The following table describes the functions and features on the screen:
Callout Function
H LIGHTING and
SETTINGS panels
I SAVE THEME
J Zone selection
K Live preview
L Thumbnails
Click the panel tab and use the provided controls
to set up lighting effects and visual elements of
games for a theme.
See Setting the lighting effects
details.
NOTE: The LIGHTING panel appears only
when the supplied USB 3.2 Gen 1 (5 Gbps)
upstream cable is connected to both the
Alienware monitor and the computer.
Click to save all adjustments and changes for the
theme.
To make adjustments for a single zone, click the
specific check box. To make adjustments for all
zones, select the All Zones check box.
Under the LIGHTING panel, you can see the
lighting zones of the monitor with numbered
callouts. You may select a single zone by clicking
the number on the image. When you make
lighting adjustments, the preview of the monitor
displays the new effects simultaneously.
Under the SETTINGS panel, you can see the
applied effect of AlienVision displayed in this
window by toggling the PREVIEW switch to
ON.
Displays the thumbnails of the Alienware monitors
connected to your computer when you are under
the LIGHTING panel. The image displayed in the
live preview area is selected from this thumbnail
list.
Using AlienFX application
Description
and Settings for
