- Page 1 MC ETD2 User Guide...
- Page 2 MC ETD2 User Guide Introduction The Motion Control ETD2 marks the second generation of the Electric Terminal Device. Continuing the features of the previous ETD, the ETD2 is robust, lightweight and water-resistant to provide a high level of functionality to persons with upper extremity limb loss.
- Page 3 Do not bend fingers While the MC ETD2 is robust, body weight represents a great deal of force. Do not apply full body weight on the fingers. A fall with the force directed to the fingers could cause damage. Additionally, when pushing forcefully with the ETD2 do not push on the open, moveable finger.
- Page 4 Instructions for Use Before attaching the MC ETD2 to the forearm, locate the power switch at the base of the ETD2. Ensure it is switched OFF (see diagram, page 3). Insert the quick disconnect wrist on the ETD2 into the wrist on the forearm. While pushing it in firmly, rotate the ETD2 until an audible click is heard.
- Page 5 The first time the application is opened, a tutorial is offered. This overview will take 10 to 15 minutes and is recommended. Additionally, located throughout the application is a context-sensitive information icon. Tapping this icon will briefly explain the function of that adjustment. *Note: The MCUI app is not available for Android devices.
- Page 6 FLAG (Optional) FLAG (Force Limiting, Auto Grasp) is an optional feature for the MC ProPlus Hand, ETD and ETD2 terminal devices. FLAG provides two functions: • Force Limiting, to prevent crushing objects due to excessive pinch force • Auto Grasp, which slightly increases the grip on an object if an inadvertent open signal is detected by the controller Turn FLAG On/Off Upon power up, FLAG is turned off.
- Page 7 Transport & Storage Temperature: -18° to 71° C (0° to 160° F) Pinch Force: At 7.2 volts nominal: 11 kg (24 lbs, or ~ 107N) Operating Voltage Range: 6 to 8.2 Vdc - MC ETD2 Load Limit: 22 kg / 50 lbs in all directions (+/- 10%)
- Page 8 MCUI User Interface for iOS Quick Setup Guide Quick Setup for Motion Control User Interface for Apple iOS (MCUI) ® 1. From the Apple App Store download and install the MCUI. ® 2. Choose "Patient". 3. Open the App and follow the Tutorial. 4.
