Network Connection Manual
SRP-330/332III
Ver. 1.00
http://www.bixolon.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRP-330III and is the answer not in the manual?

Questions and answers

Related Manuals for BIXOLON SRP-330III

Summary of Contents for BIXOLON SRP-330III

  • Page 1 Network Connection Manual SRP-330/332III Ver. 1.00 http://www.bixolon.com...

  • Page 2: Table Of Contents

    Network Connection Manual Table of Contents Copyright ........................3 1. Manual Information ....................4 2. Specifications ......................4 3. How to Connect ...................... 5 3-1 Connecting Printer ......................5 3-2 Checking Network Setting..................6 3-3 LAN Setting Values ......................7 4. Ethernet Test by using Windows Test Page ............8 5.

  • Page 3: Copyright

    This user manual and all property of the product are protected under copyright law. It is strictly prohibited to copy, store, and transmit the whole or any part of the manual and any property of the product without the prior written approval of BIXOLON Co., Ltd.

  • Page 4: Manual Information

    Network Connection Manual 1. Manual Information To change the printer settings, establish a connection by configuring its LAN and the network settings of the host e.g., PC, PDA. 2. Specifications CATEGORIES FEATURE IMPLEMENTATION Interface 10/100 Base-T All in one(Auto detection) Specification Protocol DHCP Client, HTTP, ARP, ICMP, IPv4, TCP, UDP...

  • Page 5: How To Connect

    Network Connection Manual 3. How to Connect To change the printer settings, establish a connection by configuring its LAN and the network settings of the host e.g., PC, PDA. 3-1 Connecting Printer • Connect the LAN cable to the printer. Establish a connection with the hub or host using a LAN cable.

  • Page 6: Checking Network Setting

    Network Connection Manual 3-2 Checking Network Setting After the printer has finished booting, open the printer cover and press and hold the • FEED Button for 5 seconds. This will cause the interface setting confirmation mode. Then add the paper, close the cover, and check that the following message is printed. Checking Interface Setting 0: Exit 1: WLAN Information Print...

  • Page 7: Lan Setting Values

    Network Connection Manual 3-3 LAN Setting Values Classification Item Description Input Range Inactivity Time TCP connection hold time 0~3600 integer IP Assignment IP Assignment Method DHCP/Manual Method Network IP Address Printer IP IP Address Subnet Mask Subnet mask IP Address Gateway Default Gateway IP Address...

  • Page 8: Ethernet Test By Using Windows Test Page

    Operating systems that allow you to use the Windows printer driver are Windows, XP, Server 2003, VISTA, 2008 Server, 7, 8, 10. You can download the latest version of Windows driver from our home page. (www.bixolon.com) 1) Double-click the Windows Driver installation file. 2) Click Install.
  • Page 9 Network Connection Manual 3) Select Installation and click Next. 4) Select Model Name and click Next. Ver. 1.00 - 9 -...
  • Page 10 Network Connection Manual 5) Select Ethernet and click Add TCP/IP Port. 6) Enter the IP address and port number, and then click Next. Ver. 1.00 - 10 -...
  • Page 11 Network Connection Manual 7) Click Next. 8) Click Next. Ver. 1.00 - 11 -...
  • Page 12 Network Connection Manual 9) Click Next. 10) Click Finish. Ver. 1.00 - 12 -...
  • Page 13 Network Connection Manual 11) Open the printer properties window in the Windows OS. Installing on Windows VISTA / Server 2008 / 7 / 8 / Server 2012 / 10 ※ Control Panel – Hardware and Sound – Device and Printers. 12) In the Ports tab, click Configure Port.
  • Page 14 Network Connection Manual 14) Click Print Test Page and check printing status. Proper installation of the driver is indicated if the test page is printed normally. Ver. 1.00 - 14 -...

  • Page 15: Factory Reset

    Network Connection Manual 5. Factory Reset 5-1 Initializing LAN Setting • This function changes the LAN settings of the printer to the initial factory settings. After the printer has finished booting, open the printer cover and press and hold the •...

  • Page 16: Troubleshooting

    Network Connection Manual 6. Troubleshooting [IP Address] Check the band of the IP Address. Check whether the bands of the printer and the AP (or wireless terminals) are the same. Check network The first three digits of the four digit value of the IP address setting must be the same.
  • Page 17 Network Connection Manual When you see “Request timed out.” as shown below, it means that there is no collision. The corresponding IP can be used. On the other hand, if there is a reply as shown below, then the corresponding IP is used by another network terminal and it cannot be used for the printer IP.

This manual is also suitable for:

Srp-332iii
