If you have any questions regarding assembly or if parts are missing, DO NOT return this item
to the store where it was purchased. Please call our customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
Or e-mail your request to parts@whalenfurniture.com
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
78" TV Stand
Model # AVC78H-13AX
# AVC78H-13AXGR
CN Patent CN200920267469.6
ADULT ASSEMBLY REQUIRED
1-866-942-5362
www.whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2018-07-27 Rev. 0001-A Factory: DONAFU
LOT NUMBER:
DATE PURCHASED: /
/
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Whalen AVC78H-13AX
Summary of Contents for Whalen AVC78H-13AX
- Page 1 LOT NUMBER: DATE PURCHASED: / 78” TV Stand Model # AVC78H-13AX # AVC78H-13AXGR CN Patent CN200920267469.6 ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our customer service number and have your...
- Page 2 M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing CATALOG: 78” TV Stand MODEL # AVC78H-13AX / AVC78H-13AXGR MADE IN CHINA FITS UP TO MOST 84” FLAT PANEL TVs MAXIMUM LOAD 135 lb.
- Page 3 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Spine and Legs Assembly (Qty. 1) B- Top Panel (Qty. 1) C- Lower Shelf (Qty. 2) D- Top Shelf Frame Front Assembly (Qty.
- Page 4 Assembly Instructions NOTE: Please do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make the assembly easier. 1. Unpack the unit and confirm that you have all the hardware and required parts. 2.
- Page 5 Assembly Instructions D/E/F 1/4” x 1/2” Bolt (8 used in this step) ① 5. Turn the unit at its back edge. 6. Fasten the Top and Bottom Shelf Frame Front Assemblies (D and F) and the Middle Shelf Frame Front Stretcher (E) in place with eight 1/2” Bolts (1). DO NOT fully tighten the bolts in this step.
- Page 6 Assembly Instructions 1/4” x 1 1/4” Bolt (3 used in this step) ② Flat Washer Lock Washer 1/4” x 1 3/4” Bolt (6 used in this step) (6 used in this step) (3 used in this step) ④ ⑤ ③ 7.
- Page 7 Assembly Instructions 1/4” x 1/2” Bolt Flat Washer Lock Washer (3 used in this step) (3 used in this step) (3 used in this step) ① ④ ⑤ 8. Attach the Top Shelf Support (G) between the Spine (A) and the Top Shelf Frame Front Assembly (D) with three 1/2”...
- Page 8 Assembly Instructions A/E/F Flat Washer 1/4” x 1 1/4” Bolt Lock Washer (12 used in this step) (12 used in this step) (12 used in this step) ④ ⑤ ② 9. Fit the Lower Shelves (C) onto the Shelf Frames properly so that the threaded inserts underneath Shelves overlap the drilled holes on the Shelf Frames.
- Page 9 Assembly Instructions 1/4” x 1/2” Bolt (4 used in this step) ① 10. Stand the unit upright. 11. Attach two Cable Wheels (H) to the backside of the Spine (A) with four 1/2” Bolts (1). Tighten the bolts with the provided hex wrench. NOTE: You can use the Cable Wheels to help keep your entertainment center’s cables and cords organized.
- Page 10 Assembly Instructions o prevent the TV from tipping, you must install the acrylic stopper when placing NOTE: T your flat panel television on the top panel.Otherwise, skip to step 13. 12. Remove the paper backing from the Acrylic Stopper (6), then properly align the acrylic stopper into the cut-out on the acrylic stopper template on the front of Top Panel (B).
- Page 11 Assembly Instructions Tools required: Hex wrench (provided), Phillips screwdriver, stud finder, power drill and 1/8" drill bit (not provided). 14. Ask for assistance to position the unit at the desired location against a wall. 15. Follow the instructions printed on the plastic bag containing the Tipping Restraint Hardware to attach the tip-over restraints to the unit and the wall.
-
Page 12: Care And Maintenance
Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
