- Page 1 OWNER’S MANUAL LG UltraFine™ Display OLED Pro (Professional Video Display) Please read this manual carefully before operating your set and retain it for future reference. 65EP5G www.lg.com Copyright © 2021 LG Electronics Inc. All Rights Reserved. (2210-REV01)
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY PRECAUTION ....3 MENU ........25 - Precautions for the AC Adapter and Power .. 4 USER SETTINGS ...... 33 - Precautions for Moving the Product ....6 - Precautions for Installing the Product ..... 7 - Picture ................34 - Precautions for Cleaning the Product ..... -
Page 3: Safety Precaution
WARNING - This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio interference. SAFETY PRECAUTION The safety precautions are intended to prevent unexpected danger or harm by helping the user to use the product safely and for its intended purpose. -
Page 4: Precautions For The Ac Adapter And Power
• Use only the power cord or AC adapter provided or approved by LG Electronics, Inc. If you use another power cord, make sure that it is certified by the national standards. If the power cable is faulty in any way, please contact the manufacturer or the nearest authorised service centre for a replacement. - Page 5 • If water or any foreign substance goes inside the product, disconnect the power cord immediately and contact the service centre. - Otherwise, this may cause a fire or electric shock due to damage to the product. • Keep the power cord or AC adapter away from any heating devices. - The cord coating may melt and cause fire or electric shock.
-
Page 6: Precautions For Moving The Product
Precautions for Moving the Product WARNING • Contact the service centre before moving the product. - It may cause electric shock and damage the product. • Make sure the product is turned off, unplugged, and all cables have been removed before the product is moved. - You may be electrocuted or the product can be damaged. -
Page 7: Precautions For Installing The Product
Precautions for Installing the Product WARNING • Contact the service centre before installing the product. - It can cause electric shock and damage the product. • Do not drop an object on or impact on the product. Keep out of reach of children and do not place toys or objects near the product to prevent throwing things on the product screen. - Page 8 CAUTION • Install the product where no Electromagnetic Interference occurs. • If you install the product in a place that does not meet the recommended conditions, this may cause serious damage to the product’s picture quality, life cycle, and appearance. Please check with service engineer before installing. Please do not install the product in places such as where there is an abundance of fine dust or oil mist, chemical substances are used, exposed to direct sunlight, the temperature is very high or low, the humidity is very high.
-
Page 9: Precautions For Cleaning The Product
Precautions for Cleaning the Product WARNING • Keep the product clean at all times. - If you don’t clean the unit for a long time and it becomes covered in dust, it can cause fire or product damage. • When you need to clean the inside of the product, you must contact the service centre. - Otherwise, cleaning without support may cause a fire, electric shock, or damage to the product. -
Page 10: Precautions For Using The Product
Precautions for Using the Product WARNING • Do not use the product in any environment with excessively high temperatures or humidity. - It may cause electrical shock or damage the product. • If you use the product for a long period of time, take a rest from time to time to protect your vision. - Extended viewing could result in impaired vision. - Page 11 • Do not use high voltage electrical goods near the product (e.g., a bug zapper). - This may result in product malfunction if it receives an electrical shock. • If there is a gas leak, do not touch the outlet, and open the windows for ventilation. - Otherwise, the product may cause fire or electric shock.
-
Page 12: Precautions For Using The Remote Control
Precautions for Using the Remote control WARNING • Avoid places with high humidity. - It may cause electrical shock or damage the product. • Do not expose batteries to excessive heat, such as direct sunlight, open fireplace, and electric heaters. - It may cause fire and you may be injured. -
Page 13: Assembling And Preparing
Software & Manual - Downloading from the LG Electronics website. - Visit the LG Electronics website ( http://partner.lge.com ) and download the latest software for your model. • The product’s quality is not guaranteed for use in direct sunlight or excessive dust. -
Page 14: Optional Accessories
Optional Accessories Without prior notice, optional accessories are subject to change to improve the performance of the product, and new accessories may be added. The illustrations in this manual may differ from the actual product and accessories. Stand ACC-S-EP5G Bracket Screws Screw Diameter 3.0 mm x Pitch 0.5mm x Length 4 mm... -
Page 15: Product Installation
Product Installation Neither a separate stand nor a wall-hanging unit is provided with this product. CAUTION • Disconnect the power cord before moving or installing the monitor to avoid risk of electric shock. • If you install the monitor on the ceiling, it may fall down and cause an injury. Contact a nearby agency or installation specialist. -
Page 16: Installing On A Wall
Screws which are longer than standard length may damage the inside of the monitor. A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is not liable for any accidents related to the use of non-standard screws. - Page 17 Disconnect the power cord before moving or installing the monitor to avoid risk of electric shock. • If you install the monitor on a ceiling or slanted wall, it may fall and result in injury. Use an authorized LG wall mount and contact your local dealer or qualified personnel to assist with the installation.
