User's Manual
Network Interface
Rev. 1.00
SRP-330II
SRP-332II
http://www.bixolon.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the SRP-330II and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BIXOLON SRP-330II

Summary of Contents for BIXOLON SRP-330II

  • Page 1 User's Manual Network Interface Rev. 1.00 SRP-330II SRP-332II http://www.bixolon.com...

  • Page 2: Table Of Contents

    Network Interface ■ Table of Contents 1. Manual Information ......................3 2. Specifications ........................ 3 3. How to Connect......................4 4. Ethernet Test by using Windows Test Page ..............5 5. Factory Reset ......................... 9 6. Troubleshooting......................10 - 2 - Rev.

  • Page 3: Manual Information

    1. Manual Information This Network manual provides information on the connection of network with the printer. We at BIXOLON maintain ongoing efforts to enhance and upgrade the functions and quality of all our products. In following, product specifications and/or user manual content may be changed without prior notice.

  • Page 4: How To Connect

    Network Interface 3. How to Connect 1) Checking Network Setting (1) LAN Function key Function key a. Turn on the printer. b. Wait 10 or more seconds until the LAN interface boots up. c. Push the function key. d. The settings will be printed only one time since the printer is turned on. 2) LAN Setting Values Classification Item...

  • Page 5: Ethernet Test By Using Windows Test Page

    Server 2003, VISTA, 2008 Server, 7, 8, 10. [Note] -The Windows driver is included in the CD, and you can download the latest version from our home page. (www.bixolon.com) 1) Double-click the Windows Driver installation file. 2) Click Next. 3) Select Ethernet.
  • Page 6 Network Interface 4) Enter the IP address and port number, and then click Next. 5) Click Yes to reboot the PC. 6) Open the printer properties window in the Windows OS. (1) Installing on Windows XP / Server 2003 ※ Control Panel – Printers and Faxes. (2) Installing on Windows VISTA / Server 2008 / 7 / 8 / Server 2012 / 10 ※...
  • Page 7 Network Interface 8) Match the communication settings to those of the printer. - 7 - Rev. 1.00...
  • Page 8 Network Interface 9) Click Print Test Page and check printing status. Proper installation of the driver is indicated if the test page is printed normally. - 8 - Rev. 1.00...

  • Page 9: Factory Reset

    Network Interface 5. Factory Reset This function changes the WLAN settings of the printer to the initial factory settings. Follow the instructions shown below to perform the Factory Reset. 1) Default Printer Settings - Dynamic IP mode(DHCP mode is enabled.) - Local Port: 9100 - Inactivity Time: 0 2) Procedure...

  • Page 10: Troubleshooting

    Network Interface 6. Troubleshooting When printing doesn‟t work Check network setting (Refer to Configuration for checking/changing the printer settings) IP Address Check the band of the IP Address. Check whether the bands of the printer and the AP(or wireless terminals) are the same. The first three digits of the four digit value of the IP address must be the same.
  • Page 11 Network Interface When you see “Request timed out.” as shown below, it means that there is no collision. The corresponding IP can be used. On the other hand, if there is a reply as shown below, then the corresponding IP is used by another network terminal and it cannot be used for the printer IP.
