Motion Foot
SLX
Product Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Motion Foot SLX and is the answer not in the manual?

Questions and answers

Related Manuals for Fillauer Motion Foot SLX

Summary of Contents for Fillauer Motion Foot SLX

  • Page 1 Motion Foot Product Manual...

  • Page 2: Table Of Contents

    Serious Incidents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 To see other language options, visit fillauer.com .

  • Page 3: Intended Use

    Range of motion. Fillauer has designed the Motion Foot SLX to support each phase of foot function in the gait cycle—from heel strike, to mid-stance, to toe off.

  • Page 4: Warnings And Precautions

    CAUTION: The Motion Foot SLX is designed to be maintenance free and should not be disassembled. The hydraulic unit on the foot is permanently attached to the main and top spring and should not be removed .
  • Page 5 NOTICE: Fillauer has tested (ISO 10328) and recommends the use of standard adult endoskeletal components from Fillauer together. Components from other manufacturers may or may not be compatible.

  • Page 6: Alignment (Specifications & Preparations Before Use)

    Standard bench alignment techniques may be used for the Motion Foot SLX foot (Figure 2). Before aligning, the initial heel height should be established. The Motion Foot SLX is designed for a 3/8 in. or 1 cm heel height . The initial heel height can be established with a simple spacer under the heel.
  • Page 7 Transtibial Bench Alignment The foot should be set in the proper amount of inset found in the evaluation . When using separate suspension and attachment components, the foot may be slightly inset 1 – 12 mm depending on the limb length. Short limb lengths are set with very little inset of 2 – 3 mm and longer limb lengths may tolerate a greater varus thrust at 10 – 12 mm.
  • Page 8 Dynamic Alignment The Motion Foot SLX hydraulic Range of motion allows it to conform well to the ground. This characteristic may make the foot appear to be properly aligned after the static alignment. Small adjustments in the alignment however will smooth the transition from heel to toe, optimize gait and efficiency.
  • Page 9 Motion Foot SLX Dynamic Alignment Procedure Observe initial contact with the user walking to determine if “foot slap” is occurring. Does the user Increase Decrease report the heel as resistance. resistance. too stiff? Does the user report a sensation of...
  • Page 10 “walking down a hill.” Dorsiflex the foot or decrease dorsiflexion resistance to increase the rate of rollover . If a smooth stance phase of gait cannot be achieved, contact Fillauer for additional assistance .

  • Page 11: Foot Shell And Spectra Sock (Consumable Components)

    Foot Shell and Spectra Sock (Consumable Components) The Motion Foot SLX uses a unique cosmetic foot shell that is flexible and durable (sold separately). Use care in the installation and removal of the foot shell to maintain its appearance and durability. Always use the shell with an internal Spectra Sock (included).

  • Page 12: Compatibility

    • If the foot shell is too tight, a smooth-edged shoehorn may be used to disengage the heel lock . Compatibility Fillauer feet are appropriate for use with Fillauer or equal, ISO 10328 compliant, Endoskeletal components. A Fillauer spectra sock and foot shell should be used with this device, the fit of other manufacturers shells cannot be guaranteed .

  • Page 13: User Instructions

    User Instructions The providing health care professional must review the following information directly with the user. Care and Maintenance WARNING: If the foot performance changes or it begins to make noise, the patient should immediately contact his or her practitioner . These things may be as sign of a failure of the foot or other part of the prosthesis that could result in a fall or other serious injury.

  • Page 14: Serious Incidents

    In the unlikely event a serious incident occurs in relation to the use of the device, users should seek immediate medical help and contact their prosthetist, local competent authority and Fillauer at the earliest possible convenience . Clinicians should at any time contact their local Fillauer representative and local competent authority immediately in the event of any device failure.
  • Page 16 Fillauer LLC 2710 Amnicola Highway Chattanooga, TN 37406 423.624.0946 Fillauer Europe EC REP Kung Hans väg 2 192 68 Sollentuna, Sweden www.fillauer.com +46 (0)8 505 332 00 © 2022 Fillauer LLC M080/06-01-22/Rev.1...
