Manual
TV Console
Model # AVCBEC60-SMB
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our customer service number and have your instructions and
parts list ready to provide the model name, part name or factory number:
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Whalen Furniture Manufacturing
ADULT ASSEMBLY REQUIRED
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com
Date 2014-10-27 Rev. 1 Factory: KONRIC
1-866-942-5362
Page 1
LOT NUMBER:
DATE PURCHASED: /
Factory No. 16086
/
Advertisement
Related Manuals for Whalen AVCBEC60-SMB
Summary of Contents for Whalen AVCBEC60-SMB
- Page 1 LOT NUMBER: DATE PURCHASED: / TV Console Model # AVCBEC60-SMB ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our customer service number and have your instructions and...
- Page 2 M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing CATALOG: TV Console (AVCBEC60-SMB) DATE OF MANUFACTURE: October 2014 MADE IN CHINA FITS UP TO MOST 70”...
- Page 3 Model # AVCBEC60-SMB Important Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non- abrasive surface. You will need the parts identified on page 4 of this instruction manual. NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH DOWELS.
- Page 4 Model # AVCBEC60-SMB Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Top Panel (1) B- Side Panel (2) C- Left Partition Panel (1) D- Right Partition Panel (1)
- Page 5 Model # AVCBEC60-SMB Assembly Instructions Cam Bolt (12 used in this step) ② 1. Unpack the unit and confirm that you have all the hardware and required parts. Assembly the unit on a carpeted floor or the empty carton to avoid any scratch.
- Page 6 Model # AVCBEC60-SMB Assembly Instructions Cam Lock (4 used in this step) ① M8 x 30 mm Wood Dowel (4 used in this step) ③ 3. Insert two Wood Dowels (3) into the inner end holes of each Side Panel (B). Tap in with a rubber mallet, if necessary.
- Page 7 Model # AVCBEC60-SMB Assembly Instructions FRONT FRONT M4 x 40 mm Wood Screw M8 x 30 mm Wood Dowel (4 used in this step) (4 used in this step) ⑤ ③ 6. Insert two Wood Dowels (3) into the inner holes on the bottom edge of each Partition Panel (C and D) and fasten them to the Base (E) with four M4 x 40 mm Wood Screws (5), as shown.
- Page 8 Model # AVCBEC60-SMB Assembly Instructions Cam Lock M8 x 30 mm Wood Dowel (8 used in this step) (8 used in this step) ③ ① 7. Insert eight Wood Dowels (3) into the inner holes on the top edge of Side Panels (B) and Partition Panels (C and D).
- Page 9 Model # AVCBEC60-SMB Assembly Instructions M3.5 x 16 mm Washer Head Screw (24 used in this step) ④ 9. Stand the assembled unit upright. 10. Now, go back and securely tighten all the Cam Locks and Wood Screws. Make sure all the parts are tight and there are no gaps between the pieces.
- Page 10 Model # AVCBEC60-SMB Assembly Instructions Ø1/4" x 3/4" Bolt (4 used in this step) ⑧ 12. Attach two Cable Wheels (J) to the threaded inserts on the back side of Partition Panels (C and D) with four 3/4” Bolts (8). You can use the Cable Wheels to organize your cables and cords.
- Page 11 Model # AVCBEC60-SMB Assembly Instructions B/C/D Shelf Pin Cam Lock Cover (24 used in this step) (14 used in this step) ⑩ ⑨ 13. Insert eight Shelf Pins (9) into the desired holes in the sides of each compartment. Make sure you place the four Shelf Pins in the same level so the shelf is not tilted.
- Page 12 Model # AVCBEC60-SMB Assembly Instructions 15. Extend the two Hinge Arms that are pre-attached on one Door (F) and attach them to the Hinge Bases on one Side Panel (B). Loosen the bolt on the back of Hinge Base for an easy fit. Align and insert the “U”...
- Page 13 Model # AVCBEC60-SMB Assembly Instructions Knob Knob Bolt Rubber Pad (2 used in this step) (2 used in this step) (4 used in this step) ⑥ ⑫ ⑦ 18. Open the doors and attach one Knob (6) to the front side of each door with the provided Knob Bolt (7).
- Page 14 Model # AVCBEC60-SMB Assembly Instructions Acrylic Stopper (1 used in this step) ⑪ NOTE: You must install the Acrylic TV Stopper to prevent the TV from tipping when placing your flat panel television directly on the console. 20. Remove the paper backing of Acrylic Stopper (11), then properly align the Acrylic Stopper into the cut-out on the acrylic stopper template on the front of the Top Panel (A).
- Page 15 Model # AVCBEC60-SMB Assembly Instructions Tools required: Phillips screwdriver, Power Drill, 3/8” Drill Bit and Rubber Mallet. 22. Position the assembled unit at the desired location against a wall. If necessary, adjust the pre-attached Floor Levelers at the bottom of the Base (E) to level the unit. Now, follow the instructions printed on the plastic bag containing the Tipping Restraint Hardware to attach the tip-over restraint to the Table and the wall.
-
Page 16: Quality Guarantee
Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
