Ideal Heating LOGIC COMBI2 C24 Installation & Servicing page 7

LOGIC COMBI
Natural Gas Only
BOILER SIZE G.C. Applicance No
kW (Benchmark No.)
24
30
35
Destination Country:
For UK, to comply with Building Regulations Part L1 (Part 6 in Scotland) the boiler should be fitted in accordance with the
manufacturer's instructions. Self-certification that the boiler has been installed to comply with Building Regulations can be
demonstrated by completing and signing the Benchmark Commissioning Checklist.
Before installing this boiler, read the Code of Practice sheet at the rear of this book.
B
oiler
Make and model ......................................................... 9
Appliance serial no. on data badge ................. Front Cover
SEDBUK No. % .......................................................... 8
Controls
Time and temperature control to heating ................. 29
Time and temperature control to hot water ............. 29
Heating zone valves ................................................ n/a
TRV's........................................................................ 12
Auto bypass .................................................................... 12
Boiler interlock .......................................................... 12
For all boilers
Flushing to BS.7593 ................................................. 15
Inhibitor ........................................................................... 15
Central heating mode
Heat input ...................................................to be calculated
NOTE TO THE INSTALLER: COMPLETE THE BENCHMARK
COMMISSIONING CHECKLIST AND LEAVE THESE
INSTRUCTIONS WITH APPLIANCE
Installation and Servicing
Section 1 - General
C
2
47-349-93
47-349-94
47-349-95
GB
BENCHMARK COMMISSIONING CHECKLIST DETAILS
Page
Burner operating pressure ...................................... n/a
Central heating flow temp. ...........measure and record
Central heating return temp. ........measure and record
For combination boilers only
Scale reducer ........................................................... 15
Hot water mode
Heat input ............................................to be calculated
Max. operating burner pressure .............................. n/a
Max. operating water pressure ........ measure & record
Cold water inlet temp ...................... measure & record
Hot water outlet temp. ..................... measure & record
Water flow rate at max. setting ........ measure & record
For condensing boilers only
Condensate drain ................................................25-26
For all boilers: Complete, sign & hand over to customer
Page
For assistance call Technical Helpline
01482 498663
7
