3. Select the
IP over Ethernet
4. Modify the fields as needed.
The fields on this page are explained in the following table.
Field Name
Description
Enter Service
(Optional) Enter a name to describe this configuration.
Description
Enter 802.1P Pri-
Options are 0 - 7. The default is 0.
ority
For tagged service, enter values in this field and the
For untagged service, enter -1 (disabled) in this field and the
Enter 802.1Q VLAN
Options are 0 - 4094. The default is -1 (disabled).
ID
For tagged service, enter values in this field and the
For untagged service, enter -1 (disabled) in this field and the
Select the TPID for this VLAN. Options are 0x8100 , 0x88A8 , and 0x9100 .
Select VLAN TPID
Internet Protocol
This data packet scheduling technique allows different scheduling priorities to be applied to
Selection
statistically multiplexed data flows. Since each data flow has its own queue, an ill-behaved
flow (which has sent larger packets or more packets per second than the others since it
became active) will only punish itself and not other sessions. Options are IPv4 Only, IPv4&IPv6
(Dual Stack), and IPv6 Only. The default is IPv4 Only.
Note: When selecting IPV4&IPV6 or IPV6, the subsequent options presented will change
accordingly.
SmartRG Inc., an ADTRAN company. All Rights Reserved. © 2020
WAN service type.
802.1Q VLAN ID
field.
802.1Q VLAN ID
field.
802.1P Priority
field.
802.1P Priority
field.
37
