Instruction Leaflet IL29C150G
Installation Instructions for Shunt Trip for
R-Frame Series C Circuit Breakers and
Molded Case Switches
Effective December 2011
Supersedes IL29C150F 03/07
Contents
Description
1. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Page
Advertisement
Related Manuals for Eaton R-Frame Series
Summary of Contents for Eaton R-Frame Series
- Page 1 Effective December 2011 Instruction Leaflet IL29C150G Supersedes IL29C150F 03/07 Installation Instructions for Shunt Trip for R-Frame Series C Circuit Breakers and Molded Case Switches Contents Description Page 1. Introduction ......2...
-
Page 2: Installation
The recommendations and information contained herein The standard wiring configuration for the shunt trip is pig- are based on Eaton experience and judgement,but should tail leads exiting the right side of the cover. An optional not be considered to be ail-inclusive or covering every ap- terminal block (Cat No. - Page 3 Installation Instructions for Shunt Trip for Instruction Leaflet IL29C150G R-Frame Series C Circuit Breakers and Effective December 2011 Molded Case Switches Press Push-to-Trip button to trip operating mecha- 2-2. WARNING nism. Remove cover screws and cover. 2-3. THE VOLTAGES IN ENERGIZED EQUIPMENT CAN 2-4.
- Page 4 Installation Instructions for Shunt Trip for Instruction Leaflet IL29C150G R-Frame Series C Circuit Breakers and Effective December 2011 Molded Case Switches the handle (see Fig. 2-3). Use a tool t o depress and hold the lever even w i t h the top of the circuit break- er base while performing mechanical tests.
- Page 5 Installation Instructions for Shunt Trip for Instruction Leaflet IL29C150G R-Frame Series C Circuit Breakers and Effective December 2011 Molded Case Switches Accessory Remote Pigtail Lead a n d rarn U s e d ; G r o u n d Fault Label"...
- Page 6 Installation Instructions for Shunt Trip for Instruction Leaflet IL29C150G R-Frame Series C Circuit Breakers and Effective December 2011 Molded Case Switches TABLE 1-1. SHUNT TRIP ELECTRICAL RATINGS DATA Average circuit breaker contact total opening time approximately 62 milliseconds, at rated voltage Endurance electrical operations.
- Page 7 Installation Instructions for Shunt Trip for Instruction Leaflet IL29C150G R-Frame Series C Circuit Breakers and Effective December 2011 Molded Case Switches Notes: EATON CORPORATION www.eaton.com...
- Page 8 Instruction Leaflet IL29C150G Installation Instructions for Shunt Trip for R-Frame Series C Circuit Breakers and Effective December 2011 Molded Case Switches The instructions for installation, testing, maintenance, or repair herein are provided for the use of the product in general commercial applications and may not be appropriate for use in nuclear applica- tions. Additional instructions may be available upon specific request to replace, amend, or supplement these instructions to qualify them for use with the product in safety-related applications in a nuclear facility. This Instruction Booklet is published solely for information purposes and should not be considered all-inclusive. If further information is required, you should consult an authorized Eaton sales representa- tive. The sale of the product shown in this literature is subject to the terms and conditions outlined in appropriate Eaton selling policies or other contractual agreement between the parties. This literature is not intended to and does not enlarge or add to any such contract. The sole source governing the rights and remedies of any purchaser of this equipment is the contract between the purchaser and Eaton. NO WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE OR MERCHANTABILITY, OR WARRANTIES ARISING FROM COURSE OF DEALING OR USAGE OF TRADE, ARE MADE REGARDING THE INFORMATION, RECOMMENDATIONS, AND DESCRIPTIONS CONTAINED HEREIN.
