SimpliFire SF-SCT43-BK Service Manual

Glass Front, Heater, Control Board, LED Spotlight, Ember Bed Cover, Glass Side Panels, Glass Screen
Panel, Remote Receiver, Flame Screen, Rotisserie, Rotisserie Motors, Flame and Ember LEDs,
Leave this manual with party responsible for use
and operation.
NOTICE! DO NOT discard this manual.
and maintenance instructions included.
NOTICE! DO NOT discard any hardware while
servicing. It may be reused.
WARNING! Risk of Personal Injury or Property Dam-
age! Failure to follow instructions below may result in
damage to the equipment and / or may expose the user
to the risk of fire, serious injury, illness or death.
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during
installation and service. Sheet metal edges are sharp.
WARNING! Risk of Shock! Always turn off the circuit
breaker before moving or servicing.
Tools and Supplies Needed
Before beginning the installation be sure that the following
tools and building supplies are available.
Needle-nose pliers
Gloves
Magnetic Phillips screwdriver
Safety glasses
Drill
Flat blade screwdriver
SERVICE MANUAL
Model: SF-SCT43-BK, SF-SCT55-BK
- Instructions -
Important service
SimpliFire • SF-SCT43-BK, SF-SCT55-BK Service Manual • 2043-960 • 7/20
CAUTION! Two adults recommended for the removal
or installation of glass front. Use caution when han-
dling glass. Failure to do so could result in personal injury
or property damage.

Glass Front Replacement

1. Remove the two (2) thumb screws and brackets
located on the inner upper corners of the appliance
opening. See Figure 1.
2. Tilt the glass away from the appliance and lift out of
the bottom glass channel.
3. Set the bottom edge of glass into the glass channel
and tip back into the appliance until it rests against
the glass stops.
4. Re-install the glass brackets and thumb screws.
THUMB SCREW THUMB SCREW
Figure 1. Remove Glass Front
1