-
Page 18: Parts And Buttons
Parts and Buttons Front Item Explanation The LED flashes red when the panel brightness limit working. Supports tri-Color (red / green / orange) tally LEDs. Changes the input mode. (HDMI, SDI, SFP+, etc.) Frequently used functions can be assigned to the buttons as shortcuts. - Once a function has been assigned to a button, pressing that button turns on the LED. - Page 19 Rear REMOTE REMOTE RS232C AUDIO HDMI(4K@60Hz)IN USB IN REF IN SFP+ • : Updates and calibrate the software. • : Outputs sound through headphones. • : Uses the GPI controller to control the monitor from the outside. CAUTION For safety, do not connect the connector for peripheral device wiring that might have excessive voltage to this port. <Pin Assignment>...
-
Page 20: Remote Control
• (RJ45, 8pin): The input signal of the GPI controller can be used as an output. • : Updates the software. • : Connects HDMI signal. Please refer to the HDMI supported resolutions page. (Refer to page 72) • (SDI Input): Connects SDI signal. Please refer to the SDI supported resolution page. (Refer to page 68) •... - Page 21 (Power) Turns the monitor on or off. Turns the image on the monitor on and off. Selects the HDMI mode. (Input) Selects the input mode. Toggles between numerical and alphabetical. (This function is not supported.) Number and Alphabet Button Enters numerical or alphabetical characters depending upon the setting.
-
Page 22: Getting Ready
GETTING READY • It may take about one minute to initialize the product when the power is turned on for the first time after shipment from the factory. • The images of the product in this manual are to aid comprehension and may differ from the actual appearance. •... -
Page 23: Sdi Signal Connection
SDI Signal Connection • Use an SDI standard cable to secure the transmission distance of the SDI signal. (Refer to “PRODUCT SPECIFICATIONS” on page 66) • Use in the order of SDI cable connection according to the SDI transmission specifications. - Single Link 12G / 6G / 3G / HD / SD-SDI and Dual-Link 3G-SDI signals can be input to the SDI IN connectors of this monitor. -
Page 24: Using The Input List
• If you cannot hear any sound in HDMI mode please check your PC settings. Some PCs require you to manually change the default audio output to HDMI. • You may experience compatibility issues if you use HDMI-PC mode. • Make sure the power cable is disconnected. -
Page 25: Menu
MENU Menu Item 1 Item 2 Value OLED Light 0 ~ 100 Brightness 0 ~ 100 Contrast 0 ~ 100 Chroma 0 ~ 100 Sharpness 0 ~ 50 Tint -50 ~ 50 VAR Temp, 9300K, 5400K, Color Temp 3200K, D65 (6504K), D-Cinema (6302K) VAR Temp 3200K ~ 9300K... - Page 26 Menu Item 1 Item 2 Item 3 Value SDR / HDR Signal Auto , SDR , HDR Format Auto , Native, BT.709 , BT.2020 , sRGB , SDR Gamut AdobeRGB , P3 SDR Configuration SDR EOTF Auto , User , 1.9 , 2.2 , 2.4 , 2.6 SDR EOTF User 0.8 ~ 3.0 (0.1 step) Auto , Native, BT.709 , BT.2020 , sRGB ,...
- Page 27 Menu Item 1 Item 2 Value Over Scan Zero Scan, Over Scan, Under Scan Full Wide, 4 : 3, 14 : 9, 13 : 9, 1.85 : 1, 2.35 : 1, Aspect Ratio Aspect Ratio 1 : 1, Original, Auto 2 x Zoom Apply 3 x Zoom...
- Page 28 Menu Item 1 Item 2 Value Marker Line Color White, Yellow, Blue, Red, Black BG Color None, Gray, White, Blue, Black BG Transparency 0%, 20%, 40%, 60%, 80%, 100% Marker Color Center Marker Color White, Yellow, Blue, Red, Black Safety Area Line Color White, Yellow, Blue, Red, Black BG Color...
