Linksys WIP300 Quick Installation

Package Contents
• Handset
• Power Adapter
• Quick Installation
• User Guide on CD-ROM
• Registration Information Card
Wireless-G
IP Phone
Quick Installation
WIP300
Model
1 Install and Charge the Battery
A C
Remove the battery compartment Replace the battery cover by sliding it
cover by sliding it downwards. upwards until it clicks into place.
D
Connect the small end of the included
power adapter to the USB mini-B port
on the bottom of the Phone.
USB mini-B port
E
Plug the other end of the adapter
into a standard electrical outlet.
You see a charging indicator on the
LCD screen.
IMPORTANT: Allow the battery to
charge for eight hours before initial use.
B
Insert the battery with the metal
contacts facing the contacts at the F
When the battery charging indicator
bottom of the battery compartment.
remains solid blue, the battery is fully
charged and ready for use.
2 Identify the IP Phone's Buttons
Navigation Button: Move the Navigation Clear Button: If you make a mistake while
button up or down to scroll through menus entering information in the Phone, press
and settings. You can also push the the Clear button until the incorrect
Navigation button to select a highlighted characters have been erased. If you need
menu item or setting. to erase all of the characters, press the
Clear button until they are erased.
Navigation button
Clear button
Power/End Call Button: If the Phone is
off, press the Power button once to turn
the Phone on. If the Phone is on, press and Soft Keys: Use the Soft Keys to select
hold the Power button to turn the Phone
menu items directly above the Soft Keys.
off. If you're on a phone call, press the End
Call button to disconnect the call.
Soft Keys
Numeric Keypad: Use the numeric key
Power/End Call button
pad to enter letters and numbers in the
Phone. Press the number keys until the
Call Button: Press the Call button to make letter you want is displayed on the LCD
screen. To switch from entering letters to
or receive phone calls.
numbers, press the left Soft Key. To enter
special characters, press the * (star), #, or
1 keys.
Call button
Numeric Keypad
3 Configure the IP Phone
D
Before you begin, make sure you have an You see a message asking you to
active Internet connection and the account create a password. Press the
information provided by your Internet Navigation button, then use the
phone service provider. numeric keypad to enter a password.
NOTE: The Phone automatically dims
and turns off the LCD display when the
Phone is not in use. If this happens
while you are configuring the Phone,
press any key to turn the display back
on and continue configuring the Phone.
A
Press the Power button to turn on
the Phone.
B
Press the Menu Soft Key.
When you are finished entering a
password, press the Navigation
button to save your password.
NOTE: After you have created a
password, you will need to enter
it to access the Profile menu.
E
Scroll to SIP Account, then press
the Select Soft Key to enter the SIP
Account menu.
C
Scroll to Profile, then press the
Navigation button to enter the
Profile menu.
F
Press the Option Soft Key, then press
the Select Soft Key to edit the default
SIP account.
