60" Audio Video Tower
If you have any questions regarding assembly or if parts are missing, DO NOT return this item
to the store where it was purchased. Please call our customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Model # ATD60H-13AX
CN Patent CN200920267469.6
ADULT ASSEMBLY REQUIRED
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2018-07-24 Rev. 0001-A Factory: BESBEA
# ATD60H-13AXGR
1-866-942-5362
LOT NUMBER:
DATE PURCHASED:
/
/
Advertisement
Related Manuals for Whalen ATD60H-13AX
Summary of Contents for Whalen ATD60H-13AX
- Page 1 LOT NUMBER: DATE PURCHASED: 60" Audio Video Tower Model # ATD60H-13AX # ATD60H-13AXGR CN Patent CN200920267469.6 ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our customer service number and have your...
- Page 2 M AX I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing CATALOG: 60" Audio Video Tower MODEL # ATD60H-13AX / ATD60H-13AXGR MADE IN CHINA MAXIMUM LOAD 50 lb. (22.6 kg) MAXIMUM LOAD 20 lb.
- Page 3 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Left Leg and Spine Assembly (Qty. 1) B- Right Leg (Qty. 1) C- Shelf Front Stretcher (Qty. 3) D- Top Panel (Qty.
- Page 4 Assembly Instructions 1/4” x 1/2” Bolt (3 used in this step) ① NOTE: Please do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make the assembly easier. 1.
- Page 5 Assembly Instructions 1/4” x 1/2” Bolt (6 used in this step) ① 3. Fit the U-shaped bracket on the three Front Stretchers (C) into the side rails of the leg assemblies with six 1/2” Bolts (1).
- Page 6 Assembly Instructions Handle with Bolts (1 used in this step) ④ 4. Locate the Drawer Box (G) on a scratch free surface as shown. 5. Pull the utility drawer all the way out, then simultaneously push the plastic release lever of the ball bearing slide up on one side and down on the other side, and then pull the drawers completely out.
- Page 7 Assembly Instructions 1/4” x 1-1/4” Bolt (6 used in this step) ② 7. Turn the assembled tower frame at its back edge。 8. Fit the Drawer Box (G) between the legs and press firmly to the bottom metal frame. Fasten the Drawer Box (G) in place with six 1-1/4”...
- Page 8 Assembly Instructions 1/4” x 1-1/4” Bolt (8 used in this step) ② 9. Fit the Top Panel (D) and Middle Fixed Shelf (E) onto the assembled shelf frames properly so that the threaded inserts underneath shelf overlap the drilled holes on the Shelf Frames. Insert four 1-1/4”...
- Page 9 Assembly Instructions 1/4” x 1/2” Bolt Metal Bracket (4 used in this step) (2 used in this step) ① ⑤ 10. Fasten two Metal Brackets (5) to the Spine (A) at the desire height using four 1/2” Bolts (1). Make sure that the right-angle side of Metal Bracket will face upward when the unit is turned upright.
- Page 10 Assembly Instructions 1/4” x 1/2” Bolt Shelf Pin (4 used in this step) (4 used in this step) ① ③ 11. Insert four Shelf Pins (3) into the proper hole sets on the inner side of legs. Be sure the Shelf Pins and the installed Metal Brackets (5) are at the same level, so that they will hold the Shelves (F) properly.
- Page 11 Assembly Instructions 13. Go back and securely tighten all the bolts with the enclosed hex wrench. Ask for assistance to stand the unit upright. 14. Insert the removed drawer into the Drawer Box (G). To place the drawer back, simply push the ball bearing cart all the way to the end of the slides (in both sides), and then align the slide runners on the drawer with the slide tracks on the unit and push it carefully inside until it stops.
- Page 12 Assembly Instructions 1/4” x 1/2” Bolt (4 used in this step) ① 15. Attach two Cable Wheels (H) to the backside of the Spine (A) with four 1/2” Bolts (1). Tighten the bolts with the enclosed hex wrench. NOTE: You can use the Cable Wheels to help keep your entertainment center’s cables and cords organized.
- Page 13 Assembly Instructions Tools required: Hex wrench (provided), Phillips screwdriver, mallet, power drill, and 1/8” drill bit. 16. Position the assembled unit at the desired location against a wall. If necessary, adjust the pre-attached Floor Levelers at the bottom of the Legs to level the unit. Now, follow the instructions printed on the plastic bag containing the Tipping Restraint Hardware to attach the tip-over restraint to the unit and the wall.
-
Page 14: Care And Maintenance
Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
