- Page 1 QUICK START GUIDE VIA ARTiGO A950 Compact and durable fanless system for M2M and Edge-AIoT applications 1.00-20102022...
- Page 2 VIA Technologies, Inc. reserves the right the make changes to the products described in this manual at any time without prior notice.
- Page 3 Safety Precautions • Always read the safety instructions carefully. • Keep this User Manual for future reference. • All cautions and warnings on the equipment should be noted. • Keep this equipment away from humidity and direct sunlight. • Put this equipment on a reliable flat surface before setting it up. •...
- Page 4 VIA ARTiGO A950 Quick Start Guide Ordering Information Part Number Description ATG-A950-1Q10A0 Fanless Edge AIoT system with 2.0GHz MediaTek Genio 500 Octa-Core SoC, 16GB eMMC, 4GB LPDDR4 SDRAM, HDMI, USB 2.0, Micro USB 2.0 OTG, 2 LAN, 3.5mm Phone Jack, Wi-Fi, Bluetooth 5.0, MiniPCIe slot, SIM card slot, 12V DC-in.
-
Page 5: Table Of Contents
VIA ARTiGO A950 Quick Start Guide Table of Contents Introduction ..............................1 Product Specifications ........................... 1 System Layout ............................3 System Dimensions ..........................4 Hardware Installation ............................. 5 System Installation ..........................5 Wi-Fi/BT Antenna Installation ....................... 5 Connecting System to Power Source ....................6... - Page 6 Figure 03: Left panel external I/O layout ......................3 Figure 04: Right panel external I/O layout ......................3 Figure 05: VIA ARTiGO A950 system dimensions ....................4 Figure 06: A Wi-Fi/BT antenna ..........................5 Figure 07: Installing a Wi-Fi antenna on the system's left panel ................5 Figure 08: Installing the Bluetooth and Wi-Fi antennas on the system's right panel ...........
-
Page 7: Introduction
OCR, and biometric measurement. This user guide introduces the VIA ARTiGO A950 system and provides instructions for a quick hardware setup. 1.1 Product Specifications Processor •... - Page 8 VIA ARTiGO A950 Quick Start Guide Front Panel I/O • Power button with LED • Reset button Back Panel I/O • HDMI connector • USB 2.0 port • Micro USB 2.0 port (for OS image upload only) • 2 10/100Mbps Ethernet ports •...
-
Page 9: System Layout
VIA ARTiGO A950 Quick Start Guide 1.2 System Layout Reset Button Power Button Figure 01: Front panel external I/O layout USB 2.0 Ethernet DC-In Jack HDMI Micro USB OTG Figure 02: Back panel external I/O layout Antenna Hole Wi-Fi Antenna Connector... -
Page 10: System Dimensions
VIA ARTiGO A950 Quick Start Guide 1.3 System Dimensions 147.25mm 111.06mm 103.5mm 165.25mm 34.0mm Figure 05: VIA ARTiGO A950 system dimensions... -
Page 11: Hardware Installation
The VIA ARTiGO A950 system's standard package includes 3 Wi-Fi/BT antennas. Figure 06: A Wi-Fi/BT antenna To install the Wi-Fi/BT antennas on the VIA ARTiGO A950 system, follow the steps below: Step 1 Locate the Wi-Fi antenna connector on the VIA ARTiGO A950 system's left panel. -
Page 12: Connecting System To Power Source
2.3 Connecting System to Power Source The VIA ARTiGO A950 system requires a 12V DC input power supply. A 100 ~ 240V AC-to-DC power adapter and Japan-type power cord with ground fuse is provided in the VIA ARTiGO A950 system's standard package. To connect the VIA ARTiGO A950 system to the power source, follow the steps below. -
Page 13: Figure 11: Power Connections
VIA ARTiGO A950 Quick Start Guide Step 2 Locate the DC-In Jack on the VIA ARTiGO A950 system's back panel and plug in the power adapter. Step 3 Connect the power cord to the power source and its fuse to ground. -
Page 14: Technical Support And Assistance
VIA ARTiGO A950 Quick Start Guide 3. Technical Support and Assistance • For technical support and additional assistance, contact your local sales representative/board distributor or visit webpage https://www.viatech.com/en/support/technical-support/ for technical support. • For OEM clients and system integrators developing a product for long-term production, other code and resources may also be made available. - Page 15 Taiwan Headquarters Japan China 1F, 531 Zhong-zheng Road, 940 Mission Court 3-15-7 Ebisu MT Bldg. 6F, Tsinghua Science Park Bldg. 7 Xindian Dist., New Taipei City 231 Fremont, CA 94539, Higashi, Shibuya-ku No. 1 Zongguancun East Road, Taiwan Tokyo 150-0011 Haidian Dist., Beijing, 100084 Japan China...
