Controls

Editing parameters

The Ambika parameters are organized in pages. To jump to a page, press one of the 7
switches S1...S7. Some pages share the same switch ; and you will need to repeatedly
press a switch to cycle between those pages. The active page is indicated by the LEDs
L1...L7 next to the navigation switches.
The following table lists which page is associated with each switch:
Switch Pages
S1 Oscillators, Mixer
S2 Filter
S3 Envelopes and LFOs, voice LFO
S4 Modulation matrix
S5 Keyboard & tuning, sequencer & arpeggiator, sequence editor
S6 Voice and parts mappings, Tempo/clock
S7
Performance, knob assignments
Each page displays up to eight related synthesis parameters. Each parameter can be
edited by turning the knob sitting at its top (for the first row of the display) or at its bottom
(for the second row of the display).
Here is an example:
After having powered up the unit, press S1 to bring the oscillators page. L1 lights up in
green, and the LCD display shows the following parameters:
Wave saw
wave squa
You can use the first row of knobs to edit the shape, parameter, range and detune of the
first oscillator ; and the second row of knobs to edit the shape, parameter, range and
detune of the second oscillator.
| para 0
| para 32
| rang 0
| rang -12
9
| tune 0
| tune 12
