LIFEPAK 15 Monitor/Defibrillator
LIFEPAK
Monitor/Defibrillator
Pocket
15
®
guide
This is not the complete instructions
for use. Refer to the Operating
Instructions for complete device
information including directions
for use, indications and warnings.
Page A

Advertisement

Table of Contents
loading

Related Manuals for Stryker LIFEPAK 15

Summary of Contents for Stryker LIFEPAK 15

  • Page 1 LIFEPAK 15 Monitor/Defibrillator LIFEPAK ® Monitor/Defibrillator Pocket guide This is not the complete instructions for use. Refer to the Operating Instructions for complete device information including directions for use, indications and warnings. Page A...

  • Page 3: Home Screen

    LIFEPAK 15 Monitor/Defibrillator Home screen Time ® Bluetooth indicator Alarm limits Heart symbol Battery indicator Selected energy Alarm indicator Heart rate ECG Lead/Size SPO2 SpO2/SpCO/ Channel 1 SpMet mmHg EtCO mmHg Channel 2 or temperature mmHg Channel 3 NIBP mmHg...
  • Page 4 LIFEPAK 15 Monitor/Defibrillator QUIK-COMBO Electrodes ® with REDI-PAK preconnect system • Reads ECG with lead II • Delivers defibrillation shock • Delivers external pacing Connecting therapy electrodes Anterior Therapy cable QUIK-COMBO QUIK-COMBO Lateral connector electrode connector Therapy Electrodes Connecting therapy cable to defibrillator...
  • Page 5 LIFEPAK 15 Monitor/Defibrillator Manual defibrillation controls GREEN ON button turns device on and off ENERGY SELECT increases or decreases energy level while in Manual Mode CHARGE charges the device in Manual Mode SHOCK initiates discharge of the defibrillator energy to the patient...

  • Page 6: Noninvasive Pacing Procedure

    LIFEPAK 15 Monitor/Defibrillator Noninvasive pacing procedure Demand pacing 1. Press ON 2. Apply ECG electrodes 3. Apply and connect QUIK-COMBO therapy electrodes; ® consider sedation if patient is conscious 4. Press PACER 5. Confirm placement of the sense marker ( ) is near the middle of each QRS 6.
  • Page 7 LIFEPAK 15 Monitor/Defibrillator Other features, right side Control Description NIBP Initiates blood pressure measurement. LED illuminated when BP measurement is being obtained. ALARMS Activates and silences alarms. LED illuminated when alarms are enabled and flashes when an alarm condition occurs.
  • Page 8 LIFEPAK 15 Monitor/Defibrillator Noninvasive blood pressure monitoring procedure NIBP measurement typically takes 40 seconds to complete. If the measurement is not completed in 120 seconds, the cuff automatically deflates. 1. Press ON 2. Select appropriate sized cuff, attach snugly to extremity;...
  • Page 9 LIFEPAK 15 Monitor/Defibrillator Features, left side, Invasive pressure option Connection Action Connect: Open CO port door, insert FilterLine ® connector and turn clockwise until connector is firmly seated. Disconnect: Rotate FilterLine connector counterclockwise and pull connector out. Connect: Align cable connector with SpO port and push in until connector clicks into place.
  • Page 10 LIFEPAK 15 Monitor/Defibrillator Features, left side, Continuous temperature option Connection Action Connect: Open CO2 port door, insert FilterLine connector, and turn clockwise until connector is firmly seated. Disconnect: Rotate FilterLine connector counterclockwise and pull connector out. Connect: Align cable connector with SpO port and push in until connector clicks into place.

  • Page 11: Acquiring A 12-Lead Ecg

    LIFEPAK 15 Monitor/Defibrillator Acquiring a 12-Lead ECG 1. Press 12-LEAD Button Main Cable 2. AGE Menu – enter Age (4-wire) Protective 3. SEX Menu – enter Sex flap (open) 4. 12-Lead acquires, analyses and automatically prints the 12-Lead ECG Precordial lead...
  • Page 12 LIFEPAK 15 Monitor/Defibrillator EtCO monitoring procedure SpO2 1. Press 2. Select appropriate EtCO accessory for the patient 3. Open CO port door and insert FilterLine connector, turn connector clockwise until tight NIBP 4. Verify CO area is displayed 5. Display CO waveform in Channel 2 or 3 6.
  • Page 13 LIFEPAK 15 Monitor/Defibrillator / SpCO / SpMet SpO2 monitoring procedure NIBP SpCO & SpMet 1. Press ON Perform steps 1-5, then: 2. Connect the pulse 6. Verify that SpCO / SpMet oximeter cable to the sensor is in use; ONLY...

