1.5

SAFETY

Current Gas Safety (installation and use) regulations or
rules in force:
The appliance is suitable only for installation in GB and should
be installed in accordance with the rules in force.
In GB, the installation must be carried out by a Gas Safe
Registered Engineer. It must be carried out in accordance with
the relevant requirements of the:
• Gas Safety (Installation and Use) Regulations
• Appropriate Building Regulations, either The Building
Regulations, The Building Regulations (Scotland), Building
Regulations (Northern Ireland).
• Water Fittings Regulations or Water byelaws in Scotland.
• Current I.E.E. Wiring Regulations.
Where no specific instructions are given, reference should be
made to the relevant British Standard Code of Practice.
The Boiler has been tested and certified to;
BSEN 15502-1, BSEN 15502-2, BSEN 15502-2-1, BSEN
60335-1, BSEN 60335-2-102, BSEN 55014-1 and BSEN
55014-2 for use with Natural Gas & Propane.
Detailed recommendations are contained in the following
British Standard Codes of Practice:
BS5440:1 Flues (for gas appliances of rated input not
exceeding 70 kW).
BS5440:2 Ventilation (for gas appliances of rated input
not exceeding 70 kW).
Heating Systems in buildings: Design for water
BSEN12828
based heating systems.
Heating Systems in buildings: Method for
BSEN12831
calculation of the design heat load.
Heating Systems in buildings: Installation
BSEN14336
and commissioning of water based heating
systems.
BS5546 Installation of gas hot water supplies for
domestic purposes (2nd Family Gases)
Installation of gas fired hot water boilers of
BS6798
rated
input not exceeding 70 kW.
BS6891 Installation and maintenance of low pressure
gas installation pipework.
BS 7593:2019 Code of practice for the preparation,
commissioning and maintenance of domestic
central heating and cooling water systems.
Health & Safety Document No. 635.
The Electricity at Work Regulations, 1989.
The manufacturer's notes must NOT be taken, in any way, as
overriding statutory obligations.
This appliance is UKCA/CE certificated for
IMPORTANT:
safety and performance. Do not connect external control devices
directly to this appliance unless recommended in this manual or
by Ideal Heating in writing. If in doubt, please enquire.
Unapproved control devices could invalidate the warranty of this
appliance and infringe the Gas Safety Regulations.
Installation and Servicing
Section 1 - General
1.6

SAFE HANDLING OF SUBSTANCES

No asbestos, mercury or CFCs are included in any part of the
boiler or its manufacture.
1.7

LOCATION OF BOILER

The boiler must be installed on a flat and vertical internal wall,
capable of adequately supporting the weight of the boiler and
any ancillary equipment.
The boiler may be fitted on a combustible wall and insulation
between the wall and the boiler is not necessary, unless
required by the local authority.
WARNING:
CAUTION: Do not fit the boiler outside.
Timber Framed Buildings
Boilers installed in a timber-framed building must comply with
IGE/UP7 +A 2008.
Bathroom Installations
CAUTION: This appliance is IP20 rated, do not clean
with jets of water.
You may install the boiler in any internal space. The installation
must comply with the current IEE (BS 7671) Wiring Regulations
and the electrical regulations applicable in Scotland.
If the appliance is to be installed in a room containing a bath or
shower then the appliance must be installed beyond Zone 2,
as detailed in BS7671.
Bathroom Installations
[0] Zone 0
[1] Zone 1
[2] Zone 2
[2*] Without the end wall, zone 2 must extend 600 mm from the bath
[A] 600 mm radius from the bath or shower
Rear access to the boiler is not permitted.
m
6 0 0 m
A
A
A