- Page 29 Menu Item 1 Item 2 Value GPI Control Enable/Disable GPI 1 Undefined, Marker Preset 1, Marker Preset 2, Marker, Center Marker, Safety Area, Tally R, Rally G, GPI 2 Input HDMI1, Input HDMI2, Input SDI1, Input SDI2, GPI 3 Input SDI3, Input SDI4, GPI 4 Input Dual Link (SDI 1&2), Input Dual Link (SDI GPI 5...
- Page 30 Menu Item 1 Item 2 Value Load Profile Profile1 ~ 10 Save as Profile Profile1 ~ 10 Reset Profile Profile1 ~ 10 Profile Change Profile Password Option for Loading Saved Load without Entering Password Profiles Undefined, Marker, Safety Area, Marker Preset 1, Marker Preset 2, Aspect Ratio, Function Key Audio Level Meter, Mono / Blue Only, Waveform,...
- Page 31 Menu Item 1 Item 2 Value Device Name Model Name webOS Version S/W Version Serial Number Information Micom Version FPGA Version Network Settings Internal Memory Temperature Open Source Software Notice Front LED Enable/Disable Control Auto Front Key Lock Enable/Disable Auto IR Lock Enable/Disable HDMI 1 Enable/Disable...
- Page 32 Menu Item 1 Item 2 Value LG Connect Enable/Disable Closed Caption Enable/Disable Closed Caption Mode 708, 608 ANC, 608 Transcoded Caption 608 Caption Channel 708 Catption Channel Off, Service1 PIP/PBP Enable/Disable Type Advanced Input Source HDMI 1, HDMI2 Picture In Picture /...
-
Page 33: User Settings
USER SETTINGS Main Menu Sub Menu • How to adjust the menu - You can press the button to launch the Settings menu. - Press the / Dial button on the Main menu icon to go to the Submenu. - Pressing the button while running the Setup menu moves you to the previous step. -
Page 34: Picture
Picture [Color Adjustment] • [OLED Light]: Adjusts the brightness of the screen by adjusting the brightness of the OLED panel. • [Brightness]: Adjusts the overall brightness of the screen. The closer the value to 100, the brighter the screen. • [Contrast]: Adjusts the difference between the screen’s light and dark areas. - Page 35 [Display Configuration] • [SDR / HDR Signal Format]: Select HDR, SDR signal format manually. Auto: use Video Information - [SDR Configuration] - [SDR Gamut]: Selects the Color Gamut for SDR input. - [SDR EOTF]: Selects the EOTF for SDR input. - [SDR EOTF User]: Adjusts the EOTF in the range of 0.8 ~ 3.0.
- Page 36 • [Mono / Blue Only] - [Off]: Disables [Mono / Blue Only]. - [Mono Color]: Displays a single Color screen. - [Blue Color]: Displays only the blue signal on the screen. • [Input Range]: Correct the darkness and contrast of the screen based on the input signal range. (Settings recommended based on input signal: RGB 0 –...
- Page 37 [Over Scan] Select a scan mode for image output. • [Zero Scan]: Displays 100 % of the original image size. • [Over Scan]: Displays 95 % of the original image size. • [Under Scan]: Displays 105 % of the original image size. NOTE • [Over Scan] is deactivated when any of the features below have been enabled. - [HDR / SDR Monitoring] - [Internal Pattern] - [PBP] When deactivated, [Over Scan] is set to [Zero Scan].
- Page 38 [Aspect Ratio] The screen size can be adjusted to the set ratio. • [Full Wide] : Sets the screen size to full wide. • [4 : 3]: Sets the screen size to 4 : 3. • [14 : 9]: Sets the screen size to 14 : 9. •...
- Page 39 [Zoom] Zoom into the current external input image. • [2x Zoom]: The original image is enlarged 2x by dividing the external input into a 2 x 2 grid. • [3x Zoom]: The original image is enlarged 3x by dividing the external input into a 3 x 3 grid. •...
- Page 40 [Picture Options] • [Noise Reduction]: Removes irregularly generated tiny dots for a clearer picture. • [MPEG Noise Reduction]: Reduces the noise produced during the generation of digital video signals. • [Real Cinema]: Optimises the screen for movie viewing. • [Motion Eye Care]: Adjusts brightness and image blurring based on the image information in order to reduce eyestrain.
