Thank you for trusting Pursuit products! If you are a consumer, please note:
Professional installation is strongly recommended.
This manual assumes the installer has adequate knowledge of the following expertise. Therefore, it does not
cover these topics in detail:
•
12-volt electronics
•
Testing and verifying circuits
•
Making safe and lasting wiring connections
•
Factory ignition, power, lighting, data bus and sensing systems
•
Factory systems and components to avoid
•
Safe wire routing, circuit protection and product placement
•
Access to vehicle-specific technical information
In addition, this manual assumes the installer has the proper tools, skill and facilities to perform a professional installation.
Performing an improper installation could result in damage to the vehicle or its components, improper system function,
unsafe vehicle operation or physical injury. Such instances would not be covered by the vehicle manufacturer's warranty,
nor by Voxx Electronics, Inc.
Detailed Descriptions
2
2
4
5
6
6
6
Valet / LED
6
6
7
7
2020 Voxx Electronics Corporation. All rights reserved.
PRO9233Z
Security Upgrade
Installation and Reference Guide
11
System Programming
11
Programming Mode Entry / Exit
12
12
12
13
13
13
System Diagnostics
13
13
14
Alarm Override Procedures
15
Wiring Diagrams
15
18
Starter Kill Relay
19
Full System Connections
PRO9233Z_RevA_08/20
Advertisement
Table of Contents
Related Manuals for PURSUIT PRO9233Z
Summary of Contents for PURSUIT PRO9233Z
-
Page 1: Table Of Contents
Security Upgrade Installation and Reference Guide Thank you for trusting Pursuit products! If you are a consumer, please note: Professional installation is strongly recommended. This manual assumes the installer has adequate knowledge of the following expertise. Therefore, it does not cover these topics in detail: •... -
Page 2: Wire Harness Colors And Functions
Detailed Descriptions: Wire Harness Colors and Functions Input / Output Connector (14-pin connector) See page 19 for the full system diagram. These wires are listed in order of their placement in the harness connector. 10 11 13 14 1. WHITE/RED – Parking Light Relay Input (Internal Relay Pin 87) The WHITE/RED connects to vehicle 12-Volt (+) or Ground (-) to supply the relay output (WHITE wire). - Page 3 Detailed Descriptions: Wire Harness Colors and Functions Input / Output Connector (14-pin connector) (Cont.) See page 19 for the full system diagram. These wires are listed in order of their placement in the harness connector. 8. BLACK/WHITE – Horn Output (-) The BLACK/WHITE wire connects to the vehicle's horn wire and supplies Ground (-) when activated from the system.
-
Page 4: Control Connector
Detailed Descriptions: Wire Harness Colors and Functions Control Connector (5-pin connector) (Cont.) See page 19 for the full system diagram. These wires are listed in order of their placement in the harness connector. 1. GREEN/BLACK – Arm 2 Input (-/+) The GREEN/BLACK wire connects to the vehicle's door lock trim switch wire. -
Page 5: Door Lock Connector
Detailed Descriptions: Wire Harness Colors and Functions Door Lock Connector (2-pin connector) See page 19 for the full system diagram. These wires are listed in order of their placement in the harness connector. 1. RED – Door Lock (-) The RED wire supplies Ground (-) when the Lock function is activated from the remote control or system. Verification: The vehicle lock wire registers 12-Volts (+) or Ground (-) when the Lock button is activated. -
Page 6: External Components
Shock Sensor The shock sensor plugs into a 4-pin connector on the Pursuit module. It should be securely attached to a vehicle surface or sturdy wire harness. Testing takes place after all connections are made and the system is powered up. Refer to Quick Reference: System Diagnostics on page 13 for instructions on testing and adjusting the shock sensor. -
Page 7: Setup Options
Detailed Descriptions: Setup Options Security Control (Bank 2) See page 11 for Programming Instruction. Op�ons Feature Bank 2 1 Chirp 2 Chirp 3 Chirp 4 Chirp 5 Chirp 6 Chirp 1 Lock / Unlock Func�on 500ms 3.5sec 500ms L, DBL UL DBL L, 500ms UL DBL L, DBL UL 500ms L, 350ms UL... - Page 8 Detailed Descriptions: Setup Options Security Control (Bank 2) (cont.) See page 11 for Programming Instruction. Feature 5: Automatic Arming Function: Set the system to arm automatically after exiting the vehicle. Setting Choices: • Option 1 - System will arm and doors will lock only when the alarm is armed from the remote control. •...
