VIM3*-IO-* Vibration Sensors

Commissioning with IO-Link via FTD Framework Program (Offline Parameterization)

6 Commissioning with IO-Link via FTD Framework
Program (Offline Parameterization)
IO-Link Offline Parameterization Tool
An IODD (IO-Link Device Description) file is available to download for parameterizing the vibra-
tion sensor via IO-Link and diagnosis. See the product page for the relevant VIM3*-IO-* vibra-
tion sensor online at www.pepperl-fuchs.com or use the IODDfinder at https://ioddfinder.io-
link.com/.
With offline parameterization, IO-Link devices are already configured before installation. To do
this, use the Pepperl+Fuchs IO-Link USB master.
The software components required in each case are summarized in the latest version of the
"IO-Link Offline Parameterization Tool" software package. The software package and the docu-
mentation on its installation and use can be found online at www.pepperl-fuchs.com.
If the "IO-Link Offline Parameterization Tool" software package is used, there is active internet
access, and the device is connected via the Pepperl+Fuchs IO-Link USB master, the IODD can
be directly integrated into the IO-Link Offline Parameterization Tool via the "IODD DTM Config-
urator."
Note
Suitable cordsets can be found at www.pepperl-fuchs.com. Navigate to the product page for
the relevant vibration sensor under "Accessories."
To activate the vibration sensor via IO-Link using the corresponding IODD, proceed as follows:
1.
Make sure that the "IO-Link Offline Parameterization Tool" software package is installed on the
computer.
2.
Connect the vibration sensor to an IO-Link master with a suitable M12 cordset.
3.
Connect the IO-Link master to a USB connection on your PC via a USB cable.
4.
Start PACTware.
PACTware automatically communicates with the vibration sensor if PACTware from the "IO-
Link Offline Parameterization Tool" is used and the IODD was found automatically online.
15