-
Page 41: Marker
Marker [Marker] Check the ratio for the image displayed on the screen in advance. • [Off]: Disables the marker (Default) • [16 : 9]: Displays a ratio of 16 : 9 (3840 x 2160) on the screen. • [4 : 3]: Displays a ratio of 4 : 3 (2880 x 2160) on the screen. •... - Page 42 [Safety Area] Check the scan ratio of images to be displayed on the screen in advance. • [Off] : Disables the safety zone (Default). • [16 : 9, 95%]: Displays the ratio of 16 : 9 at 95 % (3648 x 2052). • [16 : 9, 93%]: Displays the ratio of 16 : 9 at 93 % (3570 x 2008). • [16 : 9, 90%]: Displays the ratio of 16 : 9 at 90 % (3456 x 1944). • [16 : 9, 88%]: Displays the ratio of 16 : 9 at 88 % (3378 x 1900). • [16 : 9, 85%]: Displays the ratio of 16 : 9 at 85 % (3264 x 1836). • [16 : 9, 80%]: Displays the ratio of 16 : 9 at 80 % (3072 x 1728). • [4 : 3, 95%]: Displays the ratio of 4 : 3 at 95 % (2736 x 2052). • [4 : 3, 93%]: Displays the ratio of 4 : 3 at 93 % (2678 x 2008). •...
- Page 43 [Marker Color] Set the Color of the marker and the safety zone. [Line Color] Set the line Color of the marker. • [White]: Set the line Color of the marker to white (default). • [Yellow]: Set the line Color of the marker to yellow. •...
-
Page 44: Audio
Audio [Audio Source Selection] Audio is outputted from the selected SDI input source. The Audio Level Meter measures the audio level for the corresponding SDI audio and displays it on the screen. • [SDI1]: Select the SDI1 input source for which to measure the audio level. •... - Page 45 [Audio Level Meter] • [Audio Level Meter]: Shows audio broadcast signals on the screen through the audio level meter. • [Audio Level Meter Type] : Select the direction of the bar graph to show the audio level meter on the screen. •...
- Page 46 NOTE • For Quad View output, the audio output and audio level meter output for a specific input source can be selected from the Audio Source Selection menu. • For Single Link / Dual Link / Quad Link, the Audio Source Selection menu is disabled, and the feature for selecting the audio source based on the current input is automatically enabled.
-
Page 47: Gpi
Assign frequently used features to GPIs (General Purpose Interface) 1 to 7. Each GPI can send a signal to execute the feature assigned to it. • The features that can be assigned to GPIs 1 to 6 are as follows: - [Undefined]: No feature is assigned. - Page 48 - [Input Dual Link (SDI 1&2)]: Switches input to Dual Link (SDI1 & 2). - [Input Dual Link (SDI 3&4)]: Switches input to Dual Link (SDI3 & 4). - [Input Quad Link : Auto]: Switches input to Quad Link: Auto. - [Input Quad Link : 2SI]: Switches input to Quad Link: 2SI.
-
Page 49: Video Analysis
Video Analysis [Waveform] View the luminance information of the current input picture as a waveform. View the saturation components through a vectorscope. Select a graph type. - [Off]: Turns off Waveform. - [WF (Waveform)]: Turns on Waveform. - [VT (Vectorscope)]: Turns on Vectorscope. - [WF + VT]: Turns on Waveform and Vectorscope. - Page 50 • [Vector Color]: Select a background Color for the vectorscope. - [On/Off]: Turns on / off the vectorscope background Color. • [Position]: Select a location to display the graph. - [Left-Top]: Set the graph location to the top left corner. - [Right-Top]: Set the graph location to the top right corner.
- Page 51 [Input Source] Select the input to show on the sub screen when [HDR / SDR Monitoring] is [2 Source Mode] NOTE • Only the combinations of HDMI and SDI or HDMI and SFP+ are allowed. Main Screen Input Sub screen Input List HDMI1 HDMI2, SDI1, SDI2, SDI3, SDI4, SFP+ HDMI2...
-
Page 52: Advanced Settings
Advanced Settings Profile This feature allows the user to save his or her preferred settings and load them at any time. [Load Profile] Retrieve and load specific user settings to the device and make them available by saving them as [Profile]. If no settings have been saved by the user, the default settings are loaded. - Page 53 • Items Displayed in User Settings - OLED Light - Brightness - Contrast - Chroma - Sharpness - Tint - Color Temperature - SDR Gamut - SDR EOTF - HDR Gamut - HDR 1D LUT - Dolby Vision 1D LUT - Dolby Vision Parameters - PQ Clip Point - SDI Color Format...
