Stryker LUCAS 3 Implementation Manual

Chest compression system, v3.1
Hide thumbs Also See for LUCAS 3:

Advertisement

Quick Links

See also: Service Manual
LUCAS
®
Chest Compression System, v3.1
Implementation
3
The LUCAS
3 device, version 3.1 with
®
wireless connectivity to the LIFENET
System, allows for device configuration,
post-event reporting and asset management.
This Implementation Guide provides a
comprehensive step by step instruction
on how to configure the LUCAS device for
Wi-Fi, assign setup options and define e-mail
addresses to receive reports and notfications.
Guide
®

Advertisement

loading
Need help?

Need help?

Do you have a question about the LUCAS 3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Stryker LUCAS 3

Summary of Contents for Stryker LUCAS 3

  • Page 1 LUCAS ® Chest Compression System, v3.1 Implementation Guide The LUCAS 3 device, version 3.1 with ® wireless connectivity to the LIFENET ® System, allows for device configuration, post-event reporting and asset management. This Implementation Guide provides a comprehensive step by step instruction on how to configure the LUCAS device for Wi-Fi, assign setup options and define e-mail addresses to receive reports and notfications.

  • Page 2: Table Of Contents

    Contents Step 1: LIFENET user account ................ 1 Step 2: Defining LUCAS device setup options ..........1 Step 3: Configuring the LUCAS device for Wi-Fi .......... 4 Step 4: Checking in LUCAS to LIFENET............11 Step 5: Assigning new setup options ............12 Step 6: LUCAS Post-Event Report ..............

  • Page 3: Step 1: Lifenet User Account

    Edit Setup Options * LUCAS factory default settings are consistent with 2015 AHA and ERC guidelines for CPR. Please refer to the LUCAS 3, v3.1 Instructions for Use 101034-00, chapter 9, for a complete description. Use the “LUCAS 3, v3.1 Defining setup options GDR 3336793” flyer to get an overview and to help define the setup options.
  • Page 4 NOTE: The LUCAS device is delivered with factory default settings and the existing name for this setup options profile is ”LUCAS 3 – 3.1 – Default Profile”. You can change the setup options profile name in navigation step 1 (see above image).
  • Page 5 Back to contents • If you have not yet registered any LUCAS 3, v3.1 device on your LIFENET account the navigation step 8 “Assign to Devices” will be empty. Skip this step, and continue to step 9 “Summary”. Review your setups, then check the box “Assign as default profile to new devices”...

  • Page 6: Step 3: Configuring The Lucas Device For Wi-Fi

    A few steps ® are required to configure and enable LUCAS Wi-Fi. To configure the LUCAS device/s for Wi-Fi you will need to have the following: Your LUCAS 3 v3.1 device/s Your local Wi-Fi information SSID (Wi-Fi name) –...
  • Page 7 Back to contents • Use the same credentials that you use to log into your LIFENET account. This is the LIFENET account on which your LUCAS device/s will be registered and connect to. First time you run the Wi-Fi Configuration Tool.
  • Page 8 (means it is searching for Bluetooth connection). After a while you should see the serial number of your LUCAS 3, v3.1 device appearing on your Wi-Fi Configuration Tool screen. NOTE: This may take up to 2 minutes. Page 6...
  • Page 9 Back to contents • Select the serial number of the LUCAS device you want to connect and click ”Next”. You can find the serial number on the inside of LUCAS support leg. Troubleshooting If no LUCAS device/s is/are detected; 1. Ensure that the Bluetooth LED on LUCAS user interface is blinking, if not, go back to previous step to initiate the LUCAS Bluetooth connection.
  • Page 10 Back to contents • Click ”Next” • Choose a network Advanced Setup; this is used for customers who need to set up enterprise security or when adding multiple Wi-Fis. Page 8...
  • Page 11 Back to contents • In this case ”physio-guest” was selected • Fill in ”Security key” • Click ”Test Connection” before you go to ”Next”. By doing this you are testing the network connection is functioning. Page 9...
  • Page 12 LUCAS 3 device for Wi-Fi, check this box. If your are finished, check this box instead and close the Wi-Fi Configuration Tool. NOTE: You need to run the Wi-Fi Configuration Tool for each LUCAS 3, v3.1 device you want to configure to Wi-Fi.

  • Page 13: Step 4: Checking In Lucas To Lifenet

    Back to contents Important: By finishing the Wi-Fi Configuration Tool, you have now established a Wi-Fi connection with LIFENET and the LUCAS device but you have not yet exchanged any device or setup data between LIFENET and LUCAS (i.e. ”checked in” LUCAS to LIFENET). You will see your LUCAS device registered in your LIFENET account under the Asset menu, but there is no LUCAS data or setup information yet.

  • Page 14: Step 5: Assigning New Setup Options

    Back to contents Step 5: Assigning new setup options If you defined the LUCAS device setup options in your LIFENET account prior to the Wi-Fi configuration (see step 2 in this Guide) and the ”Assign as default profile for new devices”...
  • Page 15 Back to contents 3. Check in your LUCAS device to receive its new setup options profile. 1. Make sure the LUCAS device is powered OFF. 2. Press TRANSMIT key on the LUCAS device. 3. The LUCAS device will check in to LIFENET Asset via Wi-Fi and get the assigned setup options profile.

  • Page 16: Step 6: Lucas Post-Event Report

    Back to contents Step 6: LUCAS Post-Event Report After each LUCAS use where a compression was delivered, the LUCAS device can transmit data to LIFENET and create a LUCAS device Post-Event Report. This report can be delivered automatically to any pre-designated email address(es). •...

  • Page 17: Step 7: Lifenet Asset Notifications

    Back to contents • To add additional e-mail recipients go to “Account / Users” and then select “Add User”. You can create a LUCAS Report User profile and add multiple e-mail addresses to receive the Post-Event Report. • To activate or deactivate the LUCAS Post-Event Report e-mail, go to “My Settings / My Notifications”...
  • Page 18 Back to contents Support Resources • Please refer to the LUCAS 3 Chest Compression System Instructions for Use (version 3.1) 101034-01 for complete directions for use indications, contraindications, warnings, cautions, and potential adverse events. The Instructions for Use are included with your device or can be obtained at www.physio-control.com/LUCAS.
