- Page 1 GN27CB CURVED GAMING MONIT USER MANUAL In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from time to time. Please check our website for the latest user manuals and product materials. ver.1.0 2/21/19...
-
Page 3: Table Of Contents
Table of Contents Section 1: Safety Precautions ..........4 Section 2: Box Contents ............. 5 Section 3: Product Overview ..........6 3.1 – Monitor Buttons ............6 3.2 – Monitor Ports ............6 Section 4: Stand Installation ..........7 Section 5: Mount Installation ..........8 Section 6: Connectivity Options ........ -
Page 4: Section 1: Safety Precautions
® VIOTEK shall not be held responsible for injury or damage of products or persons due to failure to adhere to the aforementioned precautions or any others noted... -
Page 5: Section 2: Box Contents
Section 2: Box Contents Monitor x 1 Stand Stem x 1 Stand Base x 1 NO.1 Screws x 4 NO. 2 Screws x 4 DP Cable x 1 (for Stand Installation) (for Mounting) Power Cable x 1 Screwdriver x 1 User Manual x 1 (AC 100-240V, 50/60Hz) The screws come in different sizes: NO.1 (12mm x 4 pcs), NO.2 (31mm x 2 pcs... -
Page 6: Section 3: Product Overview
Section 3: Product Overview 3.1 – Monitor Buttons Power Connector: Insert the power cable to supply power to the monitor. M Menu Button: Press to display the OSD menu or enter sub-menus. Down Button: Press to move down in the menus. Up Button: Press to move up in the menus. -
Page 7: Section 4: Stand Installation
Section 4: Stand Installation Keep the foam underneath the monitor before attaching the stand. 1. Open the package and take out the monitor with foam still attached. Gently place it on a desktop or table. 2. Remove the extra parts and the foam covering the back of the monitor. Press the release button to remove the stand plate. -
Page 8: Section 5: Mount Installation
Section 5: Mount Installation This monitor ONLY includes screws which may be used when attaching the monitor to a VESA 75x75mm type mount. No VESA mount or mounting accessory is included. Keep the foam underneath the monitor before attaching the stand to a mount or accessory. -
Page 9: Section 6: Connectivity Options
Section 6: Connectivity Options 6.1 – Removing the Port Cover Before connecting any cables, remove the port cover first. Port Cover Back of Monitor 6.2 – Connecting the Power Cable Connect the included power cable to the power connector, and then plug the other end into an wall outlet. -
Page 10: Dp Connectivity
6.3 – DP Connectivity In order for the monitor to receive DP signals from the computer, use the DP cable to connect the monitor to the computer. DP Cable (Included) DP OUTPUT 6.4 – HDMI Connectivity In order for the monitor to receive HDMI signals from the computer, use the HDMI cable to connect the monitor to the computer. -
Page 11: Section 8: Indicator Light
2. Connect the other end of the cable to the corresponding connector on your monitor. See the image below. DP Connector HDMI Connectors 3. Connect the power cable to your monitor then connect the other end to your power source. It is recommended that you use a surge protector with adequate voltage if a wall outlet cannot be reached directly. -
Page 12: Section 9: Osd Setup
Section 9: OSD Setup The Multifunction (MFN) buttons (M, , , E, ) on the lower-right of the monitor serve multiple purposes, including accessing the On-Screen Display (OSD) menu. The OSD be used to adjust your monitor’s settings to your liking. 1. -
Page 13: Osd Menu Functions
9.2 – OSD Menu Functions 1. Press M button TWICE to enter the OSD menu. BRIGHTNESS BRIGHTNESS CONTRAST STANDARD 2. Press to browse functions. • Highlight the desired function and press M to enter the sub-menu. • Press to browse sub-menus and press M to highlight the desired function. •... - Page 14 Main Menu Sub-Menu Options Description OSD SETTING Language English, Español, Set OSD language Русский, Français, 한국, Português, Deutsch, Türkçe, 日本語, 简体中文, Polski, Italiano, Nederlands Adjust the OSD horizontal OSD H. POS. 0-100 position OSD V.POS. 0-100 Adjust the OSD vertical position OSD Timer 0~60 Set how long the OSD remains...
-
Page 15: Section 10: Eco Modes And Gameplus Switching
Section 10: ECO Modes and GAMEPLUS Switching ) to activate the Quick-Nav menu. 1. Press any one of the buttons (M, , , E, 2. Press button to cycle through GAMEPLUS modes. According to the needs of your game, choose the corresponding game icon. These game icons are primarily designed to optimize your aim during shooting games, though they can be used for other scenarios. - Page 16 • Try connecting to another video source for comparison. The screen appears to be scrolling, rolling, or moving unusually. • Check that your source frequency is within 48-144Hz. • Reconnect and ensure your video cable is secure. The monitor needs cleaning •...
-
Page 17: Section 12: Specifications
Weight 12.1 – Resolution Compatibility for DP System Requirements below are the minimum system requirements for your GN27CB monitor. The requirements are recommended in order to properly use all of the monitor’s features and ensure high-quality picture. All trademarks and registered trade names are the property of their respective owners. -
Page 18: Section 13: 1 Year Limited Hardware Warranty
Section 13: 1 Year Limited Hardware Warranty GN27CB Curved Gaming Monitor (”Product”) includes a One-Year ® Your VIOTEK Limited Hardware Warranty (“Warranty”). The Warranty covers product defects in materials and workmanship under normal use. This Warranty is limited to residents of the United States and Canada only and is available only to original purchasers. - Page 19 THE DURATION AND REMEDIES OF ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED TO THE DURATION OF THIS EXPRESS LIMITED WARRANTY. DECLARATION OF CONFORMITY This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 20 COPYRIGHT © 2019 VIOTEK. ALL RIGHTS RESERVED.