- Page 54 [Function Key] Assign frequently changed features to the Function keys in the local key bar and use them like hot keys. Assign features to Function keys 1 to 5, respectively, from the menu. The features that can be assigned are as follows: •...
- Page 55 [UMD] Check which camera is connected and being used to take pictures. • [UMD] (Toggle On / Off): Activates the UMD feature. • [UMD Character]: Sets the text for the UMD. • [UMD Position]: Sets the UMD location. - Left-Top: Sets the UMD location to the top left corner. - Center-Top: Sets the UMD location to the top centre.
- Page 56 [VPID] Check the status of SDI signals sent by FPGA. • [Off]: Does not show SDI signal status. • [On]: SDI signal status is shown for three seconds and disappears. NOTE • Displayed Information - Transport - Picture - Transfer - Picture Rate - Aspect Ratio - Colorimetry (Output value type: Rec.
- Page 57 [HDMI Ultra HD Deep Color] If the user has a digital input (HDMI1, 2) device connected to one of the ports with adjustable deep Color, UHD Deep Color On (6G) or Off (3G) can be selected from the ULTRA Deep Color Settings menu. If compatibility issues occur with the graphics card when the Deep Color option is set to On at 3840 x 2160 @ 60 Hz, set the option to Off.
- Page 58 [Screen Saver] • Prevent afterimage or overuse of panels using the screen protection feature when there is no signal. • On: Runs the screensaver if there is no signal for 130 seconds (default) • Off: Screensaver is disabled. [No Signal Message] Set the [no signal message] function to On or Off. • On: Enable no signal message (default).
- Page 59 • If connected to a network that supports IPv6, it is also possible to view IPv6 network connection information from a wired network connection. However, IPv6 connections only support automatic connections. [LG Connect] • Sets the [LG Connect] function to On or Off. • You can connect device via Promota, Calman API and WebApp API. •...
- Page 60 [Picture In Picture / Picture By Picture] • [PIP / PBP]: Output an image from another input source to the sub screen. - [On]: Enables PIP / PBP. - [Off]: Disables PIP / PBP. • [Type]: Sets the size of the sub screen. •...
-
Page 61: Calibration
Ensure the monitor and PC with CalMan are connected to the same local area network (LAN). Select the “Display Specific Autocal – LG” workflow in CalMan and follow CalMan’s instructions to calibrate the monitor. Connecting to CalMan will require the 65EP5G’s IP Address. Once the monitor is connected to LAN, navigate in the 65EP5G menu to “Advanced... - Page 62 [Metameric Offset] The perceived white point of the 65EP5G may not match the measured white point. The mismatch is a result of observer metamerism, which affects all wide color gamut displays in this way. Two calibrated displays may visually appear to have different white points despite having the same measured chromaticity, due to a difference in their spectral emittance.
-
Page 63: Troubleshooting
TROUBLESHOOTING Ů Each model may have different points to check. Ů For information on your PC settings, refer to the Windows Help. Issues Related to Use • The power won’t turn on. - Check if the power cord is correctly plugged into the power outlet. - Try turning the power on after disconnecting the AC adapter and cleaning the contacting port. - Page 64 Issues Related to Screen (Color) • Screen has poor Color resolution (16 Colors). - Use PC settings to set the Color to 24 bits (True Color) or above. • Screen Color is unstable or mono-Colored. - Check the connection status of the signal cable. Or, re-insert the PC graphics card. • Black spots or bright spots appear on the screen. - Some pixels (red, green, blue, black) are visible on the screen due to the unique characteristics of the display panel.
- Page 65 Other Issues • The power suddenly turned off. - Check if the auto-off function is activated on the settings related time. - Power source has not being supplied properly. See if the product power cord is connected properly. - Check the power control settings. OLED Image sticking •...
-
Page 66: Product Specifications
PRODUCT SPECIFICATIONS Without prior notice, all product information and specifications contained in this manual are subject to change to improve the performance of the product. symbol means alternating current, and the symbol means direct current. Item Standard Note Power Supply 100-240 V~ 50 / 60 Hz Maximum 4096 x 2160 @ 60 Hz... - Page 67 Item Standard Note Maximum 4096 x 2160 @ 60 Hz Resolution Recommend 3840 x 2160 @ 60 Hz Resolution * Supported SFP Module: 4K @ SFP+ YCbCr422 10 bits Embrionix SDI SFP 60 / 50 Hz module Color Format & RGB444 / YCbCr444, Depth 10 / 12 bits 4K @ 30 / 25 Hz YCbCr422 Input 10 / 12 bits USB version USB2.0, set 1 (rear) Service (SW Update) RS232C SW update and Calibration...
