- Page 4 1. Prepare 4 bolt assemblies by first inserting a lock washer (#C) onto the bolt (#A) then a flat washer (#B) onto that same bolt (#A). 2. Align the legs (#2) to the holes along the sides of the headboard (#1), then insert the bolt assemblies.
- Page 5 Hook each end of the side rails (#5) onto the slots along the sides of the legs (#2,4). Insert the threaded ends of the slat support legs (#7) into the holes along the slats (#6), turn right to tighten. Adjust according to the ground level.
- Page 6 Place the slats (#6) onto the side rails (#5), then insert a screw (#D) into each end. Secure using a screwdriver.
- Page 10 1. Prepare 4 bolt assemblies by first inserting a lock washer (#C) onto the bolt (#A) then a flat washer (#B) onto that same bolt (#A). 2. Align the legs (#2) to the holes along the sides of the headboard (#1), then insert the bolt assemblies.
- Page 11 Hook each end of the side rails (#5) onto the slots along the sides of the legs (#2,4). Insert the threaded ends of the slat support legs (#7) into the holes along the slats (#6), turn right to tighten. Adjust according to the ground level.
- Page 12 Place the slats (#6) onto the side rails (#5), then insert a screw (#D) into each end. Secure using a screwdriver.
