FEATURES

1
1. INPUT: 1/4" TRS stereo input jack accepts signals from the
headphone output on an audio interface to use for Reamping.
2. MONO: Sums the left and right input channels together. When
disengaged, only the right channel is used to feed the output of the
Reamp HP.
3. MINI IN: 3.5mm input jack for easy connection to the outputs of
smartphones, tablets, and laptops.
4. LEVEL: Controls the output signal level from the Reamp HP for
optimal gain-staging through amplifiers and pedals.
5. LIFT: Disconnects pin-1 at the input connectors to remove buzz
and hum caused by ground loops.
6. OUTPUT: 1/4" TS mono Reamp output used to feed guitar amps
and effects pedals.
Radial Engineering Ltd.
2 3
2
True to the Music
4 5 6
Reamp HP™
