34
[Color Adjustment]
•
[OLED Light]: Adjusts the brightness of the screen by adjusting the brightness of the OLED panel.
•
[Brightness]: Adjusts the overall brightness of the screen. The closer the value to 100, the brighter the screen.
•
[Contrast]: Adjusts the difference between the screen's light and dark areas. The closer the value to 100, the greater
the difference.
•
[Chroma]: Softens or deepens the Colors on the screen. The closer the value to 100, the deeper the Color.
•
[Sharpness]: Adjusts the sharpness of the edges of objects. The closer the value to 50, the clearer and sharper the
edges.
•
[Tint]: Adjusts the balance between the levels of red and green Colors displayed on the screen. The closer to +50, the
deeper the red, and the closer to -50, the deeper the green.
•
[White Balance Control]: The function to adjust white balance.
- [Color Temp]: The higher the Color temperature, the cooler the Color. The lower the Color temperature, the warmer
the Color.
- [VAR Temp]: Adjusts the Color temperature to the desired level. Enable this function by setting the [Color Temp]
option to [VAR Temp].
- [Method]: This method is for fine-tuning the color temperature setting, and for select the levels to adjust the color
temperature. If [Method] is set to 2 Points, you can control Gain, Offset. If [Method] is set to 10,22 Points IRE, you
can control white balance at each point of 10, 22 levels of the video.
- Depending upon the selected [Method], the available options may differ. [Signal Level(%)], [Target Luminance],
[Adjust Luminance], [Red/Green/Blue] will be shown, if [Method] is set to 10,22 Points.
- [Signal Level(%)]: Select screen brightness for color temperature adjustment.
- [Target Luminance]: Adjust the luminance to the highest IRE (100 Points).
- [Adjust Luminance]: You can adjust brightness of the selected signal level.
