Sharp STR3065HS Installation Manual page 5

BEFORE PLACING UNIT
ATTACH MOUNTING CLEATS
All installation options require the use of two 12" (304.8 mm) two-
by-fours as mounting cleats. The two 12" (304.8 mm) two-by-fours
are NOT included and must be supplied by the installer.
NOTE: As with most dimensional lumber, two-by-four boards are
not 2" x 4", because they are milled and paned for consistency. A
two-by-four is actually 1 1 /
2
cleats are 1 1 / " x 3 1 / " x 12" (38.1 mm x 88.9 mm x 304.8 mm).
2 2
1. Pre-drill two holes in each cleat, roughly 3" (76.2 mm) from both
ends.
2. Standard Mount: Position cleats flush with cabinet face.
Flush Mount: Position cleats
cabinet face.
3. Set cleats vertically on the plywood surface with one end flat on
the base. With cleats at the correct depth for your chosen install
option, attach cleats to the sides of the adjacent cabinets with
provided wood screws.
4. Use a framing square or other squaring tool to ensure the cleats
are attached at a 90° angle to the surface. Adjust if necessary.
countertop
mounting cleats
countertop
mounting cleats
surface
wood screws
wood screws
Standard Mount: cleats flush with cabinet face
Flush Mount: cleats
Standard Mount: cleats flush with cabinet face
Flush Mount: cleats
from cabinet face
" x 3 1 / ". The true dimensions of the
2
/ " (20.6 mm) recessed from
13
16
surface
1 / " (89 mm)
3
2
1 / " (89 mm)
3
2 12"
(304.8 mm)
12"
(304.8 mm)
13 / " (20.6 mm) recessed
16
from cabinet face
13 / " (20.6 mm) recessed
16
ATTACH ANTI-TIP BRACKET
To reduce the risk of tipping the drawer due to abnormal use, the
anti-tip bracket must be attached to the plywood surface that will
hold the unit. The bracket location is the same for all installation
options.
Position the bracket 2 11
and 16 1 / " (412.5 mm) from the front of the opening. Attach the
4
bracket with provided screws.
When the unit is installed, a lip on the unit will slide under the
anti-tip bracket and hold the unit in place.
11
2 /
16
(68.4 mm)
Note: If a flush bracket is used, install it
1
17 / " (433.4 mm) from the front of the shelf
16
5
/ " (68.4 mm) from the left adjacent cabinet
16
"
1
16 / "
4
(412.5 mm)
front of shelf
