PHYSICAL SPECIFICATIONS
The following are physical specifications of the radiographic tables:
Models QT-740 & QT-750 - Service Manual
TABLETOP SPECIFICATIONS
Length:
Width:
Height (Model QT-740):
Height (Model QT-750):
Raised:
Lowered:
Tabletop Travel:
Longitudinal:
Lateral:
Tabletop Motion:
Tabletop Material:
Tabletop X-ray Density:
Tabletop-to-Film Plane
Distance:
TABLE BASE SPECIFICATIONS
Width:
Depth:
Weight Capacity (Max. Patient
Load):
IMAGE RECEPTOR SPECIFICATIONS
Compatible With:
Receptor Longitudinal Travel: 20.0 inches (508.0 mm)
SYSTEM SPECIFICATIONS
Tube Stand Compatibility:
Overall Weight:
Model QT-740:
Model QT-750:
Chapter 1 Specifications
85.0 inches (2159.0 mm)
35.5 inches (901.7 mm)
32.5 inches (825.5 mm)
32.5 inches (825.5 mm)
21.0 inches (533.4 mm)
32 inches (812.8 mm)
10 inches (254 mm)
4-Way Floating
Fiber-resin (phenolic)
<1.0 mm Aluminum
approx. 2.5 inches (63.5 mm)
48.0 inches (1219.2 mm)
26.0 inches (660.4 mm)
650 lbs. (295 kg)
Grid Cabinet, Bucky, ACL Bucky
Compatible with all Quantum Medical Imaging
tube stands and overhead tube cranes
350.0 lbs. (158.8 kg)
500.0 lbs. (226.8 kg)
3
