex Drive Screw (117109) • Nylock Hex Locknut (117095) ATTACH MOTOR TO ADAPTER Complete these steps: 1. Insert the shear pin bushing into the mounting hole of the motor output shaft and hold in place.
- Page 9 Install Guide Post Stop Bolt INSTALL GUIDE POST STOP BOLT Gather parts: The guide post stop bolt prevents the motor and trolly bracket assembly from sliding off the bottom of the guide post • (2) FAG334B Bolts (5/16" x 2") when side panel is closed.
- Page 10 Install Low Voltage Motor Controller The 116637 controller in conjunction with the drive motor limit switches allow complete control of the roll-up panels. Consult the documentation included with the controller and motors for important wiring details as well as setup instructions. Follow all wiring instructions and diagrams relevant to your specific needs.
- Page 11 Additional Automated Roll-Up Side Photos Revision date: 12.16.20 Automated Roll-Up Sides...
