FS-1-WL Connection Guide
(Connect with the GX-100)
© 2022 Roland Corporation
This guide shows you how to pair the FS-1-WL
wirelessly to the GX-100 using BLE MIDI.
"Pairing" involves registering the MIDI device that
you want to use (making the devices recognize each
other) with the FS-1-WL.
Pairing the FS-1-WL with another compatible
device lets you control that device via MIDI from the
FS-1-WL.
* You must update the GX-100 to Ver. 1.11 or later
to use the FS-1-WL.
https://www.boss.info/support/
What is "BLE MIDI"?
"BLE MIDI" is the technology used to transmit
and receive MIDI messages wirelessly via
Bluetooth®
This is officially known as "MIDI over Bluetooth Low
Energy".
LE standard.
01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FS-1-WL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Roland FS-1-WL

Summary of Contents for Roland FS-1-WL

  • Page 1 FS-1-WL Connection Guide (Connect with the GX-100) © 2022 Roland Corporation This guide shows you how to pair the FS-1-WL wirelessly to the GX-100 using BLE MIDI. “Pairing” involves registering the MIDI device that you want to use (making the devices recognize each other) with the FS-1-WL.
  • Page 2 The Bluetooth indicators on both units stop blinking and remain lit when pairing is finished, and now the GX-100 and FS-1-WL are paired. If connected correctly, it will be in the following state. BT-DUAL Bluetooth indicator...
  • Page 3 GX-100, or when turning off the power while the Bluetooth indicator is blinking white (not connected), or when doing a factory reset of the FS-1-WL, the unit does not pair automatically. In this case, you must start from step 1 to...
  • Page 4 Press the [Bluetooth] (INSTRUMENT) button on the FS-1-WL. The [Bluetooth] (INSTRUMENT) indicator on the FS-1-WL blinks white, and pairing begins. The Bluetooth indicators on both units stop blinking and remain lit when pairing is finished, and now the GX-100 and FS-1-WL are paired.
  • Page 5 FS-1-WL blinks blue. On the BOSS TONE STUDIO for GX-100 app, select “FS-1-WL+”. The [Bluetooth] (Smartphone/PC) indicator on the FS-1-WL stops blinking and remains lit when pairing is finished. If connected correctly, it will be in the following state. BT-DUAL Bluetooth indicator...
  • Page 6 GX-100, or when turning off the power while the Bluetooth indicator is blinking white (not connected), or when doing a factory reset of the FS-1-WL, the unit does not pair automatically. In this case, you must start from step 1 to configure the settings.
  • Page 7 GX-100 Settings Assign the CC numbers that correspond to the FS-1-WL in ASSIGN SETTING - SOURCE, found in the GX-100 “CTL/EXP” settings. The default CC numbers for the FS-1-WL are set as shown below. Parameter MIDI CC numbers PEDAL L...