- Page 9 Detailed Descriptions: Setup Options Security Control (Bank 2) (Cont.) See page 11 for Programming Instruction. Feature 11: Security Profile Function: Set the system to function as a keyless entry / convenience system or full-featured alarm / convenience system. Setting Choices: •...
- Page 10 Detailed Descriptions: Setup Options Security Control (Bank 2) (Cont.) See page 11 for Programming Instruction. Feature 16: Arm 2 Input Polarity Function: Set the Arm 2 input polarity Setting Choices: • Option 1 - System will Auto Detect the input polarity on power-up . •...
-
Page 11: Quick Reference
Quick Reference: System Programming Programming Mode Entry and Exit Procedure Once the system is installed and powered up, you will use the vehicle ignition, override button and a programmed remote control to set all system options. Feature options are divided into categories, or Banks, as described throughout this section. -
Page 12: Feature Bank Options
3. Release the valet button. Dome Light Delay To program the Pursuit system to wait until the dome light turns off before arming: 1. Close all doors. 2. With the vehicle ignition off, press LOCK, UNLOCK, LOCK ,UNLOCK, LOCK, UNLOCK, LOCK on the remote control. The dash-mounted LED will turn on. -
Page 13: Silent Arm And Disarm
Quick Reference: System Programming & Diagnostics Silent Arm and Disarm Program the Pursuit system to arm and disarm without notification chirps. (The horn/siren will sound if the system is triggered while armed.) 1. Turn the ignition ON then OFF. 2. Press and release the valet/programming button three (3) times. The system will respond with one (1) chirp for ON or two (2) chirps for OFF. - Page 14 Quick Reference: Alarm Override Procedures Valet Alarm Override The Valet Override procedure will disable the alarm when the remote is not available or has become inoperative. If the vehicle door is opened without disarming, the alarm will sound and the vehicle will not start when attempting to start with the key.
-
Page 15: Door Lock Connections
Quick Reference: Wiring Diagrams Door Lock Connections Negative-Trigger Door Locks Verification: The vehicle wires register Ground when the Lock and Unlock switches are activated. RED ( - ) Lock Output Lock Vehicle Door Lock Control Relays Unlock GREEN ( - ) Unlock Output Positive-Trigger Door Locks Verification: The vehicle wires register 12V+ when the Lock and Unlock switches are activated. - Page 16 Quick Reference: Wiring Diagrams Door Lock Connections Single-Wire Negative Multiplex Door Locks (Relays required) Verification: The vehicle wire registers variable Ground values when the Lock and Unlock switches are activated. Please consult the vehicle-specific wire and location chart for resistor values. Ground Fused +12 Volt RED ( - ) Lock Output...
- Page 17 Quick Reference: Wiring Diagrams Door Lock Connections Reverse-Polarity Door Locks (Relays required) Verification: The vehicle wires rest at Ground and register 12V+ when the Lock and Unlock switches are activated. Fused +12 Volt Battery Souce RED ( - ) Lock Output Lock To Door Lock Motor Unlock...
- Page 18 Quick Reference: Wiring Diagrams Starter Kill / Anti-Grind Relay Connections Included Starter Kill / Anti-Grind Relay To ORANGE - Starter Kill / To Vehicle Ignition Anti-Grind Output (-) From Alarm PRO9233Z_RevA_08/20...
- Page 19 Quick Reference: Wiring Diagrams PRO9233Z_RevA_08/20...
