The Rear Panel

Power Receptacle

To be compatible with the electric service standards around the world, the switch is
designed to afford the power supply in the range from 100 to 240VAC, 50/60Hz. Please
make sure that your outlet standard to be within this range.
To power on the switch, plug the female end of the power cord firmly into the receptacle of
the switch and the other end into an electric service outlet. After the power cord installation,
please check if the power LED is illuminated for a normal power status.
Installation
This switch can be placed on your desktop directly, or mounted in a rack. The installation
is a snap. Users can use all the features of the switch with simply attaching the cables and
turning the power on.
Before installing the switch, we strongly recommend:
1.
The switch is placed with appropriate ventilation environment. A minimum 25mm
space around the unit is recommended.
2.
The switch and the relevant components are away from sources of electrical noise
such as radios, transmitters and broadband amplifiers
3.
The switch is away from environments beyond recommend moisture

Desktop Installation

1.
Attach the provided robber feet to the bottom of the switch to keep the switch from
slipping. The recommend position has been square-marked.
2.
Install the switch on a level surface that can support the weight of the unit and the
relevant components.
3.
Plug the switch with the female end of the provided power cord and plug the male
end to the power outlet.
3
