User's Manual
SRP-330III/332III
THERMAL PRINTER
Ver. 1.00
http://www.bixolon.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRP-330III and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BIXOLON SRP-330III

Summary of Contents for BIXOLON SRP-330III

  • Page 1 User’s Manual SRP-330III/332III THERMAL PRINTER Ver. 1.00 http://www.bixolon.com...

  • Page 2: Table Of Contents

    SRP-330III/332III Table of Contents Copyright ........................... 3 WARNING & CAUTION ...................... 7 Manual Introduction ......................9 Product Introduction ..................... 10 1. Content Confirmation ....................12 2. Product Part Names ....................13 2-1 Printer Part Names ......................13 2-2 Interface Part Names ..................... 14 2-2-1 USB Interface ......................

  • Page 3: Copyright

    It is strictly prohibited to copy, store, and transmit the whole or any part of the manual and any property of the product without the prior written approval of BIXOLON Co., Ltd. The information contained herein is designed only for use with this BIXOLON product.
  • Page 4 SRP-330III/332III Warning Hazardous moving parts Keep fingers and other body parts away Pull the print head lever can be stop all moving parts. IEC 60417-6057 (2011-05) for other moving parts. Mise en garde Les appareils électroniques, tels que les imprimantes, risquent d'être endommagés par l'électricité...
  • Page 5 SRP-330III/332III Compliance information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 6 SRP-330III/332III Waste Electrical and Electric Equipment (WEEE) This marking shown on the product or its literature, indicates that is should not be disposed with other household wastes at the end of its working life, To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.

  • Page 7: Warning & Caution

    Do not connect multiple products to a Only use authentic products from single or faulty power outlet. Use only BIXOLON. The company will not provide post-sale support for damaged or other grounded power outlets that meet the industry standard. Noncompliance may quality issues that any fake cause electric shock or fire.
  • Page 8 Do not place heavy place of purchase or through objects, liquids, or metals on the product. This could cause damage to BIXOLON website’s product repair the product or a fire. page (http://www.bixolon.com). Ver. 1.00 - 8 -...

  • Page 9: Manual Introduction

    SRP-330III/332III Manual Introduction This manual provides basic information on printers and provides ways to install, use, and check them. In order to protect the safety of users and prevent property damage, be fully familiar with this manual before using the product. Please use it.

  • Page 10: Product Introduction

    SRP-330III/332III Product Introduction SRP-330III/332III printers have been designed to be connected to various types of electronic devices such as POS (Point Of Sales), and computer peripheral devices. The main features of the printer are as follows 1. Maximum 250mm/s printing speed 2.
  • Page 11 SRP-330III/332III Symbol Information DC (Direct current) Error, Warning Paper Feeding Stand-By Ethernet Ver. 1.00 - 11 -...

  • Page 12: Content Confirmation

    SRP-330III/332III 1. Content Confirmation • If there is any part missing, please contact the place of purchase. • The actual part may look different from the image. SRP-330III/332III Cable Cover Installation Guide AC/DC Adaptor Paper Power Cord USB A-B Cable 2-Inch Partition Ver.

  • Page 13: Product Part Names

    SRP-330III/332III 2. Product Part Names 2-1 Printer Part Names Printer Cover Cover-Open Lever Controller Cable Cover Cutter Cover Power Switch Manual Cutter Ver. 1.00 - 13 -...

  • Page 14: Interface Part Names

    SRP-330III/332III 2-2 Interface Part Names • Connect the printer to the host computer using the right interface cable that complies with the specifications of the interface. 2-2-1 USB Interface USB Port Pin No. Signal Name Designation (Color) Function Shell Shield...

  • Page 15: Ethernet Interface

    Transmit + Orange Transmit - White Green Receive + Blue White Blue Green Receive - White Brown Brown Refer to the Network User Manual that is available from the BIXOLON website for more detailed information. Ver. 1.00 - 15 -...

  • Page 16: Serial Interface (Rs-232C)

    SRP-330III/332III 2-2-3 Serial Interface (RS-232C) 2-2-1-1 Single Serial Interface Serial Port Ver. 1.00 - 16 -...
  • Page 17 SRP-330III/332III Pin No. Signal Name Direction Function Frame Ground Output Transmit Data Input Receive Data Output Ready To Send Input Clear To Send Input Data Set Ready Signal Ground Output Data Terminal Ready Connect or disconnect the communication cable while the printer power is off.

  • Page 18: Parallel Interface (Ieee1284)

    SRP-330III/332III 2-2-4 Parallel Interface (IEEE1284) Parallel Port Compatibility Pin No. Source Nibble Mode Byte Mode Mode Host nStrobe HostClk HostClk Host / Printer Data 0(LSB) Data 0(LSB) Host / Printer Data 1 Data 1 Host / Printer Data 2 Data 2...

  • Page 19: Drawer Kick-Out Cable

    SRP-330III/332III 2-2-5 Drawer Kick-out Cable Connect the cash drawer connecting cable to the cash drawer connector located in the back of the printer. Drawer Kick-out Port Pin No. Signal Name Direction Frame Ground Drawer Kick-out Drive Signal 1 Output Drawer Open/Close Signal...

