COMPX Pearl KEYPAD Installation Instructions Manual page 12

KEYPAD version
Pearl
– installation instructions
Electronic push button cabinet lock
Template for Surface Mounting
This template is for surface mounting.
For flush mounting, please see Pearl
mounting sheet online at:
http://compx.com/downloads
WARNING:
page and measure the line
above. It is ONE INCH
LONG. If it measures less
than or more than one inch,
the template measurements
also need to be scaled
accordingly.
FAILURE TO DO SO
COULD RESULT IN
MISDRILLED HOLES.
Copyright 2021 © CompX Security Products / 847.752.2600 / compxpearl.com / 715 Center St., Grayslake, IL 60030
Any companies and/or products referred to herein are marks or registered trademarks of their respective companies, owners and/or mark holders.
12
1"
Print this
Pearl — Installation instructions: KEYPAD version
Part #: 334363000000
