Klaser Series Programmable Keyboard
Built-in Laser Barcode Scanner
PROGRAMMING MANUAL
LOGIC CONTROLS, INC.
355 Denton Avenue
New Hyde Park, NY 11040
TEL: (516) 248-0400
FAX: (516) 248-0443
Email:
lci@logiccontrols.com
http://www.logiccontrols.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LK7000 and is the answer not in the manual?

Questions and answers

Related Manuals for Logic Controls LK7000

Summary of Contents for Logic Controls LK7000

  • Page 1 Klaser Series Programmable Keyboard Built-in Laser Barcode Scanner PROGRAMMING MANUAL LOGIC CONTROLS, INC. 355 Denton Avenue New Hyde Park, NY 11040 TEL: (516) 248-0400 FAX: (516) 248-0443 Email: lci@logiccontrols.com http://www.logiccontrols.com...

  • Page 2: Operational Parameters

    Operational Parameters The Klaser integrated barcode scanner is shipped with the default settings shown below. These default values are stored in non-volatile memory and are preserved even when the scanner is powered down. You can change the default values by scanning the appropriate bar codes included in this manual. These new values replace the standard default values in memory.

  • Page 3: Set Default Parameter

    Set Default Parameter Scanning this barcode returns all parameters to the factory default values. Beeper Tone To select a decode beep frequency (tone), scan the appropriate bar code. Laser On Time This parameter sets the maximum time decode processing continues during a scan attempt. It is programmable in 0.1 second increments from 0.5 to 9.9 seconds.

  • Page 4: Triggering Modes

    Triggering Modes Level - Pressing and holding trigger key activates the laser. The laser remains on, and decode processing continues until trigger key is released, a valid decode, or the Laser On Time-out is reached. Pulse - Pressing trigger key activates the laser. The laser remains on and decode processing continues until a valid decode, or the Laser On Time-out is reached.
  • Page 5 UPC/EAN Enable/Disable UPC-A Enable/Disable UPC-E Enable/Disable UPC-E1 Enable/Disable EAN-8...

  • Page 6: Enable/Disable Bookland Ean

    Enable/Disable EAN-13 Enable/Disable Bookland EAN Decode UPC/EAN Supplementals Supplementals are additionally appended characters (2 or 5) according to specific code format conventions (e.g., UPC A+2, UPC E+2, EAN 8+2). Three options are available. DECODE - UPC/EAN barcodes with supplemental characters are decoded. Barcodes without supplemental characters are ignored completely.
  • Page 7 Enable/Disable UPC-A Check Digit Transmission Enable/Disable UPC-E Check Digit Transmission Enable/Disable UPC-E1 Check Digit Transmission...

  • Page 8: Upc-A Preamble

    UPC Preamble Three options are given for lead-in characters for UPC symbols transmitted to the host device: No Preamble transmitted, transmit System Character Only, and transmit System Character and Country Code (“0” for USA). The lead-in characters are considered part of the symbol. UPC-A Preamble UPC-E Preamble UPC-E1 Preamble...

  • Page 9: Code 128

    Code 128 Enable/Disable USS-128 Enable/Disable UCC/EAN-128 Enable/Disable ISBT 128...

  • Page 10: Enable/Disable Code

    Code 39 Enable/Disable Code 39 Set Lengths for Code 39 Lengths for Code 39 may be set for one discrete length or lengths within a specific range. The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code (Numeric barcodes are at the end of this manual.
  • Page 11 Enable/Disable Code 39 Check Digit Verification Enable/Disable Code 39 Check Digit Transmission...
  • Page 12 Code 93 Enable/Disable Code 93 Set Lengths for Code 93 Lengths for Code 39 may be set for one discrete length or lengths within a specific range. The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code (Numeric barcodes are at the end of this manual.

  • Page 13: Interleaved 2 Of 5

    Interleaved 2 of 5 Enable/Disable Interleaved 2 of 5 Set Lengths for Interleaved 2 of 5 Lengths for I 2 of 5 may be set for one discrete length or lengths within a specific range. The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code (Numeric barcodes are at the end of this manual.

  • Page 14: I 2 Of 5 Check Digit Verification

    I 2 of 5 Check Digit Verification When enabled, this parameter checks the integrity of an I 2 of 5 symbol to ensure it complies with a specified algorithm, either USS (Uniform Symbology Specification), or OPCC (Optical Product Code Council). Enable/Disable I 2 of 5 Check Digit Transmission...
  • Page 15 Discrete 2 of 5 Enable/Disable Discrete 2 of 5 Set Lengths for Discrete 2 of 5 Lengths for D 2 of 5 may be set for one discrete length or lengths within a specific range. The length of a code refers to the number of characters (i.e., human readable characters) the code contains, and includes check digits.

  • Page 16: Enable/Disable Codabar

    Codabar Enable/Disable Codabar Set Lengths for Codabar Lengths for Codabar may be set for one discrete length or lengths within a specific range. The length of a code refers to the number of characters (i.e., human readable characters) the code contains, and includes check digits.
  • Page 17 Enable/Disable OTIS Editing When enabled, this parameter strips the start and stop characters from decoded Codabar symbol.

  • Page 18: Prefix/Suffix Values

    Prefix/Suffix Values A prefix and/or one or two suffixes may be appended to scan data for use in data editing. These values are set by scanning a four digit number (i.e. four barcodes) that corresponds to key codes for various terminals. See the Character Table (P.20) and Numeric Barcodes (P.19). If you make an error, or wish to change your selection, scan the CANCEL barcode.

  • Page 19: Scan Data Transmission Format

    Scan Data Transmission Format To change the Scan Data Transmission Format, scan one of the eight bar codes below corresponding to the desired format.

  • Page 20: Numeric Bar Codes

    Numeric Bar Codes...

  • Page 21: Character Table

    Character Table Scan Value Hex Value 1000 1001 1002 1003 1004 1005 1006 1007 1008 1009 1010 1011 1012 1013 1014 1015 1016 1017 1018 1019 1020 1021 1022 1023 1024 1025 1026 1027 1028 1029 1030 1031 Key / ASCII Scan Value CTRL 2 1032...
  • Page 22 Scan Value Hex Value Key / ASCII 1064 1065 1066 1067 1068 1069 1070 1071 1072 1073 1074 1075 1076 1077 1078 1079 1080 1081 1082 1083 1084 1085 1086 1087 1088 1089 1090 1091 1092 1093 1094 1095 Scan Value 1096 1097 1098...
