4.2 Installation into the product line
Installation into the product line is possible up to a flow rate of 50 l/min (using H
other viscosities, differing pressure losses must be considered.
Caution!
The pressure in the product line must never fall below the vapor pressure. Direct solar irradiation of the
density transducer must be avoided. If necessary, heat insulation must be provided.
4.3 Examples for installation positions
The device may be mounted in any position. However, depending on the properties of the liquid and the
flow velocity, the following positions are recommended:
Inclination 20°-
A
Mounting position A:
Mounting position B:
Mounting positions C or D:
5 Mounting
5.1 Density transducer
- Handle with care: do not knock the density transducer.
- Install density transducer into by-pass or directly into the product line.
- Deaerate the device before putting it into operation.
- Provide a constant flow through the density transducer.
- Any flow direction is possible.
- Normal flow rate to be approx. 1.5 to 6 l/min, max. 50 l/min
(provides current liquid sample, avoids deposits)
- Avoid generation of steam bubbles.
- The use of a clamp or a bracket is recommended
(e.g. mounting plate, pipe or wall clamp).
- If mounting position is "self-draining",
a clamp or a bracket must be used.
- The pipe bends of the density transducer must not
be bent during mounting.
We reserve all rights of ownership and exploitation in respect of these
documents, including industrial property rights. These documents may only
be used with our express consent in writing, and only to the extent permitted
in any such consent. The documents may not be duplicated or made
available to third parties. In case of violation of the aforementioned
provisions, we reserve all rights.
30°
B
C
standard mounting position, e.g. for clean liquids at low
flow velocities
self-draining position
for liquids with solids
O as an example). For
2
D
10