  • Page 20: Installation & Usage

    SRP-330III/332III 3. Installation & Usage 3-1 Printer Installation Placings • Install the printer in a location that meets the following conditions. - Allow sufficient space around the printer for proper ventilation. - Do not place objects close to the back or bottom of the printer, which may hinder the air circulation.

  • Page 21: Power Connection

    SRP-330III/332III 3-2 Power Connection • Face the flat side of the power cable to the bottom of the printer and connect the power cable to the power port. Power Port Power Cable Ver. 1.00 - 21 -...
  • Page 22 SRP-330III/332III - Only use a power supply provided by Bixolon. Bixolon shall bear no responsibility for damage caused by using a third-party power supply. - Check the power supply’s label to check its electronic specs. - When removing the power supply, make sure you have a firm grasp of the plug terminal of the power cable and the printer and pull horizontally.

  • Page 23: Inserting And Changing The Paper Roll

    SRP-330III/332III 3-3 Inserting and changing the paper roll Use paper roll that complies with the specifications If you use a paper roll including paper core attached to paper, the paper may not be properly recognized as paper Empty due to not proper releasing of paper.
  • Page 24 SRP-330III/332III 2) Replace with a new one as shown in the image. 3) Check the orientation of the roll paper when inserting it into the printer. Ver. 1.00 - 24 -...
  • Page 25 SRP-330III/332III 4) Pull out a small amount of paper as shown in the picture, and close the Pinter Cover. When closing the cover, hold down the center of printer cover firmly so that paper roll is loaded correctly. 5) Cut out the paper as indicated.

  • Page 26: Using Controller

    SRP-330III/332III 3-4 Using Controller Controller Explanation Power LED The Power LED light is on whenever the printer is on. Error LED is on when there is an error Error LED such as no paper roll, open cover, etc. Paper LED is on when the paper roll is almost used up or there is no paper roll inside.

  • Page 27: 2-Inch Mounting Partition

    SRP-330III/332III 3-5 2-inch Mounting Partition • When using 2-inch roll paper, mount the partition in the direction of the arrow as shown below. Partition - Do not use 3-inch paper after using 2-inch paper as there may be a decline in print quality.

  • Page 28: Self-Test

    SRP-330III/332III 4. Self-Test The self-test checks whether the printer has any problems. If the self-diagnostics reveal no error in the printer, please see other device or software. If the printer does not run normally, please contact the place of purchase.
  • Page 29 SRP-330III/332III If “VMSM Selection” is selected (1) The following lines will be printed when the VMSM opens. ** VMSM Selection ** 0 : Exit and reboot printer 1 : Print current settings 2 : Set Print Density 3 : Set Print Speed...

  • Page 30: Hexadecimal Dumping

    SRP-330III/332III 5. Hexadecimal Dumping This function allows experienced users to see exactly what data is coming to the printer. This can be useful in finding software problems. When you turn on the hexadecimal dump function, the printer prints all commands and data in hexadecimal format along with a guide section to help you find specific commands.

  • Page 31: Maintenance

    SRP-330III/332III 6. Maintenance 6-1 Paper Jam 1) If paper is stuck, turn the printer ON/OFF and open the cover to remove the crumpled paper inside the printer. If the Printer Cover will not open, please follow the following instructions. 2) Turn the printer OFF.

  • Page 32: Cleaning Printer

    SRP-330III/332III 6-2 Cleaning Printer • The presence of dust, foreign matter, adhesive matter, or other pollutants inside the printer’s head and internal capacity may undermine printing quality. It is recommended to clean printer at every paper roll change. 1) Open the Printer Cover and remove the paper currently in use.

  • Page 33: Specifications

    SRP-332III: 203 dpi(8 dots/mm) 3-Inch: 72mm Printing Width 2-Inch: 48mm 3-Inch: 79.5±0.5mm Paper Width 2-Inch: 57.5±0.5mm SRP-330III: 42(Font A), 56(Font B), 56(Font C) Characters Per Line(Default) SRP-332III: 48(Font A), 64(Font B), 64(Font C) Printing Speed Max. 250 mm/sec Receive Buffer Size 4Kbytes...

  • Page 34: Recommended Papers

    SRP-330III/332III 7-2 Recommended Papers - TF50KS-E (Paper Thickness: 65μm): Nippon Paper Industries Co., Ltd. - PD 150R (Paper Thickness: 75μm): New Oji Paper Mfg. Co., Ltd. - PD 160R (Paper Thickness: 75μm): New Oji Paper Mfg. Co., Ltd. - P350 (Paper Thickness: 62μm): Kansaki Specialty Paper, Inc. (USA) - P220AG (Paper Thickness: 65μm): Mitsubishi Paper Mills Limited...
  • Page 35 SRP-330III/332III Revision history Rev. Date Page Description 1.00 2022-11-23 Ver. 1.00 - 35 -...