  • Page 14: Invasive Pressure Monitoring

    LIFEPAK 15 Monitor/Defibrillator Invasive pressure monitoring Label Description Arterial Pressure Pulmonary Artery Pressure Central Venous Pressure Intracranial Pressure Left Atrial Pressure Page 12...
  • Page 15 LIFEPAK 15 Monitor/Defibrillator Invasive pressure monitoring procedure 1. Prepare transducer system according to local protocol 2. Position transducer at the patients phlebostatic axis – zero-reference 3. Press ON 4. Connect IP cable to the transducer and to the port on the...

  • Page 16: Monitoring Continuous Temperature

    LIFEPAK 15 Monitor/Defibrillator Monitoring continuous temperature 1. Press ON 2. Connect adapter cable to TEMP port on monitor 3. Connect temperature probe to adapter cable 4. Attach temperature probe to patient according to probe Instructions for Use 5. Confirm temperature reading appears and is stable Note: The temperature probe may require three minutes to equilibrate after patient placement.
  • Page 17 LIFEPAK 15 Monitor/Defibrillator Auxiliary power management 1. Connect power cord to power adapter and auxiliary power source 2. Confirm LED strip on power adapter is illuminated 3. Connect power adapter output cable to power adapter 4. Connect green end of output cable to auxiliary power connector on back of defibrillator 5.

  • Page 18: Battery Power Management

    LIFEPAK 15 Monitor/Defibrillator Battery power management 1. Install batteries in battery wells 1 and 2 2. Press ON 3. Check battery indicators for charge level of each battery 4. If battery is low, replace with charged battery or connect defibrillator to auxiliary power using...
  • Page 19 5. Do not use alcohol, tincture of benzoin or antiperspirant to prep the skin 6. Discard the electrode if gel is not intact or Use By date has passed Troubleshooting Tips For a complete list of troubleshooting tips, please consult the LIFEPAK 15 Operating Instructions Page 17...

  • Page 20: Manual Defibrillation

    • Review skin prep section and reapply PADDLES LEADS new electrodes OFF message appears • Replace damaged therapy cable and perform daily checks per Operator’s Checklist Troubleshooting Tips For a complete list of troubleshooting tips, please consult the LIFEPAK 15 Operating Instructions Page 18...

  • Page 21: Ecg Monitoring

    LEADS connected to ECG cable. Select one of the OFF message when limb or precordial leads. ECG electrodes are connected Troubleshooting Tips For a complete list of troubleshooting tips, please consult the LIFEPAK 15 Operating Instructions Page 19...
  • Page 22 • Encourage patient to lie quietly • Stop vehicle while acquiring 12-lead ECG data EXCESSIVE Press 12-LEAD to acquire another 12-lead NOISE-12-LEAD CANCELLED Troubleshooting Tips For a complete list of troubleshooting tips, please consult the LIFEPAK 15 Operating Instructions Page 20...
  • Page 23 (I, II or III) Intrinsic QRS • Increase ECG size or select another lead complexes not sensed • Adjust PPM when pacing Troubleshooting Tips For a complete list of troubleshooting tips, please consult the LIFEPAK 15 Operating Instructions Page 21...
  • Page 24 • Apply appropriately sized cuff and properly align cuff artery markings to extremity • Check that cuff/monitor connection is secure • Check cuff for leaks Troubleshooting Tips For a complete list of troubleshooting tips, please consult the LIFEPAK 15 Operating Instructions Page 22...
  • Page 25 • Valid breaths must be detected in order for the no breath alarm to function and count the respiratory rate (RR) • The RR represents an average over the last 8 breaths Troubleshooting Tips For a complete list of troubleshooting tips, please consult the LIFEPAK 15 Operating Instructions Page 23...
  • Page 26 FilterLine set is (---) XXX appears instead of Turn device off then on again. If EtCO value problem persists, contact qualified service personnel. Troubleshooting Tips For a complete list of troubleshooting tips, please consult the LIFEPAK 15 Operating Instructions Page 24...
  • Page 27 Unexpected In addition to above troubleshooting readings methods, take readings on 3 separate digits and average readings Troubleshooting Tips For a complete list of troubleshooting tips, please consult the LIFEPAK 15 Operating Instructions Page 25...
  • Page 28 • Change catheter tip position • Use mean pressure values • Check the stopcock position. Replace any Inability to zero defective stopcocks. system • Replace transducer Troubleshooting Tips For a complete list of troubleshooting tips, please consult the LIFEPAK 15 Operating Instructions Page 26...
  • Page 29 NOTE: The temperature probe may require 3 minutes to equilibrate after placement on the patient monitoring site. Troubleshooting Tips For a complete list of troubleshooting tips, please consult the LIFEPAK 15 Operating Instructions Page 27...
  • Page 30 Refer to operating instructions for complete directions for use indications, contraindications, warnings, cautions, and potential adverse events. Physio-Control is now part of Stryker. For further information, please contact Physio- Control at 800.442.1142 (U.S.), 800.668.8323 (Canada) or visit our website at www.physio-control.com...
