TRACe Subsystem
Commands
TRACe:Clear
TRACe|DATA[:DATA]
<Channel>,<index>{,ASCII Trace Voltages|BINary Indefinite Block
TRACe Voltages>}
<Channel>,<Numeric List of Indices>{,<ASCII Trace Voltages>}
TRACe:POINts<Trace Buffer Points>
TRACe:RFRequency<repeat frequency|OFF>
TRACe:RPERiod<repeat period|OFF>
TRACe:SRATe<sample_rate>
Queries
TRACE|DATA[:DATA]?<Channel Select>|<Numeric List of Indices>
TRACe:INDice?
TRACe:POINts?
TRACe:RFRequency?
TRACe:RPERiod?
TRACe:SRATe?
TRIGger Subsystem
Commands
TRIGger:COUNt <count>
TRIGger([:SEQuence1]|:STARt)[:LAYer]:DELay <time delay>
TRIGger([:SEQuence1]|:STARt)[:LAYer]:ECOunt <event delay>
TRIGger([:SEQuence1]|:STARt)[:LAYer]:HANDshake:POLarity
:REQuest <polarity>
:STRobe <polarity>
TRIGger([:SEQuence1]|:STARt)[:LAYer]:IMMediate
TRIGger([:SEQuence1]|:STARt)[:LAYer]:MODE <mode>
TRIGger([:SEQuence1]|:STARt)[:LAYer]:SOURce <source>
Queries
TRIGger:COUNt?
TRIGger([:SEQuence1]|:STARt)[:LAYer]:DELay?
TRIGger([:SEQuence1]|:STARt)[:LAYer]:ECOunt?
TRIGger([:SEQuence1]|:STARt)[:LAYer]:HANDshake:POLarity
:REQuest?
:STRobe?
TRIGger([:SEQuence1]|:STARt)[:LAYer]:MODE?
TRIGger([:SEQuence1]|:STARt)[:LAYer]:SOURce?
TRIGger([:SEQuence1]|:STARt)[:LAYer]:SOURce:CATAlog[ALL]?
TRIGger([:SEQuence1]|:STARt)[:LAYer]:SOURce:CATalog:DELayable?
TRIGger([:SEQuence1]|:STARt)[:LAYer]:SOURce:CATalog:FIXed?
VX4101A Multipaq
Instrument Reference
23
