Product Specifications - LevelOne ProCon FSW-1610TX Specification Sheet

16/24 port 10/100mbps fast ethernet switch
Hide thumbs Also See for ProCon FSW-1610TX:

Advertisement

16/24 Port
16/24 Port
Fast Ethernet
Fast Ethernet

Product Specifications

Product Specifications
Standards Conformance
Network Interface
Supported Cable
Forwarding Method
Packet Forwarding Rate
MAC Address Size
Buffer Memory Size
Network Data Transfer Rate
Protocol
Dimensions
Temperature
Humidity
Status LEDs
EMC Compatibility
Ordering Information
Ordering Information
FSW-1610TX
FSW-2410TX
10/100Mbps
10/100Mbps
Switch
Switch
IEEE802.3u 100Base-TX
IEEE802.3 10Base-T
• STP RJ45 port for 10/100Mbps auto-sensing
• 10Base-T: UTP category 3 or category 5 cable up to 328ft/100M
• 100Base-TX: UTP category 5 cable up to 328 ft/100M
• Store and Forward
• 10Base-T:
14,880pps to 10Mbps per port
• 100Base-TX:
148,800pps to 100Mbps per port
• FSW-1610TX:
16K MAC address entries per device
• FSW-2410TX:
24K MAC address entries per device
• FSW-1610TX:
512KBytes per device
• FSW-2410TX:
1.5MB per device
• Ethernet:
10Mbps (half-duplex), 20Mbps (full-duplex)
• Fast Ethernet:
100Mbps (half-duplex), 200Mbps (full-duplex)
• CSMA/CD
• 440mm x 44mm x 195mm
• Operation Temperature: 0 C-40 C
• Storage Temperature: -20 C-70 C
• Operation Humidity: 10% - 90% RH
• Storage Humidity: 5% to 90% RH
• Power
• 10/100Mbps Link/Activity
• FDX/COL
• FX
• FCC Part 15 Class A
• VCCI-I
• CE
• 16 Port 10/100Mbps Fast Ethernet Switch
• 24 Port 10/100Mbps Fast Ethernet Switch
LevelOne Quality Switches
The FSW-1610TX/FSW-2410TX (16/24-
port) 10/100 Mbps Fast Ethernet switches
from LevelOne provide you with the right
connectivity to set up your LAN quickly
and easily. Half-and full-duplex capability is
supported on all TX ports, providing bi-
directional transmission that boosts bandwidth
up to 200 Mbps. Operating at maximum packet
filtering and forwarding rate, the FSW-1610TX/
FSW-2410TX supports store-and-forward and
offers 1/1.5 Mbytes buffer memory. The units
comply with the IEEE802.3 10Base-T and
IEEE802.3u 100Base-TX standards providing
adequate flow control between communicating
devices for full-duplex operation. Other features
include 16K/24K MAC address entries and an
STP RJ45 port for 10/100 Mbps auto sensing.
Expanding Possibilities
The FSW-1610TX/2410TX switches help get the
maximum utility from your office network. Offering
connections of up to 100m (328ft) apart and an extra
MDI-II connector in a virtually plug and play
configuration the FSW-1610TX/2410TX, allows for
easy network expansion.
The intelligent choice
The clearly visible status LEDs provide easy
monitoring of port link activity, speed, and collision,
so that you are never in the dark when it comes to the
status of your data transmissions.
Offering a compact design (440 mm x 44 mm x 195
mm) the FSW-1610TX/2410TX supports reliable
operation in extreme operating environments.
