- Page 1 MO T O R T R O N I C S S o l i d S t a t e A C Mo t o r C o n t r o l M s m a r t M V C 4 Q u i c k S e t u p G u i d e...
- Page 2 Msmart MVC4 Quick Navigation Guide Motortronics Startup Startup “Splash” Screen Click MVC4 Status Status Menu The MVC setpoint pages can be Select MVC Setpoint Page accessed by pressing the button. Select Parameter Set Parameter Value Select parameter Set value press Done to Save www.motortronics.com...
- Page 3 Msmart MVC4 Quick Navigation Guide Motortronics Msmart consist of a touchscreen and four membrane buttons for navigation that can be used when the system is installed in a harsh environment. Touch screen Panel buttons Navigation buttons (Button mode) Msmart Touch Screen Hardware Push Button Description Resets the device on the screen only.
- Page 4 Msmart MVC4 Quick Navigation Guide Motortronics MVC4 Start-up Parameters Verify Setpoint Page 1 • Set Maximum Current • Set Motor Full Load Amps • Set Service Factor • Set Overload Class Consult factory for assistance if parameters don’t match your motor.
- Page 5 MO T O R T R O N I C S S o l i d S t a t e A C Mo t o r C o n t r o l M s m a r t M V C 4 Q u i c k S e t u p G u i d e P h a s e t r o n i c s , I n c .
