PURSUIT PR71TW Operator's Manual

Model PR71TW

Operators Manual

RF Upgrade Kit

Start Button

Press two times in

succession to

start vehicle

To Operate System:

1) Press transmitter button two times in succession to start the vehicle. The vehicle will start and

run the predetermined time set up during installation (5 to 60 minutes selectable). The two way

transmitter will flash every 10 seconds during the run cycle to advise you that the vehicle started

and is running.

2) During the run cycle, enter the vehicle using your door key or, if the unlock option is installed,

once you are within range of the vehicle, press and hold the transmitter button for 3 seconds to

unlock the vehicle doors.

3) Enter the vehicle, insert your key and turn it to the run, NOT START, position, then step on the

brake, the vehicle is now in control of the ignition key.

NOTE: For push to start vehicles, contact your installation center for proper procedure.

4) With vehicle running, if you wish to make a quick stop and leave the vehicle running, once

you arrive at your destination:

a) place the gear selector in Park,

b) set the parking brake,

c) with your foot off the brake, press the transmitter button two times in succession.

The vehicle will now be under control of the remote start system. Turn your ignition switch off,

WITHOUT, stepping on the brake, and exit the vehicle. Lock the doors with the key to insure

security.

The Remote Start unit has the ability to start the vehicle automatically at timed intervals. This

feature is useful in extremely cold climates where starting the engine is the only means to keep

PATENTED: www.voxxintl.com/company/patents

128-9489

Page 1

Table of Contents

Do you have a question about the PR71TW and is the answer not in the manual?

Page 1 Model PR71TW Operators Manual RF Upgrade Kit Start Button Press two times in succession to start vehicle To Operate System: 1) Press transmitter button two times in succession to start the vehicle. The vehicle will start and run the predetermined time set up during installation (5 to 60 minutes selectable). The two way transmitter will flash every 10 seconds during the run cycle to advise you that the vehicle started and is running.
Page 2 the battery charged and fluids warm. The operator has the option to have the unit start every 2 or 4 hours for a maximum of 48 hours. Factory preset is to start at 4 hour intervals. To select 2 or 4 hour automatic start timer: 1.
Page 3 Programming New or Replacement 171XPR or 1BER17XPR Transmitters: 1) Turn the ignition switch to the “On” position” 2) Press and release the pushbutton switch found on the windshield mount receiver 3 times. (The LED on the receiver will flash). 3) Press and hold the transmitter start button, until the LED on the receiver turns solid. 4) Release the transmitter button.
Page 4 NOTE: The 1BER17XPRP two way transmitter used two CR2025 Batteries. 1) Locate and remove the “00” point Phillips head screw located in the lower center on the back of the transmitter case. 2) Locate the slot at the lower right hand side of the transmitter case. 3) Separate the case halves by inserting a small plastic tool in the slot and carefully prying apart the case halves.