- Page 68 SDI Support mode Interfaces Signal Format YCbCr 4:2:2 10 bit 47.95 / 48 / 50 / 59.94 / 60 p YCbCr 4:2:2 12 bit YCbCr 4:4:4 10 bit 12G Single Link 4K 3840 x 2160 (ST 2082-10) 4096 x 2160 YCbCr 4:4:4 12 bit 23.98 / 24 / 25 / 29.97 / 30 p RGB 4:4:4 10 bit RGB 4:4:4 12 bit 6G Single Link 4K 3840 x 2160 YCbCr 4:2:2 10 bit 23.98 / 24 / 25 / 29.97 / 30 p (ST 2081-10) 4096 x 2160 YCbCr 4:2:2 10 bit 47.95 / 48 / 50 / 59.94 / 60 p YCbCr 4:2:2 12 bit...
- Page 69 Interfaces Signal Format YCbCr 4:2:2 10 bit 47.95 / 48 / 50 / 59.94 / 60 p YCbCr 4:2:2 12 bit YCbCr 4:4:4 10 bit 3G_B Dual Link 1920 x 1080 23.98 / 24 / 25 / 29.97 / 30 p (ST 425-1) 2048 x 1080 YCbCr 4:4:4 12 bit 50 / 59.94 / 60 i RGB 4:4:4 10 bit RGB 4:4:4 12 bit YCbCr 4:4:4 10 bit 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 1280 x 720 / 60 p RGB 4:4:4 10 bit YCbCr 4:2:2 10 bit...
- Page 70 SFP+ Support mode Interfaces Signal Format YCbCr 4:2:2 10 bit 47.95 / 48 / 50 / 59.94 / 60 p YCbCr 4:2:2 12 bit YCbCr 4:4:4 10 bit 12G Single Link 4K 3840 x 2160 (ST 2082-10) 4096 x 2160 YCbCr 4:4:4 12 bit 23.98 / 24 / 25 / 29.97 / 30 p RGB 4:4:4 10 bit RGB 4:4:4 12 bit 6G Single Link 4K 3840 x 2160 YCbCr 4:2:2 10 bit 23.98 / 24 / 25 / 29.97 / 30 p (ST 2081-10) 4096 x 2160 YCbCr 4:4:4 10 bit 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 1280 x 720...
- Page 71 Quad View Support mode Interfaces Signal Format YCbCr 4:2:2 10 bit 47.95 / 48 / 50 / 59.94 / 60 p YCbCr 4:2:2 12 bit YCbCr 4:4:4 10 bit 12G Single Link 4K 3840 x 2160 (ST 2082-10) 4096 x 2160 YCbCr 4:4:4 12 bit 23.98 / 24 / 25 / 29.97 / 30 p RGB 4:4:4 10 bit RGB 4:4:4 12 bit 6G Single Link 4K 3840 x 2160 YCbCr 4:2:2 10 bit 23.98 / 24 / 25 / 29.97 / 30 p (ST 2081-10) 4096 x 2160 YCbCr 4:2:2 10 bit 47.95 / 48 / 50 / 59.94 / 60 p YCbCr 4:2:2 12 bit...
- Page 72 HDMI Support Mode Signal Format 640 x 480 RGB 4:4:4 8 / 10 / 12 bit 720 x 480 800 x 600 YCbCr 4:4:4 8 / 10 / 12 bit 60 p 1024 x 768 YCbCr 4:2:2 12 bit 1280 x 720 RGB 4:4:4 8 / 10 / 12 bit 720 x 576 YCbCr 4:4:4 8 / 10 / 12 bit 50 p 1280 x 720 YCbCr 4:2:2 12 bit RGB 4:4:4 8 / 10 / 12 bit 24 / 25 / 30 / 50 / 60 p 1920 x 1080 YCbCr 4:4:4 8 / 10 / 12 bit 50 / 60 i YCbCr 4:2:2 12 bit RGB 4:4:4 8 / 10 / 12 bit...
-
Page 73: Licenses
. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to o pensource@lge.com . - Page 74 The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. MODEL Temporary noise is normal when powering ON or OFF this device. SERIAL NO.
