ureach Mini SAS Series User Manual

1-1 duplicator and sanitizer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Mini SAS Series
SAS-MS118
1-1 Duplicator and Sanitizer
User Manual
V A.02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mini SAS Series and is the answer not in the manual?

Questions and answers

Related Manuals for ureach Mini SAS Series

Summary of Contents for ureach Mini SAS Series

  • Page 1 Mini SAS Series SAS-MS118 1-1 Duplicator and Sanitizer User Manual V A.02...

  • Page 2: Table Of Contents

    Index SAS-MS118 v A.02 Product Disclaimer ........................2 Warranty ............................2 Piracy Statement ........................2 Before You Start .........................3 Notice Symbols ..........................3 Product Overview ........................4 Function Table ...........................5 Function Introduction ........................8 1. Copy ..........................8 2. Compare ..........................9 3. Copy+Compare .........................9 4. Erase ..........................9 5.

  • Page 3: Product Disclaimer

    Product Disclaimer U-Reach is not accountable for any incidental or consequential damages, which includes, but is not constrained to property harm, loss of time or data from use of a U-Reach product, or any other damages attributable to product malfunction or failure (including without limitation, those attributable to: (1) reliance of the materials provided, (2) costs of product replacement, (3) loss of use, data or profits, (4) delays or business interruptions, (5) and any principle of legal...

  • Page 4: Before You Start

    Before You Start Important Notice Carefully read the entire manual before operating. ● Make sure the source device is correct and functioning. ● Equal capacity of source and target is recommended for guaranteed data consistency. ● Using the Copy+Compare function provides the most flawless duplication. ●...

  • Page 5: Product Overview

    Product Overview A. System Overview Red: Fail Green: Pass Yellow: Powering Backward Forward Confirm / OK Cancel / Back B. LCD Configuration Function Target HDD Total size (Source) Copy 2047M 0:11 0:11 860M Copied Processed size (Target) Copy Progress % Time (mm:ss)

  • Page 6: Function Table

    Function Table Function Item & Description Copies source device to connected target device(s). Refer to function 1. Copy 6.1 Copy Area for 4 different copy modes. 2. Compare Verifies target device(s) bit by bit to the master device. 3. Copy Automates copy and compare by first duplicating and then verifying all +Compare the data, bit by bit.
  • Page 7 5.2.2 Create Update HDD Formats HDD with a 2GB FAT partition for the operator to save the new firmware. 5.3 System Info Displays information of the duplicator system, including controller model number and firmware version. 5.4 Read Speed Performs a full reading speed test on the desired, connected device(s). 5.5 Write Speed Performs a full writing speed test on the desired, connected device(s).
  • Page 8 Setting Target HPA Copies HPA setting from source device to target. Copy and Setting Copies HPA setting and data from source device to target. 6.4 Skip Bad Sectors Sets the number of bad sectors to skip. (0-65535 or unlimited) 6.5 Erase Master Allows user to erase the source port or not.

  • Page 9: Function Introduction

    Function Introduction 1. Copy The copy function copies data from source HDD to target HDD. You can set following settings before copy. (You can check more detail in ”6. Setup”.) I. Set Copy Area of Source HDD → 6.1 Copy Area II.

  • Page 10: Compare

    Step 4: Completion! The copy result (Pass/Fail), total copy time and bad sectors will show on LCD. Copy result Total copy time Pass 0:05 Pass No Bad Sector! Fail 0:05 Fail Bad Sector R0 W1 The default setting of error counter is 0. If users want to adjust Note the accepted error sectors of the HDD, they can set "Skip Bad Sectors".
  • Page 11 I. Set Erase mode II. Set Erase Master → 6.5 Erase Master III. Set Erase Pattern → 6.7 Erase Pattern It will erase the data in the HDD, please make sure you back up Caution all important data before using this function. ➢...
  • Page 12 This function will erase the whole sectors on the connected device(s). It will take longer than quick erase. Complies with NIST800-88 Standards. 4.3 DoD Erase This function complies with the U.S.A. Department of Defense (DoD5220.22-M) standard to fully erase the HDD three times bit by bit to overwrite HDD data and guarantees data will not be recoverable.

  • Page 13: Utility

    4.8 Block Erase Performs Secure Erase for SAS HDD. 4.9 Overwrite Performs Enhanced Secure Erase for SAS HDD. 5. Utility 5.1 Show Disk Info. This function will show HDD's S.M.A.R.T information. After selecting the port, press ▼ to check detail information. ◼...
  • Page 14 5.2 Update System Step 1: Create an Update HDD Connect a SDD/HDD to the duplicator. Select function "5.2 Create Update HDD". Step 2: Format BIOS HDD Click "OK" to format the BIOS hard disk. One FAT, 2GB partition will be formatted on the HDD.

  • Page 15: Setup

    Measures the writing speed of the HDD by writing the whole HDD. 5.6 Unlock HDD Unlocks the HDD that has not completed Secure Erase so that the HDD can continue to be used. 6. Setup 6.1 Copy Area There are 5 submenu modes. Scroll to select "6.1 Copy Area”, then press "OK.”...
  • Page 16 long as the source HDD’s data is within the target HDD’s space, the copy will be processed. FAT16/32/64, NTFS, ext2/3/4, HFS/HFS+/HFSX are supported for this copy mode. Target Source Duplication Partition1 (150GB) Data 30 GB Partition2 (200GB) 500GB Data 90GB 150GB Unallocated Partition...
  • Page 17 Target Source Duplication Partition1 (150GB) Data 30 GB Partition2 (200GB) 500GB 500GB Data 90GB 150GB 150GB 150GB Unallocated Unallocated Unallocated Partition Partition Partition All 500GB of data will be copied. 6.1.4 Percentage (%) Defines the selected percentage range of source HDD. Target Source Duplication...
  • Page 18 Index Partition Disabling function “6.2 Copy GPT Backup Area” will force the duplicator to ignore this area. GPT Backup Area If function is disabled, the target HDD will reconstruct the GPT Backup Area by Caution Windows system. It may require the HDD to restart in order to work. 6.3 Copy HPA Mode This menu contains submenus related to HPA Copy Modes.
  • Page 19 6.4 Skip Bad Sectors This function sets the number of errors you would like to skip during copy / compare / erase process. The default is 0. You can choose 0-65535 or unlimited. 6.5 Erase Master Setting to Enable allows erasure of source HDD. Please make sure this setting is correct before executing DoD erase.
  • Page 20 ◼ Keep HPA Setting Retain all HPA in connected device(s) while erasing all non-HPA areas. 6.9 Language Select preferred language. You can select English or Japanese. 6.10 Delete Disk Signature After Copy Set at “Yes” means do not copy the disk signature part. This function is for Windows only.
