TITAN SERIES POWER RACK
90TITAN, 100TITAN, TITAN36, TITAN42, PUB114TITAN, PUB2TITAN,
TITANFDWN36, TITANFDWN42, TRLJHOOKS, TITANSNDJHOOK,
TITANLOGOSTB, TITANSTRAP36, TITANSTRAP42
Operator's Manual
Read the Operator's Manual entirely. When you see this
symbol, the subsequent instructions and warnings are
serious follow without exception. Your life and the lives
of others depend on it!
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Titan Fitness TITAN Series
Summary of Contents for Titan Fitness TITAN Series
- Page 1 TITAN SERIES POWER RACK 90TITAN, 100TITAN, TITAN36, TITAN42, PUB114TITAN, PUB2TITAN, TITANFDWN36, TITANFDWN42, TRLJHOOKS, TITANSNDJHOOK, TITANLOGOSTB, TITANSTRAP36, TITANSTRAP42 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives...
- Page 2 SAFETY TIPS WHEN ASSEMBLING YOUR TITAN SERIES, WE HIGHLY RECOMMEND THAT YOU… − ENLIST THE HELP OF A FRIEND − WATCH EACH OTHER AND BE MINDFUL OF YOUR SURROUNDINGS AS YOU PERFORM EACH ASSEMBLY STEP − EXERCISE EXTREME CAUTION, ESPECIALLY WHEN STANDING UP THE UPRIGHTS AND LIFTING PARTS OVERHEAD −...
- Page 3 PARTS DIAGRAM / EXPLODED VIEW...
- Page 4 PARTS DIAGRAM / EXPLODED VIEW (BOX 1 = TITAN1) DESCRIPTION (BOX 2 = TITAN2) UPRIGHT BASE FRAME UPPER FRAME LOGO PLATE 1.25 OR 2” PULL-UP BAR BAND PEG (16) FLAT WASHER Φ26*Φ44*4 (17) SPRING WASHER Φ24 (18) NUT M24 (19) BOLT M24*120...
- Page 5 90TITAN OR 100TITAN UPRIGHTS DESCRIPTION 1 (X2) (2) 90” TITAN UPRIGHTS 1 (X2) (2) 100” TITAN UPRIGHTS...
- Page 6 TITAN36 OR TITAN 42 DESCRIPTION LOWER SIDE BRACING UPPER SIDE BRACING BAND PEGS FLAT WASHER Φ26*Φ44*4 SPRING WASHER Φ24 NUT M24 HEX BOLT M24*120...
- Page 7 ASSEMBLY INSTRUCTION – TITAN SERIES POWER RACK 1. Secure each UPPER FRAME (3) and BASE FRAME (2) between two UPRIGHTS (1) using FLAT WASHERS Φ26*Φ44*4 (16), SPRING WASHERS Φ24 (17), NUTS M24 (18), and BOLTS M24*120 (19) as shown in the image below.
- Page 8 ASSEMBLY INSTRUCTION – TITAN SERIES POWER RACK 2. Install the LOGO PLATE (4) and PULL-UP BAR (5) between the UPRIGHTS (1) using FLAT WASHERS Φ26*Φ44*4 (16), SPRING WASHERS Φ24 (17), NUTS M24 (18), and BOLTS M24*120 (19) as seen in the figure below.
- Page 9 PUB114TITAN OR PUB2TITAN DESCRIPTION 1.25” OR 2” PULL UP BAR FLAT WASHER 26*44*4 SPRING WASHER 24 NUT M24 HEX BOLT M24*120...
- Page 10 TITANLOGOSTB DESCRIPTION LOGO FRAME FLAT WASHER 26*44*4 SPRING WASHER 24 NUT M24 HEX BOLT M24*120...
- Page 11 TITANSTRAP36 OR TITANSTRAP42 DESCRIPTION DESCRIPTION BRACKET SAFETY FLAT WASHER 17*30*3 STRAP REINFORCED SIDE NUT M16 PLATE REINFORCED REAR SCREW M16*125 PLATE SAFETY STRAP SCREW M6*10...
- Page 12 TITANFDWN36 OR TITANFDWN42 DESCRIPTION DESCRIPTION LEFT SAFETY ARM PLASTIC PLATE RIGHT SAFETY ARM SMALL PIN Φ6*45 PULL RING Φ1.5*31 PLASTIC PLATE CABLE Φ5.5*Φ1.6*330 (10) PLASTIC PLATE SCREW M6*10...
-
Page 13: Description Qty
TRLJHOOK DESCRIPTION DESCRIPTION LEFT J-HOOK FRONT PLASTIC PLATE RIGHT J-HOOK FLAT WASHER LOCK PIN NUT M12 ROLLER (10) HEX BOLT M12*110 SHORT PLASTIC PLATE (11) HEX BOLT M6*10 LONG PLASTIC PLATE... - Page 14 TITANSNDJHOOK DESCRIPTION DESCRIPTION LEFT J-HOOK REINFORCE PLATE FLAT WASHER RIGHT J-HOOK Φ6.6*Φ12*1.6 SLEEVE HEX BOLT M6*15 PLASTIC SAFETY HOOK HEX BOLT M6*10 BACK REINFORCE PLATE...
- Page 15 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non-economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims, demands, damages,...
- Page 16 NEED HELP? CONTACT US FIRST. 1-888-410-1503 info@titan.fitness www.titan.fitness © 2021 Titan Brands...
