  • Page 1 Operation manual Daikin Altherma hybrid heat pump EHYHBH05AA Operation manual EHYHBH08AA English Daikin Altherma hybrid heat pump EHYHBX08AA...
  • Page 2: Table Of Contents

    Instant DHW (no tank installed) ........Latest revisions of the supplied documentation may be available on 3.4.2 Tank ................the regional Daikin website or via your installer. Schedules: Example..............Menu structure: Overview user settings ........The original documentation is written in English. All other languages Installer settings: Tables to be filled in by installer ....
  • Page 3: Components In A Typical System Layout

    If you press while changing settings, the changes will NOT be applied. 3.2.2 Status icons Icon Description Space operation mode = Heating. Space operation mode = Cooling. EHYHBH05AAV3* + EHYHBH/X08AAV3* Operation manual Daikin Altherma hybrid heat pump 4P349588-1D – 2016.02...
  • Page 4: Space Heating/Cooling Control

    Actual temperature 20.0°C Depending on your heat  pump model, you have to tell the system Scheduled 17:30 which space operation mode to use: heating or cooling. Actual temperature Operation manual EHYHBH05AAV3* + EHYHBH/X08AAV3* Daikin Altherma hybrid heat pump 4P349588-1D – 2016.02...
  • Page 5: Room Thermostat Control - Using The Leaving Water Temperature Home

    35°C), the DHW  tank heats up until it reaches the reheat set point (example: 45°C). This ensures that a minimum amount of hot water is available at all times. EHYHBH05AAV3* + EHYHBH/X08AAV3* Operation manual Daikin Altherma hybrid heat pump 4P349588-1D – 2016.02...
  • Page 6: Schedules: Example

    1 Go to the DHW tank temperature home page (Tank). 2 Press to select . Schedules: Example INFORMATION The procedures to program other schedules are similar. In this example: ▪ Room temperature schedule in heating mode Operation manual EHYHBH05AAV3* + EHYHBH/X08AAV3* Daikin Altherma hybrid heat pump 4P349588-1D – 2016.02...
  • Page 7: Menu Structure: Overview User Settings

    LWT main LWT additional DHW temp Quiet mode DHW pump Elec price [7.4] Preset values Room temperature LWT main Tank temperature Quiet level Elec price Fuel price EHYHBH05AAV3* + EHYHBH/X08AAV3* Operation manual Daikin Altherma hybrid heat pump 4P349588-1D – 2016.02...
  • Page 8: Installer Settings: Tables To Be Filled In By Installer

    Leaving water temperature: Main zone [A.3.1.1] depends on your user permission level: LWT setpoint mode 1 (Weather dep.) ▪ End user (= default) Leaving water temperature: Additional zone [A.3.1.2] Operation manual EHYHBH05AAV3* + EHYHBH/X08AAV3* Daikin Altherma hybrid heat pump 4P349588-1D – 2016.02...
  • Page 9: Setting The Energy Prices

    Gas price=8.58 INFORMATION Calculation of the electricity price: If no schedule is set, the Elec price for High is taken into account. Electricity price=Actual electricity price+incentive/kWh Electricity price=12.49+5 EHYHBH05AAV3* + EHYHBH/X08AAV3* Operation manual Daikin Altherma hybrid heat pump 4P349588-1D – 2016.02...
  • Page 10: Energy Visualisation

    ▪ If heating up the DHW  tank once at night is not sufficient, program to additionally heat up the DHW tank to a preset value (Storage eco = lower DHW tank temperature) during the day. Operation manual EHYHBH05AAV3* + EHYHBH/X08AAV3* Daikin Altherma hybrid heat pump 4P349588-1D – 2016.02...
  • Page 11: Troubleshooting

    The user interface will then ask you to confirm whether the boiler can take over the entire heat load or not. When the heat pump fails, will appear on the user interface. EHYHBH05AAV3* + EHYHBH/X08AAV3* Operation manual Daikin Altherma hybrid heat pump 4P349588-1D – 2016.02...
