Table Top Console
Model # AVCEC65-TC
ADULT ASSEMBLY REQUIRED
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to
the store where it was purchased. Please call our customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Whalen Furniture Mfg., Inc.
1-866-942-5362
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com
Date 2014-06-04 Rev. 2
LOT NUMBER:
DATE PURCHASED:
Page 1
/
/
Factory: FOCIDI
Advertisement
Related Manuals for Whalen AVCEC65-TC
Summary of Contents for Whalen AVCEC65-TC
- Page 1 LOT NUMBER: DATE PURCHASED: Table Top Console Model # AVCEC65-TC ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our customer service number and have your...
- Page 2 M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Mfg., Inc. CATALOG: Table Top Console (AVCEC65-TC) DATE OF MANUFACTURE: July 2014 MADE IN CHINA FITS UP TO MOST 65”...
- Page 3 Model # AVCEC65-TC Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Top Shelf Frame (1) B- Middle Shelf Frame (1) C- Bottom Shelf Frame (1)
- Page 4 Model # AVCEC65-TC Assembly Instructions Flat Washer 1-1/4” Bolt Lock Washer (2 used in this step) (6 used in this step) (2 used in this step) ④ ⑦ ⑥ NOTE: Please do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts.
- Page 5 Model # AVCEC65-TC Assembly Instructions 5/8” Bolt Lock Washer Flat Washer (3 used in this step) (3 used in this step) (3 used in this step) ⑥ ⑦ ② 4. Align and attach Top Shelf Middle Support (J) to connect the middle rail of the Top Shelf Frame (A) with the Spine (D), using three 5/8”...
- Page 6 Model # AVCEC65-TC Assembly Instructions 7/8” Bolt (4 used in this step) ③ 5. Align and attach Left Leg (E) to the Lower Shelf Frames (B and C) with two 7/8” Bolts (3). tighten the bolts. Make sure that the pre-drilled hole on the back rail of the Top Shelf Frame (A) overlaps the top threaded socket on the Left Leg (E).
- Page 7 Model # AVCEC65-TC Assembly Instructions 1-1/8” Bolt (2 used in this step) ⑤ 7. Stand the unit upright. 8. Insert two 1-1/8” Bolts (5) through the pre-drilled holes on the back rail of the Top Shelf Frame (A) and screw into the threaded sockets on the Legs (E and F).
- Page 8 Model # AVCEC65-TC Assembly Instructions Lock Washer 5/8” Bolt (2 used in this step) (2 used in this step) ⑥ ② Flat Washer (2 used in this step) ⑦ 1-1/8” Bolt (2 used in this step) ⑤ 9. Align and attach one Top Shelf Side Support (K) to the “L” bracket of the Top Shelf Frame (A) using one 5/8”...
- Page 9 Model # AVCEC65-TC Assembly Instructions 5/8” Bolt (4 used in this step) ② 11. Attach 2 Cable Wheels (L) to the backside of the Spine (D) and tighten with the enclosed Allen Wrench. 12. The Cable Wheels allow you to organize, route and separate your component cords and cables to minimize tangling and signal interference.
- Page 10 Model # AVCEC65-TC Assembly Instructions A/B/C Suction Cup (24 used in this step) ① 14. Put the Suction Cups (1) firmly into the top holes and the metal tabs on the Shelf Frames (A, B and C). TIP: If a suction cup resists insertion, try pressing down on the middle of the cup with the Allen Wrench while twisting it clockwise into the hole.
- Page 11 Model # AVCEC65-TC Assembly Instructions Tools required: Allen Wrench (provided), Phillips screwdriver, Mallet, Power Drill, and 3/8” Drill Bit. 16. Position the assembled console at the desired location against a wall. If necessary, adjust the pre-attached Floor Levelers on the bottom of the Legs (E and F) to level the console.
-
Page 12: Care And Maintenance
