PURSUIT PRO9556Z Quick Installation Manual

PRO9556Z
Remote Start
System Layout
Important Update
The default Data Port Protocol of this system is ADS. If using an
FLCAN or other external integration module be sure to choose
iDatalink 2-Way when flashing.
This system will also support DBI. This will require programming
Feature Bank 2, Feature 18 to DBI.
1 3 5
2 4 6
1 Yellow Starter Output (+)
2 Green
Igni on 2 Output (+)
3 Red
Ba ery 12V Input (+)
4 Red/White Ba ery 12V Input (+)
5 Purple
Accessory Output (+)
6 Blue
Igni on Input / Output (+)
Replacement Part #4120467
1 White Parking Light (30) Output
2 White/Red
Parking Light (87) Input
3 Yellow/Black
Igni on Output For Alarm (+)
4 Black Ground Input (-)
Replacement Part #4120463
1 3
2 4
For Complete Installation Guide and Technical Support Visit www.voxxuniversity.com. Or Call 1-800-225-6074
P
P
P
Replacement Part #183BPR
Replacement Part #4360847
Replacement Part #4180070
6
6 Empty
Empty
5
5 Blue LED (-)
4
4 Red
Valet Switch
3 3 Black
Ground (-)
2 Green Data RX
2
1 Pink
Ba ery 12V (+)
1
4
4 Red
Ba ery 12V (+)
3
3 Black
Ground (-)
2 White Data RX
2
1
Blue Data TX
1
4
4 Red
Ba ery 12V (+)
3
3 Blue Data TX
2
Black Ground (-)
2
1
White Data RX
1
14 Green/Orange Tach Input
13 Black/Yellow Pulse During Crank Output (-)
12 Green/Yellow
Glow Plug Input (+)
11 Black/Red Pulse A er Shutdown Output (-)
13 14 10 Dk. Blue
Trunk Output (-)
11 12
9 Black/Blue
Factory Disarm Output (-)
9 10
8 Brown/Black Brake Input (+)
7 8
7 Black/Lt. Green
Factory Arm Output (-)
5 6
6 Dk. Blue/Black
External Ac va on Input (-)
3 4
1 2 5 Lt. Blue Remote Start Status Output (-)
4 Green
Unlock Output (-)
3 Gray/Black
Hood Input (-)
2 Red Lock Output (-)
1 Black/White
Horn Output (-)
2020 Voxx Electronics. All Rights Reserved.
Replacement Part #4120465
Not Included
Not Included
Replacement Part #4120476
