Print defects guide

Match a set of repeating defects on a print job to the marks on one of the vertical lines. The line that best
matches the defects on the print job indicates which particular part may be causing the defect.
For example, the distance between these two marks represents
a repeating defect that occurs every 28.3 mm (1.11 in.), which
means the charge rollers may need to be replaced.
Replace the
transfer roller
(2.04 in.)
Replace the
charge rollers
28.3 mm
(1.11 in.)
Note: If the defect appears on the printed side of a single-sided print
Replace the toner cartridge
47.8 mm
(1.88 in.)
51.7 mm
job, replace the toner cartridge before replacing the fuser.
96.8 mm
(3.81 in.)
Print defects guide
Page 1 of 1
Replace the fuser
95.2 mm
88.0 mm
(3.75 in.)
(3.46 in.)
